2.6.2 Cclusion settings of NVR channel video

1> In the {Channel} drop-down list, select the channel that
needs to be masked. A total of 4 overlapping regions are
supported.
2>In the < video screen > menu, select the area, and select
the appropriate color in the ｛color｝drop-down list.
3>Left click the settings screen button, NVR will select
the channel full screen display, the user through the drag to
achieve specific areas of the Screen occlusion.
Description: NVR only supports the CMI protocol for
IPC video occlusion configuration. If the area was not
checked, set the screen area button does not play a role.

2.6.3 set the PTZ parameters of NVR

1> left menu select [PTZ parameters]
2> select the PTZ channel you need to configure. For example, channel 1 connect Speed Dome Cameras, protocol PELCO-D,
the baud rate is 1200. According to the requirements of the Speed Dome Cameras, configure the PTZ parameters. we will not
give necessary details on the meaning of each PTZ parameter.
3> according to the NVR actual connection of the camera type, whether or not need to use [copy to] button. If the NVR is
connected to the 16 Speed Dome Cameras, then just configure one channel then copy the configuration of the channel to the
other 15 channels.
