Summary of Contents for Naxa NPD-1004
- Page 1 10 INCH PORTABLE DVD MODEL:NPD-1004 PLEASE READ CAREFULLY BEFORE OPERATING THIS EQUIPMENT KEEP IT IN A SAFE PLACE FOR FUTURE REFERENCE...
- Page 2 WARNING: CAUTION T O R E D U C E T H E R I S K O F F I R E O R RISK OF ELECTRIC SHOCK ELECTRIC SHOCK, DO NOT EXPOSE THIS DO NOT OPEN PRODUCT TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF WARNING: ELECTRIC SHOCK, DO NOT REMOVE...
- Page 3 7 ) D o n o t b l o c k a n y v e n t i l a t i o n WARNING openings. Install in accordance with the USE UNDER SUPERVISION OF AN ADULT manufacturer's instructions. DUE TO LONG CORD This unit has a long AC cord or other long Slots and openings in the cabinet and in the...
- Page 4 moved with care. Never push objects of any kind into the Quick stop, excessive force, and uneven product through openings as they may touch surfaces may cause the appliance and cart dangerous voltage points or short out parts combination to overturn. that could result in fire or electric shock.
-
Page 5: Notes On Handling
to this product, ask the service technician to NOTES ON HANDLING: perform safety checks to determine that the ● When shipping the unit, always use the product is in proper operational condition. original shipping carton and packing materials. For maximum protection, repack the unit as it 23 ) Wall or ceiling mounting was originally packed at the factory. - Page 6 of the glass. In the same way, moisture may condense on the optical pick-up lens inside this unit, one of the most crucial internal parts of the DVD player. Moisture condensation occurs during the following cases: ● When you bring the DVD player directly from a cold place to a warm place. ●...
-
Page 7: Playable Discs
DISCS The region number for this DVD Player is: See the following page for information regarding region numbers. PLAYABLE DISCS: The following discs can be played back on this DVD player: DISC TYPES: Data on most DVDs is divided into sections called titles and then into subsections called chapters, each of which is given a title or chapter number. -
Page 8: Location Of Controls
LOCATION OF CONTROLS AUDIO STOP MENU PLAY/ PAUSE VOL+ MUTE SETUP VOL- USB/SD BT PAIR 1. AUDIO Button: Press repeatedly to switch the audio mode. 2. STOP Button: Press once to pre-stop, press again to stop completely. 3. MENU Button: Press to enter root menu playing(it depen s on the disc recording). 4. - Page 9 LOCATION OF CONTROLS Right Side View: 16. A V OUT Jack 13. USB Port 14. SD/MMC CARD Slot 17. Power ON/OFF Switch Headphone Jack 18. DC IN Jack Front Side View: 19 20 19. Charge Indicator 21. Bluetooth/Power Indicator 20. Remote Sensor...
-
Page 10: Remote Control
REMOTE CONTROL 1. STANDBY Button 2. VOLUME +/– Buttons MUTE Button 4. MENU Button STANDBY 5. Direction Buttons Skip Chapter/Track Button Fast Forward Button (Play/Pause Button 9. USB/CARD Button 10. TITLE Button MENU (STOP Button 12. AUDIO Button 13. GOTO Button 14. -
Page 11: Battery Installation (Remote Control)
BATTERY INSTALLATION (REMOTE CONTROL) Battery installation: 1. Press the tab on the battery door and lift it off. 2. Ins two (2) x AAA size batteries (not included) into the battery compartment as the Figure on right with the proper polarity markings inside battery compartment. -
Page 12: Power Source
POWER SOURCE There is a built-in DC 7.4V Lithium-ion rechargeable battery. Recharge it as follows: Charging by the AC/DC adaptor: 1. Connect the small plug from the supplied AC/DC Adapter to the DC IN Jack on the unit. 2. Connect the AC/DC Adapter to the wall outlet with AC100-240V~; 50/60Hz. 3. - Page 13 CONNECTIONS Connecting to a TV or Video Player such DVD; VCR; DVR Players ... Video input jack ( Yellow ) (A V connection cable not included) Audio left channel input jack ( White ) Audio right channel input jack ( Red ) Connect to...
-
Page 14: Headphone Operation
), after a while, Activate the Bluetooth on your Bluetooth device (such as smart the pairing name "NPD-1004" will appear on pairing list, select it and try pairing. The Bluetooth indicator will blue slowly and a beep tone will be heard after connection... - Page 15 Connect with DVD player Bluetooth on" and the Press and hold the button to power on the headphone, the unit will say "power Bluetooth indicator will blue and red alternatively. Switch on the DVD Player, the Bluetooth Indicator will Blue. After a while, the Heaphone will automatically connect with DVD player, the Bluetooth Indicator on DVD player will stay on.
- Page 16 OPERATIONS 1. Lift up the panel and turn to desired angle. Slide the Power ON/OFF switch to "ON" position to power on the unit. 2. Press the OPEN button to open the disc cover. Place the disc on the center spindle with the label side facing up. Close the disc door and the player will start playback automatically.
- Page 17 OPERATIONS LCD ON/OFF ANGLE During DVD playback, press repeatedly to select the Press to turn on or off the LCD display. viewing angle (Function depends on the recording of STANDBY disc). Press to power on the unit from standby mode, press again to put the unit into standby mode.
-
Page 18: Usb Or Card Playback
USB or CARD PLAYBACK 1. Insert the USB Device or SD/MMC memory card into the USB port/slot as the figure below. 2. Switch on the unit, press the USB/CARD Button on remote control or press the DVD/USB/CARD Button on the unit, the "DVD, CARD, USB" selection window will pop up on the screen. Using the Direction Buttons to select and highlight the desired source then press the OK Button to confirm to start playing. - Page 19 SETUP Press the SETUP Button on the remote control or on the unit, the setting menu will appear on screen as below. Using the Direction Buttons to highlight the function needed to set or reset. Press the OK Button to enter or confirm the selection. After setting, press the SETUP button to save the settings and exit. - - General Setup Page - - TV Display Wide...
-
Page 20: System Setup
SYSTEM SETUP In Video Setup Page: 1.When PDVD Picture is selected, use the Directional and OK buttons to set the panel quality for Sharpness, Brightness, Contrast, Hue, or Saturation as preferred. 2.When Output Video is selected, use the Directional and OK buttons to set the Sharpness, Brightness, Contrast, Gamma, Hue, or Saturation of the Video output signal as preferred. -
Page 21: Care And Maintenance
CARE AND MAINTENANCE Caring for Discs Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to contact with the shiny, unprinted side of the disc. ● Do not attach adhesive tape, stickers, etc. to the disc label. ●... -
Page 22: Specifications
SPECIFICATIONS Power Source: Power Source: Built-in DC 7.4V Lithium-ion rechargeable battery, recharge by DC 9-12V,1000mA Car Charger: 12V, 2000 mA Disc Compatibility: DVD/VCD/CD/CD-R/CD-RW/DVD ±R/DVD±RW SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE ACCESSORIES 1 x User's Manual 1 x AC/DC Adapter 1 x Remote Control 1 x Car Adapter 1 x Headphone...
