Neurotech Vital Quick Start Manual page 8

English
Correct Electrode Positioning
We strongly recommend that the patient wears high-thigh underwear (e.g. a thong), which leaves
the buttocks exposed (Fig. a).
If they are wearing full brief underwear, they must adjust the back of the briefs to expose the buttocks.
This is because the electrodes need to make full contact with the skin on the buttocks and the hips.
When positioned correctly, the 8 electrodes should be positioned as shown in Fig. b.
Fig. a Fig. b
8
