TINYON IP 2000 PIR - Quick Install
Ø6.35 mm
1
(0.25 in)
x2
x2
Template
1
Safety
1.1
Safety precautions
CAUTION!
Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE!
Indicates a situation which, if not avoided, could result in
damage to the equipment or environment, or data loss.
CAUTION!
The Low Voltage power supply unit must comply with EN60950
/ UL60065. The power supply must be a SELV-LPS unit or a
SELV - Class 2 unit (Safety Extra Low Voltage - Limited Power
Source).
CAUTION!
Installation should only be performed by qualified service
personnel in accordance with the National Electrical Code
NEC800 (CEC Section 60) or applicable local codes.
NOTICE!
Video loss is inherent to digital video recording; therefore,
Bosch Security Systems cannot be held liable for any damage
that results from missing video information. To minimize the
risk of lost digital information, Bosch Security Systems
recommends multiple, redundant recording systems, and a
procedure to back up all analog and digital information.
2
microSD
card
RJ45
+5 VDC
Ethernet (PoE)
Default: DHCP on
(no DHCP: 192.168.0.1)
1.2
Important safety instructions
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions
5.
Do not use this apparatus near water.
6.
Clean only with a dry cloth.
7.
Install in accordance with the manufacturer's instructions.
8.
Do not install unit near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9.
Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
10. Only use attachments/accessories specified by the
manufacturer.
11. Unplug this apparatus during lightning storms or when
unused for long periods of time.
12. Refer all servicing to service personnel. Servicing is
required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
3
1 2 3 4
Reset
Pin
11 mm
1
(0.4 in)
Alarm in
2
3
Alarm out
4
1.3
FCC & ICES compliance
FCC & ICES Information
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
–
reorient or relocate the receiving antenna;
–
increase the separation between the equipment and
receiver;
–
connect the equipment into an outlet on a circuit different
from that to which the receiver is connected;
–
consult the dealer or an experienced radio/TV technician
for help.
Intentional or unintentional modifications, not expressly
approved by the party responsible for compliance, shall not be
made. Any such modifications could void the user's authority to
operate the equipment. If necessary, the user should consult
the dealer or an experienced radio/television technician for
corrective action.
4
Bosch Video Client
http://downloadstore.boschsecurity.com/
BVC-installer.exe
Wizard
1.4
Bosch notices
Disposal - Your Bosch product was developed and
manufactured with high-quality material and components that
can be recycled and reused. This symbol means that
electronic and electrical appliances, which have reached the
end of their working life, must be collected and disposed of
separately from household waste material. Separate collecting
systems are usually in place for disused electronic and
electrical products. Please dispose of these units at an
environmentally compatible recycling facility, per European
Directive 2002/96/EC
Optical elements
Optical elements are sensitive and should be protected at all
times. Do not allow objects to come into contact with glass
surfaces and do not touch optical elements with your fingers.
Copyright
This manual is the intellectual property of Bosch Security
Systems and is protected by copyright.
All rights reserved.
Trademarks
All hardware and software product names used in this
document are likely to be registered trademarks and must be
treated accordingly.
Note
Bosch Security Systems accepts no liability for damage
resulting directly or indirectly from faults, incompleteness or
discrepancies between the user guide and the product
described.
More information
For more information please contact the nearest Bosch Security
Systems location or visit www.boschsecurity.com
