MDT Technologies RF-AKK1ST.01 Technical Manual

Rf-socket with active power measurement
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
01/2015
Technical Manual
MDT RF-Socket
KNX RF+
RF – AxK1ST.01
RF-AKK1ST.01 - RF+ Socket
RF-AZK1ST.01 - RF+ Socket with active power measurement
MDT technologies GmbH,Geschäftsbereich Gebäudeautomation
1
Tel.: +49-2263-880
Fax: +49-2263-4588
E-Mail:automation@mdt.de
•
•
www.mdtautomation.de
•

Advertisement

Table of Contents
loading

Related Manuals for MDT Technologies RF-AKK1ST.01

Summary of Contents for MDT Technologies RF-AKK1ST.01

  • Page 1 01/2015 Technical Manual MDT RF-Socket KNX RF+ RF – AxK1ST.01 RF-AKK1ST.01 - RF+ Socket RF-AZK1ST.01 - RF+ Socket with active power measurement MDT technologies GmbH,Geschäftsbereich Gebäudeautomation Tel.: +49-2263-880 Fax: +49-2263-4588 E-Mail:automation@mdt.de www.mdtautomation.de • • •...

  • Page 2: Table Of Contents

    5 Parameter - Measurement ......................... 31 5.1 Active power measurement ......................31 5.2 Current measurement ......................... 34 5.3 Voltage measurement ......................... 36 5.4 Meter ............................38 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 3 7 Attachment ............................40 7.1 Statutory requirements ....................... 40 7.2 Routine disposal .......................... 40 7.3 Assemblage ..........................40 7.4 Datasheet ............................ 40 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 4: Overview

    The device communicates via the KNX RF+ protocol. Detailed information for planning and working with radio lines via the KNX RF+ protocol can be downloaded at http://www.mdt.de/EN_Downloads_Manuals.html. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 5: Aufbau & Bedienung

    LED. Via a long key press, the programming mode is activated/deactivated. An active programming mode is shown by the red programming LED. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 6: Functions

    2 counters, main and sub meters, are available. With these various power measurements for daily / weekly / monthly or annual values can be realized. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 7: Settings At The Ets-Software

    (6) Loading of the application, with requested parameterization (7) If the device is enabled you can test the requested functions(also possible by using the ETS- Software) MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 8: Communication Objects

    Visu... after activating scenes. For calling for manual of saved scenes, which are saved in control the actuator. (= Additional function) MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 9 (Nr. 85) is devices true. Only available for switching output. Table 1: Communication objects switching output MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 10 Socket sends Visu, Diagnostic, Communication object is shown at A tuator… meter exceedance of current measurement and current monitoring of current MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 11 Reset of the main Visu, Push Communication object is shown at Butto … meter activated meters Table 2: Overview objects - Measurement MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 12: Default Settings Of The Communication Objects

    The flags allocates the function of the objects in the programming thereby stands C for communication, R for Read, W for write, T for transmit and U for update. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 13: Parameter - Switch Channel

    The following diagram shows the behavior of the relay operating mode normally closed and normally opened. The input for the channels is a KNX-telegram, which sends alternating 0-signals and 1-signals: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 14: Central Function

    [default value]  Behavior when locked Behavior to a  Behavior when unlocked blocking/unblocking process  no change Table 7: Behavior at block/unblock MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 15 The blocking function is deactivated agai y se di g a logi al . “o the ha el is s it hed off. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 16: Switching Output

    By choosing a channel as switch, a sub menu, called Channel A Switching, appears for this channel at the left drop down menu. The sub menu is shown at the following illustration: Figure 5: Switching output MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 17 Activation of the scene function  active by activation this parameter a new sub menu appears (have a look at 4.4.4) Table 9: Switching output MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 18: On-/Off-Delay

    Both functions work as well alone as combined. By adjusting switched off. The following diagram describes the combination of on and off delay: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 19: Logical Functions

    Logic object 1, is the first input for the logic block Logic 2 1 Bit Logic object 2, is the second input for the logic block Table 10: Communication objects logic MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 20 Switch Logic 1 Logic 2 Channel On/Off switched? On/Off switched? Nein Nein Nein Nein Nein Nein Nein Nein Table 11: Logic function MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 21: Scene Function

    The calling device, e.g. a binary input, sends automatically the right value for calling the scene. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 22 There are up to 8 storage options for scenes at every channel. These 8 storage options can get any of the possible 64 scene numbers. Figure 10: Sub function scene MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 23  On Scene number H 1-64 Scene number; Calling value = 1 less than the adjusted scene number Table 13: Parameter scene MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 24 0x18 0x98 0x19 0x99 0x1A 0x9A 0x1B 0x9B 0x1C 0x9C 0x1D 0x9D 0x1E 0x9E 0x1F 0x9F Table 14: Calling and saving scenes MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 25 At the next call of the scene, the scene will be called with the new value. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 26: Staircase

    By choosing a channel as staircase, a sub menu, called Channel A Staircase, appears for this channel at the left drop down menu. The sub menu is shown at the following illustration: Figure 12: Staircase MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 27  no change  Off Behavior when unlocked Action for deactivating the blocking  On process  no change Table 15: Parameter staircase MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 28: Staircase Time

    The following chart shows the relevant communication object: Number Name Length Usage Staircase 1 Bit Calling of the staircase function Table 16: Communication object staircase MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 29: Prewarning Und Warning

    (next switch, length of the staircase, etc.). The whole duration of the switching process is the sum of the 3 times. The following diagram shall make this clear: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 30: Manual Switch Off

    (have a look atTable 16: Communication object staircase). The following diagram shows the behavior of this parameter: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 31: Parameter - Measurement

    The following parameters are only in the RF socket with active power meter, RF AZK1ST.01, available. 5.1 Active power measurement The following figure shows the menu active power measurement: Figure 17: Menu "Active power measurement" MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 32 Table 17: Menu "Active power measurement" MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 33 Sending an exceedance of load Lower deviation of load 1 Bit Sending a deviation of load Table 18: Communication objects power measurement MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 34: Current Measurement

    [no send] measured current Send cyclic no send, 5min-24h defines the sending behavior of the [no send] measured current MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 35 Sending an exceedance of load Lower deviation of 1 Bit Sending a deviation of load current Table 20: Communication objects current measurement MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 36: Voltage Measurement

    [no send] measured voltage Send cyclic no send, 5min-24h defines the sending behavior of the [no send] measured voltage MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 37 Sending an exceedance of voltage Lower deviation of 1 Bit Sending a deviation of voltage voltage Table 22: Communication objects voltage measurement MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 38: Meter

    1 Bit Reset value of sub meter Reset main meter 1 Bit Reset value of main meter Table 24: Communication objects meter MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 39: Index

    Table 21: Menu voltage measurement ....................37 Table 22: Communication objects voltage measurement ..............37 Table 23: Menu meter ........................... 38 Table 24: Communication objects meter ....................38 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...

  • Page 40: Attachment

    All activities on the device should only be done by an electrical specialist. The county specific regulations and the applicable EIB-directives have to be observed. 7.4 Datasheet MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
  • Page 41 • Compatible to the new KNX RF+ speciication • 3 years warranty DIN EN ISO 9001 51766 Engelskirchen • • MDT technologies GmbH Papiermühle 1 TAW Cert Tel.: + 49 - 2263 - 880 Fax: + 49 - 2263 - 4588 •...
  • Page 42 EU Declaration of Conirmity Socket RF+ Hereby, MDT technologies GmbH declares that the radio equipment type radio RF-AxK1ST.01 is in compliance with directive 2014/53/EU. The full text of the EU declaration of conirmity is available at the following internet address: www.mdt.de/download/MDT_CE_RFAKK.pdf...
