MS-6115 Multifunction Power Meter Instructions
Please read the following instructions carefully before connecting this meter to electrical appliances.
WARNING!
Do not plug two or more meters together!
Indoor use only!
Not position the energy meter so that it is difficult to disconnect it from the supply!
Don't plug in an appliance where the load exceeds 10 Amp. Always ensure the plug of any appliance is fully inserted into the meter
outlet. If cleaning of the meter is required, remove from mains power and wipe meter with a dry cloth.
1. MASTER CLEAR: Clear all data in memory including current time and all programs.
2. UP: Set current time, price, price programs combined with buttons SET; exchange 12-24 hour mode during clock display state.
3. SET: Set current time, price, price programs combined with buttons UP.
4. FUNC: Exchange display state.
1. Display current clock.
2. Display line voltage.
3. Display line current.
4. Display line power.
5. Display and memory accumulative total electric quantity.
6. Display and memory total on time and total electric charge,.
7. Display and memory total on time and total electric charge of price1.
8. Display and memory total on time and total electric charge of price2.
9. Display line frequency.
10. Display power factor.
11. Adjustable price / kWh
11 combinations of day or blocks of days available as follows:
MO
TU
WE
TH
FR
SA
SU
MO,TU, WE, TH, FR
MO,TU, WE, TH, FR, SA
SA, SU
MO, TU, WE, TH, FR, SA, SU
Insert the 3 pcs battery(LR44/AG13) according to the correct direction indication, close the cover of battery.Press master clear
button after insert battery.now the power meter is now ready to be set up for use.
Note: 1. The cover must be in place before use.
2. The battery must be taken out if not use for long time.
Press FUNC button the data displays as follows:
VOLTac → AMP → WATT →KWh →TOTAL PRICE;TOTAL ON TIME → PRICE1 → PRICE2
↑_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _↓
1.The meter will display current clock and line voltage, frequency, if plug in socket after insert battery without any operation.
2. Press FUNC button once and release, the meter will display current clock and line current, power factor.
3. Press FUNC button once again and release, the meter will display current clock and real power, power factor.
4. Press FUNC button once again and release, the meter will display current clock and accumulative KWh,power factor.
5. Press FUNC button once again and release, the meter will display total on time and total electric charge.
6. Press FUNC button once again and release, the meter will display total on time of price 1 and total electric charge of price 1.
7. Press FUNC button once again and release, the meter will display total on time of price 2 and total electric charge of price 2.
8. Press FUNC button once again and release, the meter will come back to display current time and line voltage.
Press and hold FUNC button for 5 seconds to clear accumulative total electric quantity and total electric charge during display
state of total electric charge or total electric charge of price 1 or total electric charge of price 2.
----
when total electric quantity, total electric charge overflow, the OVER will flash at the same time.
9. LCD display
1. Press FUNC button until the CLOCK displays in LCD.
IMPORTANT
KEYBOARD DEFINITION
GENERAL FEATURES
BATTERY
THE DATA DISPLAY
SETTING CURRENT CLOCK
