INNOVATION IN MAGNETICS
OM3224/4
Operation Manual for
CU1 Helmholtz Coil System
Control Unit
www.bartington.com

Advertisement

Table of Contents
loading

Summary of Contents for Bartington CU1

  • Page 1 INNOVATION IN MAGNETICS OM3224/4 Operation Manual for CU1 Helmholtz Coil System Control Unit www.bartington.com...
  • Page 2: Table Of Contents

    6.2. CU1 Control Unit Connection to the PA1 Power Amplifier 6.2.1. Current Control Output 6.2.2. Current Monitor Input 6.3. Sensor Connection to CU1 Control Unit Device Under Test Input 6.4. Sensor Connection to CU1 Control Unit Auxiliary Input 6.5. CU1 Control Unit Connection to NI Acquisition Card 6.6.
  • Page 3: About This Manual

    BARTINGTON INSTRUMENTS 1. About this Manual This manual provides the information necessary to help customers install and operate the CU1 Control Unit. It is one component of the Bartington Instruments Helmholtz Coil System. This manual should therefore be read in conjunction with: •...
  • Page 4: Safe Use

    PA1, whilst current monitor signals are return to the CU1. It also provides signal filtering and power supply to one or two magnetometers connected to the Auxiliary and/or Device Under Test inputs. Compatible NI cards can be directly connected to the back of the CU1 for ease of interface.
  • Page 5: Cu1 Features

    3. Device Test Input 4.1.1. ON/OFF Power Switch with LED Indicator The ON/OFF power switch [5] controls AC mains power to the CU1 Control Unit. The LED indicator has two colour states (red or green) and is controlled by the user software.
  • Page 6: Rear Panel

    The CU1 Control Unit is compatible with Bartington Instruments PA1 for use in Bartington Helmholtz Coil System. The CU1 is also compatible for use with the CU2 Closed-Loop Module. A range of National Instruments card can directly connect to the CU1. A non-exhaustive list of compatible card is included here: •...
  • Page 7: Cu1 Control Unit Installation

    6.1. Test Assembly Location and Ventilation Requirements The CU1 has no forced ventilation requirements and can be sited typically on top of the PA1. The CU1 and PA1 should be located at least 3m from the Helmholtz Coils to avoid interferences.
  • Page 8: Sensor Connection To Cu1 Control Unit Auxiliary Input

    CU1 to the acquisition card can be found in Appendix The CU1 will emit a beep when connection to a National Instruments acquisition card and PC is not detected. The beep will also sound at powering up until the Helmholtz Coil Control Software is started.
  • Page 9: Powering Sequence

    Before powering the system, you should ensure that all the connections between the Helmholtz Coil and the PA1, the PA1 and the CU1 and/or CU2 as well as the CU1 to a suitable National Instruments acquisition card (or PXI-system) are done.
  • Page 10: Disposal

    BARTINGTON INSTRUMENTS 10. Disposal This product should not be disposed of in domestic or municipal waste. For information about disposing of this product safely, check local regulations for disposal of electrical / electronic products. 10.1. Waste Electrical and Electronic Equipment (WEEE) Regulations...
  • Page 11: Appendix A: Connecting The Components Of The Helmholtz Coil System

    BARTINGTON INSTRUMENTS Appendix A: Connecting the Components of the Helmholtz Coil System PXI CHASSIS Sensor Optional Connector 0 Connector 1 aux sensor if required Current Current Device Control Input Monitor Test Output Input Input Current Current Monitor Control Output Input...
  • Page 12: Appendix B: Helmholtz Control Unit Cu1 Daq/Pxi Connection

    BARTINGTON INSTRUMENTS Appendix B: Helmholtz Control Unit CU1 DAQ/PXI Connection Analogue Outputs PXI function Pin (Cn1) Signal Auxiliary X output AI.16 Auxiliary Y output AI.17 Auxiliary Z output AI.18 Device Under Test X output AI.19 Device Under Test Y output AI.20...
  • Page 13 BARTINGTON INSTRUMENTS PSU Monitor Select 2 P0.18 No Connection P0.19 No Connection P0.20 PSU Monitor Enable P0.21 No Connection P0.22 No Connection P0.23 Auxiliary Input select P0.24 Device Under Test Input Select P0.25 Device Under Test Input Polarity P0.26 Reserved P0.27...
  • Page 14 BARTINGTON INSTRUMENTS Device Input gain Signal PXI function Device Under Test Input Gain P0.10 Device Under Test Input Gain = 100 Device Under Test Input Gain = 1 Input Filter Signal PXI function Filter Enable P0.29 Filter Select 0 P0.30 Filter select 1 P0.31...
  • Page 15 The power supply monitor voltage returns half the actual measured voltage. The power supply currents return the current measured across a 1 Ohm (1%) resistor. Reserved lines may be used for later enhancements by Bartington Instruments. All Reserved lines must be held at logic High (+5V).
  • Page 16 BARTINGTON INSTRUMENTS CN0 Connections pin-out Control Unit Signal PXI pin Name In/out Range Reserved P2.6 0/5V Digital Reserved P2.4 0/5V Digital Reserved P2.1 0/5V Digital Digital Ground D.Gnd Ground 0V Nominal Reserved P1.6 0/5V Digital Reserved P1.5 0/5V Digital Digital Ground D.Gnd...
  • Page 17 BARTINGTON INSTRUMENTS Reserved P1.4 0/5V Digital Reserved P1.3 0/5V Digital Reserved P1.2 0/5V Digital Digital Ground D.Gnd Ground 0V Nominal Reserved P2.2 0/5V Digital Reserved P2.3 0/5V Digital Reserved P0.3 0/5V Digital Reserved P0.7 0/5V Digital Reserved P0.2 0/5V Digital Digital Ground D.Gnd...
  • Page 18 BARTINGTON INSTRUMENTS PSU Monitor Select 1 P0.17 0/5V Digital PSU Monitor Select 0 P0.16 0/5V Digital Digital Ground D.Gnd Ground 0V Nominal Digital Ground D.Gnd Ground 0V Nominal No Connection Digital Ground D.Gnd Ground 0V Nominal Reserved P0.14 0/5V Digital Device Under Test Self-Test P0.9...
  • Page 19 BARTINGTON INSTRUMENTS P0.13 0/5V Digital AUX Test Enable P0.8 0/5V Digital Digital Ground D.Gnd Ground 0V Nominal Analogue Input Ground AO.Gnd Ground 0V Nominal Analogue Input Ground AO.Gnd Ground 0V Nominal Analogue Output Ground AI.Gnd Ground 0V Nominal No Connection AI.23...
  • Page 20: Appendix C: Guidance For Connection To Mains Supply

    NEUTRAL GREEN/YELLOW EARTH 4. It is essential that the control unit CU1 and the Power Amplifier PA1 are properly earthed at all times. 5. It is recommended that the mains to each unit is supplied via an appropriate mains fuse:-...
  • Page 21 ®The copyright of this document is the property of Bartington Instruments Ltd. Bartington is a registered trademark of Bartington Instruments Limited in the following countries: Australia, Brazil, Canada, China, European Union, India, Israel, Japan, Mexico, New Zealand, Norway, Russia, Singapore, South Korea, Switzerland, Turkey, United Kingdom, United States of America and Vietnam.
