Summary of Contents for Skovby Norra SM621
- Page 1 Assembly Instruction Samlevejledning...
-
Page 2: Table Of Contents
NORRA by Skovby Contents - Indhold SM621 SM622 SM631* * Only available with trays, door and/or drawers SM634* (AV ) * Only available with trays, door and/or drawers Mounting of modules Accessories - Tilbehør Plinths Sokler Ben i træ Wooden legs... -
Page 3: Sm621
SM621 / SM622 / SM631 / SM634 assembly instructions, options & comb. samlevejledning, muligheder og komb. Quantity Item Antal Varenr. 6 x A 994186 SM621 SM622 3 x B 994187 994285 SM634 SM631 AV Module 994287 994237... - Page 4 Fixed arrangement of modules Fast opstilling af moduler If you want a fixed arrangement of the modules, hanging on the wall or placed on a base, we recommend that you attach the modules to each other to ensure an aligned front. Drill three Ø5mm through-holes in the sides where there is room for hinges, drawer runners, shelves and trays and then insert the enclosed screws.
- Page 5 Mounting and demounting of brackets Montage og demontage af beslag Mounting - Montage Demounting - Demontage...
- Page 6 Adjustment of doors Justering af døre Before adjustering the doors The furniture MUST be levelled Før dørjustering Møblet SKAL nivelleres, så det står i lod/vater Adjusting depth - Dybdejustering Adjusting height - Højdejustering Adjusting Side - Sidejustering...
- Page 7 Slide-on assembly and adjustment Montage og justering af skuffer på glideskinne Slide-on assembly / Montage af skuffer på glideskinne Simple slide-on assembly The drawer is placed on the runners and simply pushed into place. Simpel skuffemontage Skuffen placeres på glideskinnerne og skubbes på plads. Solid connection The catch automatically locks the drawer securely to the Quadro pull-out function.
- Page 8 Recommended mounting heights Anbefalede ophængshøjder TOP of CABINET DRILLING MARKS DRILLING MARKS DRILLING MARKS DRILLING MARKS FOR WALL MOUNTING FOR WALL MOUNTING FOR WALL MOUNTING FOR WALL MOUNTING RECOMMENDED DISTANCE DRILLING MARK FOR FIXING FROM FLOOR OF TOP PLATE Please note that all measurements are Measure template enclosed Måle skabelon vedlagt shown in mm...
- Page 9 * It is necessary to check whether the wall is suitable and ensure that the fasteners are able to carry the weight of the module with contents. Skovby cannot be held responsible for whether your wall materials are suitable for fitting with the enclosed components, your fastening of fittings and suspension, or any resulting damage.
- Page 10 Weight and maximum load of NORRA modules Egenvægt og maksimal belastning af NORRA moduler Weight of the NORRA modules - Egenvægt af NORRA moduler SM621 - 7 kg SM622 - 13 kg SM631 - 13 kg SM634 - 9 kg Maximum load - Maksimal belastning 40 kg in total per module when wall mounted - i alt pr.
- Page 11 Tightening of brackets - more modules next to each other Spænding af beslag - flere moduler ved siden af hinanden If you have mounted more modules next to each other, we recommend that you tighten the bracket with the top screw to ensure that the fronts of the modules are aligned.
-
Page 12: Sokler
Plinths - assembly instructions Sokler - samlevejledning 63114 - 1 module Quantity Item Antal Varenr. 4 x a 994146 Adjustable feet Justerbare stilleskruer 63214 - comb. of 2 modules Quantity Item Antal Varenr. 8 x a 994146 Adjustable feet Justerbare stilleskruer 63314 - comb. -
Page 13: Wooden Legs
Wooden legs - assembly instructions Ben af træ - samlevejledning 63135 - 1 module Quantity Item Antal Varenr. 1 x a 994234 4 x b 994203 4 x c 994204 Quantity Item Antal Varenr. 4 x d 994146 Adjustable feet Justerbare stilleskruer... - Page 14 Wooden legs - assembly instructions Ben af træ - samlevejledning 63235 - comb. of 2 modules Quantity Item Antal Varenr. 1 x a 994234 4 x b 994203 4 x c 994204 Quantity Item Antal Varenr. 8 x d 994146 Adjustable feet Justerbare stilleskruer...
- Page 15 Wooden legs - assembly instructions Ben af træ - samlevejledning 63335 - comb. of 3 modules Quantity Item Antal Varenr. 1 x a 994234 4 x b 994203 4 x c 994204 Quantity Item Antal Varenr. 12 x d 994146 Adjustable feet Justerbare stilleskruer...
-
Page 16: Top Panels
Top panels - assembly instructions Topplader - samlevejledning 60001 / 60002 / 60003 / 60004 / 60012 / 60013 / 60014 - 1 module or comb. of 2, 3 or 4 Use the enclosed measuring template for marking Quantity Item the drilling holes to fix the top panel. - Page 17 Top panels - assembly instructions Topplader - samlevejledning...
-
Page 18: Bakker
Trays - assembly instructions Bakker - samlevejledning 62124 / 62125 Quantity Item Antal Varenr. 62124 12 x a 994046 6 x b 62138 62125 16 x a 994046 8 x b 62138... -
Page 19: Wooden Shelves
Wooden shelves - assembly instructions Hylder i træ - samlevejledning 62118 / 62218 Quantity Item Antal Varenr. 4 x a 994194 62118 62218... - Page 20 Placing more NORRA modules on each other Placering af flere NORRA moduler ovenpå hinanden Comb. SM621 / SM622 / SM631 /SM634 When stacking the modules, we recommend using the enclosed self-adhesive non-slip buttons (item no 994237). Ved stabling af modulerne anbefales det at bruge de medfølgende selvklæbende anti-skrid knapper (varennr. 994237). Attaching cover caps Montering af dækkapper SM621 / SM622 / SM631 / SM634...
-
Page 21: Remote Link
Remote Link logo you are able to control your receiver with an infrared signal, e.g. a DVD, a digital receiver, media centre, video and audio equipment etc. Your Skovby Remote Link is compatible with all AV appliances receiving between 30-60 KHz, which is the standard of lead- ing IR remote control brands. - Page 22 IR receiver IR-Empfänger IR modtager Fixed IR-transmitters Fest montierte IR-Transmitter Fastmonterede IR transmittere Insert the plug from the power supply to the connection box. Stecker für die Stromversorgung in die IR-Verteilerbox stecken. Stik fra strømforsyning isættes fordelerbox. ↑ 4 + 5...
- Page 23 OBS! Ved køb af et NORRA by Skovby AV modul med Remote Link, medfølger et ekstra kabel på 2 meter, som kan bruges til at videreføre signalet fra fra et modul til et andet. For at opnå det bedste signal, anbefales det at transmitteren placeres forrest i kabinettet.
- Page 24 Skjult kabelføring til AV moduler Concealed wiring for AV modules Versteckte Kabel Leitung für AV Module...
-
Page 25: Led Light
- quick and easy assembly - touch sensor function or switch on/off at the power outlet Skovby #79060 comprises an LED touch sensor light. Combined with Skovby #79050, power consumption for max. 4 LED lights. - stilrent design i aluminium - op til 30.000 brændetimer... - Page 26 Light - LED lights available Lys - tilkøb af LED lys Options for mounting Muligheder for montering...
- Page 27 NORRA overview - NORRA oversigt Design din egen reol/opbevaringsmøbel - med NORRA fra Skovby Vælg moduler og fronter (Alle fronter leveres monteret fra fabrik og er klar til vægmontering) MODUL FRONT OG DØRE KUN FOR SM631 SM631 SM631+ SM631+ SM631+...
-
Page 28: Led Lys
NORRA overview - NORRA oversigt Design your own bookcase/storagefurniture - with NORRA by Skovby Choose modules og fronts (All fronts are delivered assembled, ready for wall mounting) MODULE FRONTS AND DOORS ONLY for SM631 SM631 SM631+ SM631+ SM631+ SM631+ SM631+... - Page 29 Skovby Møbelfabrik A/S Frichsvej 43 DK - 8464 Galten www.skovby.dk...
