- Page 1 O U T S T A N D I N G A L T E R N A T I V E S S T A T I C C O N T R O L BFN™ Static Eliminators BFN 802 Ionizing Blower Instruction Manual...
-
Page 2: Table Of Contents
Contents BFN 802 BFN Series Description Features Specification Operating Guide Dis/Assembly Bulb Replacement Periodic Verification About Service/ warranty Transforming Technologies... -
Page 3: Bfn Series
Description Series Ionizers ® Dependable, Balanced and Fast. BFN® AC ionizers, from Transforming Technologies, are built to last. Reliable AC ionization technology is combined with superior mechani- cal design to assure years of optimal static neutralizing performance. A full 1 year warranty. -
Page 4: Features
Description Please read these operating instructions thoroughly be- fore operating the BFN 802 unit. All BFN series devices require a grounded power source for proper operation. BFN series products are NOT suitable for use in flamma- ble or explosive environments. -
Page 5: Specification
1000V- Finish 100V, fan speed on high Powder Coat, off white Temperature Approvals 32-122° F (0-50° C) RH Operating Range 20-60%, non-condensing Packing list: BFN 802 ionizing blower Power cord Instruction manual Certificate of Conformance... -
Page 6: Operating Guide
BFN 802 Performance Discharge time in seconds (1000 volts to 100volts) determined per EOS/ESD Associa- tion Standard NO.3; unit at 18” above test plate, fans at high speed. Discharge times are slightly longer for 230VAC, 50Hz unit. Tested in accord with ANSI/ESD STM3.1-2006 Operating Guide 1. -
Page 7: Dis/Assembly
Operating Guide Cont Emitter point cleaning: All BFN series ionizing blow- ers include an integrated emitter point cleaning brush on the inlet fan guards. Turn the emitter point cleaners clockwise, then counter clockwise several times, until points are clean. When finished, return the point clean- ing brush to its resting position. - Page 8 Air Inlet Disassembly A. Press the recessed release point on the bottom of the plastic rear cover using a flat blade screw- driver. B. Gently push the cover upwards. C. Lift the rear cover up and away from the metal casing.
- Page 9 Air Outlet Assembly A. Slide the slot on the upper back side of the front fan guard onto the metal case. B. Push upward from the bottom of the front fan and gently press into the metal casing, until attached. C.
-
Page 10: Bulb Replacement
Bulb Replacement The BFN 802 comes with two task lights to eliminate the work station and improve worker efficiency. The unit comes with two 5W bulbs already installed. -
Page 11: Periodic Verification
E. Replace light cover and slide to the right to lock in place. Periodic Verification: BFN ionizer have no user serviceable parts and the technology requires no calibration because of the inherently stable ioniza- tion output from the AC emission. Periodic verification is rec- ommended, per ANSI/ESD SP3.3-2006 Periodic Verification of Air Ionizers. -
Page 12: Transforming Technologies
Transforming Technologies. The company does not warrant damage due to misuse, neglect, alteration or accident. In no event shall Transforming Technologies be liable for collateral or conse- quential damages. To receive service under warranty, please contact Transforming Technologies Technical Sup- port.
