AGS Merlin User & Installation Manual
Gas safety products 2800ppm. co2 monitor
Hide thumbs
Also See for Merlin:
- User & installation manual (6 pages) ,
- Installation & operation manual (12 pages) ,
- Installation & operation instructions (16 pages)
Related Manuals for AGS Merlin
Summary of Contents for AGS Merlin
- Page 1 Merlin CO2 Monitor 2800ppm User & Installation Manual Gas Safety Products Merlin CO2 Monitor 2800PPM Installation, operating and maintenance Rev: 04 Date: 09-07-18...
- Page 2 How to turn the system on and off ..............3 Explanation of LED status ................3 3.2.1 Low (Green) LED .................... 3 3.2.2 Medium (Amber) LED ..................3 3.2.3 High (Red) LED ....................3 Merlin CO2 Wiring Diagram ................ 4 Rev: 04 Date: 09-07-18...
-
Page 3: General Information
If the CO2 reaches alarm level the Merlin CO2 Monitor would sound an audible alarm to alert the user and also send a signal to the Merlin gas control system which will in turn close the gas solenoid valve. - Page 4 Merlin CO2 Wiring Diagram Mains Input 100-240V, L & N Alarm relay, volt free connection to Merlin system. Pre alarm relay, volt free connection to Merlin system. Temperature relay. 0-10V output, low voltage connection. Audible alarm switch, ON = ON / 1 = OFF...
- Page 5 Merlin CO2 Monitor 2800ppm User & Installation Manual Specification Power Supply 120VAC, 50Hz (Max. 2VA) Carbon Dioxide: Non-Dispersive Infrared Detector (NDIR) Gas Sensor ABC Logic Self Calibration CO2 Measuring Range 0-9999ppm (Resolution: 1ppm) Accuracy @ 25°C (77°F) ±100ppm +6% Reading Temperature Measuring Range 0-50°C (Resolution: 0.5°C)
