- Page 1 Portable Wireless IrDA Printer Instruction 24-9422 Operation & Maintenance Rev. 0 – September 2001 Product Leadership • Training • Service • Reliability...
- Page 2 WARRANTY Bacharach, Inc. warrants to Buyer that at the time of delivery this Product will be free from defects in material and manufacture and will conform substantially to Bacharach Inc.’s applicable specifications. Bacharach’s liability and Buyer’s remedy under this warranty are limited to the repair or replacement, at Bacharach’s option, of this Product or parts thereof...
-
Page 3: Table Of Contents
Cleaning the Printer ... 8 Opening / Closing the Paper Cover ... 8 Cleaning the Print Head ... 8 Installing the Paper ... 9 Parts & Service ... 10 Replacement Parts ... 10 Sales / Service Centers ... 10 Instruction 24-9422 Contents... - Page 4 IrDA Printer Notes: Instruction 24-9422...
-
Page 5: Description
Description General Bacharach’s portable wireless printer uses infrared technology to commu- nicate with other Bacharach instruments that are capable of transmitting data using the Infrared Data Association (IrDA) standard. The printer is designed around a patented easy-loading paper mecha- nism, which consists of a main cavity into which a paper roll is dropped for loading. -
Page 6: Power Switch
Description Power Switch Use the Power switch located on the left side of the printer to turn the unit ON and OFF (see Figure 1). Indicator LEDs There are two LEDs on the front panel that provide the following infor- mation about the printer’s status:... -
Page 7: Sensors
IrDA Printer Sensors There are three sensors that perform the following functions: • Paper Cover: When the paper cover is open the printer is disabled to prevent damage to the print head. This condition is indicated by the Power LED flashing. -
Page 8: Technical Characteristics
Battery Pack ... Lit-ion, 7.2 V, 1650 mAh Weight ... 13 oz (0.4 kg) Dimensions ... 3.6 x 5.5 x 2.0 in. (92 x 140 x 51 mm) Sweden, Italy, Spain, Japan, Norway, Denmark II, Korea 12 V, 3 A (without battery) IrDA Printer Instruction 24-9422... -
Page 9: Operation
• Avoid dirty or dusty locations, or those with excessive heat or humidity • Choose a stable level or solid wall on which to mount the printer • Use only the supplied power adapter to charge the battery pack •... -
Page 10: Set-Up Mode
Operation Set-Up Mode The printer has been set up at the factory with the following default parameters: Baud rate : 9600 bps Handshaking : DTR Country : U.S.A. Print mode : Text (upright) Paper : Normal paper IrDA : IrDA-SIR If necessary, the default parameters can be changed as follows: 1. -
Page 11: Using The Printer
Turn ON the printer and, if necessary, set it up as previously described under the heading Set-Up Mode. Also ensure that the instrument that is sending data to the printer is set up to operate in its IrDA print mode (refer to the instrument’s instruction manual for set up information). -
Page 12: Maintenance
To maintain a good print quality, it is recommended that the print head be cleaned at least once a year or up to once a month if the printer is used heavily. The print head should be cleaned immediately, however, if the print becomes visibly fainter due to contamination of the print head. -
Page 13: Installing The Paper
Note: If there was unprinted data in memory when the paper ran out, and the printer was not shut OFF, then the printer will automatically go on-line and print the remaining data 5 seconds after closing the paper cover. -
Page 14: Parts & Service
Parts & Service Replacement Parts Complete Printer Kits: 120VAC: includes printer, 120V AC adapter, 12V in-car charger, belt clip, and instruction manual ... 24-1229 230VAC: includes printer, 230V AC adapter, 12V in-car charger, belt clip, and instruction manual ... 24-1230 Paper roll, thermal ... -
Page 15: Sales / Service Centers
Texas 5151 Mitchelldale, B-4 Houston, TX 77092 Phone: 713-683-8141 Fax: 713-683-9437 E-mail: txservice@bacharach-inc.com Instruction 24-9422 Canada Bacharach of Canada, Inc. 250 Shields Court Unit #3 Markham, Ontario L3R 9W7 Canada Phone: 905-470-8985 Fax: 905-470-8963 E-mail: bachcan@idirect.com México Bacharach de México Playa Regatas No. - Page 16 World Headquarters 621 Hunt Valley Circle, New Kensington, PA 15068 Ph: 724-334-5000 • Fax: 724-334-5001 • Toll Free: 800-736-4666 Website: www.bacharach-inc.com • E-mail: help@bacharach-inc.com Printed in U.S.A.
