- Page 1 Operating manual Core drilling system (Drill stand/Drill motor) KDS-XXL-R & DK 32 (S)
-
Page 2: Table Of Contents
Manual 0. Introduction Warning symbols You bought a drilling system of KERN- DEUDIAM firm. We thank you for purchase and we wish you successful and long-term work. We are always General danger open for your questions and offers. Attention: At the installation of system it is necessary to observe the rules EG-RL 2006/42/EG. -
Page 3: System Description
3.3 Delivery set: In order to avoid traumas use only the original equipment and the diamond tool of KERN- Drill stand KDS-XXL-R DEUDIAM. Drill motor DK 32 Manual. 3.1.2 Use of motor The motor is used according to data on the plate on the motor case. -
Page 4: Technical Data
2. stand 3. carriage 4. handle 5. support 6. foot 7. regulating screw 8. motor Type: KDS-XXL-R Max. drill diameter: 400 mm Max. drill bit length: 570 mm Max. power of motor: 3.5 kW Drilling with angle: up to 45º... -
Page 5: Instructions Of Safety
Manual 5. Instructions of safety 5.3 General measures of safety 5.1 Basic terms Use the original additional KERN- Before mounting the motor on a DEUDIAM equipment which is support and beginning the work, described in this manual. The use please attentively read the safety equipment from other... -
Page 6: First Steps Of Operation
Manual Operation while drilling requires Check the electrical connections after each use concentration. If you are overstrained or you are of the system for damages and address a under the influence of medication or narcotic professional electrician in case of damages. substances, operation on drilling is strictly Electrical instruments shall be checked by the forbidden. - Page 7 Manual During the drilling work pay attention to have 6.2 Fastening of drill stand enough water for cooling. Use only clear water from a water supply system, by no means – dirty 6.2.1 Expansion bolt (anchor) water or sewage. For our range of drill stands: KDS-150, KDS- Speed switching 200, KF-250, KDS-XXL, BS-620, XXXL-600 we recommend our checked anchor.
- Page 8 Manual 6.2.3 Other options of fastening Pressure upon a drill bit : up to 250 N/cm² (approx. 25 Kp/cm²) Fast-extensible support The active surface of drilling by segments Ø 107 mm : 7,5 cm² Ø 162 mm : 11,5 cm² The maximum pressure (F1) Ø...
-
Page 9: Management Of System
Manual an adjustment of the carriage by means of 7. Management of system special screws. Carriage shall move parallelly in 7.1 Drilling with angle relation to a stand. For drilling with angle loosen the bolts (on the For this purpose it is necessary: picture). -
Page 10: Warranty
KERN-DEUDIAM doesn't have any Address: responsibility concerning this manual. KERN DEUDIAM Diamantwerkzeuge und In addition to this the KERN-DEUDIAM Maschinen GmbH firm doesn't have responsibility for Industriestrasse 24 errors in the operation manual and in D-33161 Hövelhof... - Page 11 Manual 03/2015...
-
Page 12: Eu Declaration Of Conformity
EU machine directive as regards concept, design and the commercially available version. This declaration becomes null and avoid when any changes are made to the machine without our consultation and approval. Producer: KERN DEUDIAM Diamantwerkzeuge und Maschinen GmbH Industriestrasse 24, D-33161 Hövelhof, Germany Core drilling system Designation of the machine: XL-R &... - Page 13 Manual List of spare parts 03/2015...
- Page 14 Manual 03/2015...
- Page 15 Manual Stand (Säule) pos. article article-nr. quant. remark 100a Stahlgrundplatte 47874 6kt-Schraube M12 x 120 47945 Spannbuchse 47847 Mutter M12 47946 U-Scheibe 47947 Schild 47969 6kt- Schraube 14157 Hutmutter 14922 Gelenkstück 49454 optional Spannklotz 47873 6kt-Schraube M12 x 100 47948 6kt-Schraube M12 x 40 47949 Abstützung...
- Page 16 Manual 03/2015...
- Page 17 Manual Carriage (Vorschub) Pos. Bezeichnung Artikelnr. Anz. Bemerkung 400.1 Vorschubeinheit Rollen kompl. 49065 Vorschubschlitten 47877 402.1 Vorschubwelle vierkant 48835 Zylinderstift 5 x 28 m6 47879 Nadellager RNA 4902 47866 Ring 47870 Schmiernippel D1 M6 47872 Abdeckscheibe 47840 Sicherungsring 15mm 47958 Buchse 1 47845 Excenterwelle...
- Page 18 Manual Vorschubgetriebe, kompl. 48485 Antriebswelle vierkant 49003 Antriebsritzel 48488 Zahnrad 48895 Deckel 48487 Gehäuse 48486 Spannstift 11578 Druckstück 14248 Nadellager 48491 Rillenkugellager 49074 Rillenkugellager 15142 Stellring 42321 Zylinderschraube 13952 Zylinderschraube 13976 Stützscheibe 14281 Zylinderstift 11535 Senkkopfschraube 14110 Spannstift 11564 Kegelschmiernippel 14262 Accessories Vakuum-Pumpe (80l/min)
