- Page 1 V1.0 Network Video Recorder User manual © 2001-2016 Anviz Global Inc.
- Page 2 Introduction Thank you for using our products, if you have any questions or support needs, please feel free to contact us. Applicable models This manual applies to all NVR products of our company Declaration We have done our best to ensure integrity and accuracy of the manual content, but also unavoidable to encounter Inaccurate technical issues , product functions does not match the operations or printing errors and so on, if you have any questions or disputes, please refer to our final interpretation.
-
Page 3: Table Of Contents
Index Product Introduction .................. 4 1.1 MiniStore ..................4 1.2 TurboStore ................... 5 1.3 EverStore ..................7 Using Instructions ..................9 2.1 Operating Conventions ..............9 2.2 Switch device ................10 2.2.1 Switch .................. 10 2.2.2 Shut down ................10 2.2.3 log in .................. - Page 4 2.10.6 GB/T28181 Settings ............32 2.10.7 Cloud Services Settings ............32 2.11 Advanced settings ..............33 2.11.1 Serial Port Settings .............. 33 2.11.2 Video output ................ 33 2.11.3 Alarm output ................ 34 2.11.4 hard disk management ............34 2.11.5 User Management ..............35 2.11.6 Automatic maintenance ............
-
Page 5: Product Introduction
Product Introduction 1.1 MiniStore Front Panel Definitions Definition Features Status POWER Power indicator Power normal，always bright Network status After network connection, it starts blink, blinking speed depends on network flow indicator light amount. Hard disk status Hard disk will blink while identification, blinking speed depends on identification indicator speed. -
Page 6: Turbostore
1.2 TurboStore Front Panel Definitions Definition Features Status POWER Power indicator Power connected ,always bright light Network status after network connection,it starts blinking, blinking speed depends on network flow indicator light amount. Hard disk status hard disk will blink while identification , blinking speed depends on identification indicator speed. - Page 7 VGA video interface Microphone interface Speck Earphone speaker interface drop in temperature...
-
Page 8: Everstore
1.3 EverStore Front Panel Definitions Definition Feature Status POWER Power indicator Power is normal, always on Power switch Physical boot on shutdown Hard disk status hard disk will blink while identification , blinking speed depends on identification indicator speed. USB2.0 interface to connect the mouse to control the operation of the device Back Panel Definitions Serial... -
Page 10: Using Instructions
Using Instructions 2.1 Operating Conventions Mouse operation instructions name action Description Left click Click Select and confirm in menu operation. Double Preview, playback, single-screen, multi-screen display switch. Click Right click Click Preview: pop-up menu. Menu: Exit the current menu and return to the preview window. Video playback: Exit the video playback. -
Page 11: Switch Device
2.2 Switch device 2.2.1 Switch Note Make sure that the voltage applied to the NVR matches the requirements of the NVR and that the grounding terminal of the NVR is well grounded. if the Power supply is not normal, The NVR will be unable to work , or even damage the NVR, it is recommended to use a stabilivolt power supply Specific boot steps are as follows: 1>... -
Page 12: Log In
2.2.3 log in User login / password protection User login： After Equipment normal boot , you need to log in before operation, The system provides the corresponding functions according to the login access rights. The default user name is admin and the password is admin. -
Page 13: The Main Interface Right-Click Menu
2.3 The main interface right-click menu Right click in the main interface will pop up [main interface right-click menu] 1> Single-screen / four-screen / six-screen / eight-screen / nine-screen / sixteen screen split screen selection, you can configure the interface. After selecting a single page, you can select one of the 32 channels to display. - Page 14 Return to the main page and save the settings Right-click in the settings interface to quickly return to the main interface. If you modify the NVR parameters in the setup interface, you will be prompted for the options to be modified.. The user can confirm the last time whether or not to save the changes.
-
Page 15: Common Settings
2.4 Common settings Main Interface [Right] → [Main Menu] → [Common Settings] pop-up Common Settings interface. Device name: The user can modify the device name through the right soft keyboard. it Supports Chinese and English input. Model: Displays the device model. Serial Number: Shows the device serial number . - Page 16 operation, provide automatic logout function. After logging off, once again the operation of NVR requires administrator account login. Synchronous IPC Time: Configure the time interval for IPC to synchronize IPC. To ensure that all devices within the system time consistency. Daylight saving time: tick the option, check the relevant daylight saving time configuration.
-
Page 17: Ipc Management
2.5 IPC Management Main interface [right] [main menu] [IPC management] pop-up IPC management interface. 2.5.1 Manually add IPC by CMI protocol 1> search IPC: left click the [search] button, search the available cameras in the current NVR network. The default choice for ｛all types｝, NVR will first search available cameras in the network through the CMI protocol network , and then the ONVIF protocol can be used to search the cameras. -
Page 18: Through The Cmi Protocol To Modify The Ipc Network Address And A Shortcut To Add Ipc
Although the CMI protocol can search different network segments Cameras, but if you want to successfully connect, you must ensure that the IPC and NVR in the same segment. Need to configure the IP of IPC. See 2.5.2 through the CMI protocol to modify the IPC network address. -
Page 19: Adding Ipc Through The Onvif Protocol
2.5.3 adding IPC through the Onvif protocol 1> search IPC: left click the [search] button, search the available cameras in current NVR network. Select {Onvif}, NVR will be able to use the ONVIF protocol and search the available cameras. Description: ONVIF can only search IPCs that have the same segment with NVR. If you need to use ONVIF to add IPC, you need to set the network parameters of IPC or NVR, ensure that they are in the same segment. -
Page 20: Channel Setup
2.6 Channel setup The main interface [right] [main menu] [channel settings] into the < channel Settings > interface. 2.6.1 OSD settings of the NVR Channel 1> In ｛Channel｝ list ,select the channel that need to modify its OSD information. 2> Edit the title: on the right side of the soft keyboard pop-up NVR corresponding channel of IPC channel Title to do the configuration. -
Page 21: Cclusion Settings Of Nvr Channel Video
2.6.2 Cclusion settings of NVR channel video 1> In the {Channel} drop-down list, select the channel that needs to be masked. A total of 4 overlapping regions are supported. 2>In the < video screen > menu, select the area, and select the appropriate color in the ｛color｝drop-down list. -
Page 22: Encoding Settings
2.7 Encoding settings The main interface [right click] [main menu] [encoding settings] enter < encoding Settings > interface. 1> channel: select a certain channel of NVR , set a coding information of the front camera of the connection channel . 2>... - Page 23 Note: CBR: fixed rate, in accordance with the set bit rate, ignore the complexity of the image, all in accordance with the set bit rate coding. VBR: is a set of dynamic rate, the encoding of the video based on the rate ceiling and the level of image quality , if the image is still simple texture, then it will make out a small stream, if the image is made up of complex motion texture, then it will make out larger stream.
-
Page 24: Video Settings
2.8 Video settings The main interface [right click] [main menu] [video settings] into the < Video Settings > interface. 2.8.1 NVR Video parameter setting 1> pre recording time setting: pre recording time can be set to 5-10S. 2> stream settings: select the video stream : the main stream / sub stream. - Page 25 1> channel selection: select the channel you need to configure the video program. Configuration of other channels can be completed through the [copy to] button. 2> working days: one week after the completion of the configuration ,you can use 【Copy to】 button, to configure the other a few days a week.
-
Page 26: Event Management
2.9 event management The main interface [right click] [main menu] [event management] into the < Event Management > interface. 2.9.1 Alarm linkage instructions Alarm Description: the chapter mainly describe the NVR linkage strategy when event alarm input occurs, a variety of alarm events leads to similar linkage strategy, So in the following section we will afford giving unnecessary details on dynamic strategy significance. -
Page 27: Description Of The Effective Time Of Various Alarm Linkage Strategy
2.9.2 Description of the effective time of various alarm linkage strategy Strategy Effective Time Description: This chapter describes the various events when the alarm input occurs, NVR various linkages strategies in this effect are same, so this section to have small introduction, will not repeat them in the follow-up sections . -
Page 28: Occlusion Detection Linkage
2.9.4 Occlusion detection linkage Occlusion detection linkage: Enable this feature, the camera changes according to the image, when the camera is blocked, will output Occlusion alarm signal. Can be used as linkage video, alarm, capture and other actions. 1>Channel: Select the desired configuration occlusion detection channel. The number of channels corresponds to the maximum number of access routes of the NVR. -
Page 29: Network Abnormal Linkage
2.9.7 Network Abnormal Linkage Network Abnormal Linkage: Provides an alarm when the network is abnormal. Such as NVR network port loose lead to network disconnection. 2.9.8 Hard disk abnormal linkage Hard disk abnormal linkage: 1>Disk less alarm: after power on If you do not detect the hard disk or is working to detect hard disk ,the loss of the hard disk will produce this alarm 2>Hard Disk Error: This alarm is generated when the hard disk is present but unable to read and write it properly 3>Hard disk full: When the recording mode is not set to cycle coverage，The video will lead to the depletion of disk capacity... -
Page 30: Network Settings
2.10 Network settings 2.10.1 Basic network settings 1> work mode: Some NVR models have 2 network ports , so in the work mode select Multi-site mode, the default network port LAN0. Multi-site: two network card parameters independent of each other, work with each other, select the ‘network port’ LAN0 and LAN1respectively for settings. -
Page 31: Pppoe Settings
2.10.2 PPPOE Settings 1> Enable: If you need to open a PPPoE connection, Please enable the check box. Note: The user name and password are available from the operator. 2.10.3 NTP Settings Enable NTP,to ensure the accuracy of the system time through periodic timing of NTP server . 1>... -
Page 32: Email Settings
2.10.4 Email Settings Enable Email, when an alarm is generated, it can send a message to the specified mailbox . 1> Enable: Check the box to enable this feature. 2> Enable SSL: If SSL is enabled, fill the SMTP port with 465. If SSL is not enabled,ill the SMTP port with 25. 3>... -
Page 33: Gb/T28181 Settings
2.10.6 GB/T28181 Settings GB / T28181-2011 "security video surveillance network system information transmission, switching, control technology requirements" was proposed by the Ministry of Science and Technology Information Bureau, by the National Security Alarm System Standardization Technical Committee (SAC / TC100) centralized, Ministry of Public Security Such a number of units with the drafting of a national standard. -
Page 34: Advanced Settings
2.11 Advanced settings 2.11.1 Serial Port Settings 1> Depending on the NVR model, some NVRs do not have a serial port, then this option can not be selected. 2> How to configure the specific parameters of the serial port Please contact the project management personnel to confirm. -
Page 35: Alarm Output
2.11.3 Alarm output 1> Channel: Select the alarm output channel to be set, and then click the [Copy To] button to copy the settings to the corresponding channel. 2> Type: normally open alarm output is an open circuit or high voltage, normally closed refers to the hardware alarm output is closed circuit or low voltage. -
Page 36: User Management
2.11.5 User Management 1>In this menu you can modify add a login account . 2>Permissions settings: you can set the preview and configuration permissions for NVR. Default admin is administrator privileges 2.11.6 Automatic maintenance 1> Open: Enable Auto Maintenance 2> Select Auto Reboot time: optional week and specific reboot time 2.11.7 Default parameters... - Page 37 1> The content of this page is used to select the restore full function or part of the function to the factory settings. 2> The default factory IP of the device: 192.168.100.219 3> Default account / password: admin / admin...
-
Page 38: Video Playback
2.12 Video playback The upper right corner of the interface, search box introduction 1> Start Time / End Time: Select the start and end time, you can select the date by the mouse wheel selection, you can manually enter through the soft keyboard. 2>... -
Page 40: Video Backup
2.13 Video backup Video backup interface: the main interface, right-click menu -> video backup Mobile storage device: plug the mobile memory on USB interface in or plug in the mobile hard disk on ESATA port , then in the first column will display the detected removable memory. -
Page 41: Maintenance Information
2.14 Maintenance information about 1> System information includes the product model, serial number, system software version number and software release date. 2> Insert the USB flash drive with the upgrade file. Click 【Upgrade】 button. In the pop-up menu, select the correct upgrade file to upgrade. - Page 42 View the device operation log 1> Select the time period for which you want to query the log, and click Search. 2> The device operation log is displayed. 3> Backup Log: Click [Backup] button, select the appropriate path in the external USB disk, NVR will be in the specified directory backup TXT format log files.
- Page 43 System Information 1> Green represents the current access traffic of the NVR. Red represents the forwarding traffic of the current NVR. 2> Blue represents the current CPU usage of the NVR. Yellow represents the forwarding traffic of the current NVR Note: Depending on the model, the NVR restricts the access forwarding traffic.
-
Page 44: Setup Wizard
2.15 Setup Wizard Common settings and device list 1> Common settings: can be used frequently to set the customer. Language, resolution, time zone, date format, date, time, NTP. The setting method is the same as in the main menu. 2> Device list: Click the Search button to search for devices on the network. - Page 45 Account settings and mobile remote preview 1> Account settings: You can change the current password, 2> to disable the ‘enable password’ option, each boot, enter the system does not require a password, please choose carefully. Mobile phone remote preview: use the phone to scan the left side of the two-dimensional code then install to customer phone ‘Remote Preview APP’;...
-
Page 46: Technical Support
Technical Support Frequently Asked Questions 3.1.1 CMI can find the camera, but can not preview the image after adding it Serial Possible causes / solutions number Check whether the NVR is on the same network segment as the IPC. Even if the NVR and IPC are not on the same network segment, you can also search IPC. -
Page 47: In The Process Of Upgrading, Unplug The Memory Or Restart The Device Can Not Boot The Device ,How To Deal With This
3.1.6 In the process of upgrading, unplug the memory or restart the device can not boot the device ,how to deal with this Serial may cause / solution number 1 equipment curing procedure is damaged, please contact our technical support ask for equipment replacement. -
Page 48: Hard Disk Space Consumption
3.2 Hard disk space consumption A list of storage space occupied by single channel code Resolution / stream size time occupied space 1080P/4M 1 hour 1.75G 1080P/4M 1 day 42.2G 1080P/4M 1 week 295.4G 1080P/4M 1 month 1266G 720P/2M 1 hour 0.875G 720P/2M 1day...
