Appendix A. Schematic and Layouts

A.1

INTRODUCTION

This appendix contains the following schematics and layouts for the PICkit™ Serial
2
I C™ Demo Board User's Guide:
• Board – Schematic
• Board – Top Silk Layer
• Board – Top Metal Layer
• Board – Bottom Metal Layer
© 2007 Microchip Technology Inc.
PICkit™ SERIAL I
BOARD USER'S GUIDE
2
C™ DEMO
DS51657A-page 9
