KICKER AMP
INSTALLATION GUIDE
FOR USE WITH HARLEY DAVIDSON 2014+ FLHT
INCLUDED IN THIS FIT KIT:
> Step-by-step Installation Guide
> 6 1/2" Kicker Speakers Pair
> Kicker Amp 200W
> Stainless Steel Mounting Bracket
> Custom Wiring Harness
&
SPEAKER
> All Necessary Hardware
- 8 - 32 x 1/2" Button Head Bolts
- 8 - 32 Nylock Nuts
- Black Heat Shrink
- Black Cable Tie
- Mounting Hardware
Advertisement
Table of Contents
Related Manuals for KLOCK WERKS Kicker PXA 200.2
Summary of Contents for KLOCK WERKS Kicker PXA 200.2
- Page 1 KICKER AMP & SPEAKER INSTALLATION GUIDE FOR USE WITH HARLEY DAVIDSON 2014+ FLHT INCLUDED IN THIS FIT KIT: > Step-by-step Installation Guide > All Necessary Hardware > 6 1/2” Kicker Speakers Pair - 8 - 32 x 1/2” Button Head Bolts >...
-
Page 2: Getting Started
KLOCK WERKS | FLHT KICKER AMP AND SPEAKER INSTALLATION IMPORTANT INSTALLATION NOTE: Over-tightening mounting fasteners may result in damage to your motorcycle. Please refer to your service manual for proper procedures and torque specifications. We cannot be responsible for damage resulting from improper installation techniques. This kit may not be compatible with some aftermarket head units. - Page 3 KLOCK WERKS | FLHT KICKER AMP AND SPEAKER INSTALLATION (CONTINUED) AMP INSTALLATION MAKE SURE GAIN SETTING ON AMPLIFIER IS SET TO 0 7. Fasten the amplifier to the bracket with the supplied hardware. a. Insert the bolts through the bottom of the bracket and install the locknuts to the amplifier 8. Using the supplied ¼” hardware, fasten the amp/bracket assembly to the radio chassis with the 12 pin connector facing the clutch side HARNESS INSTALLATION 9. Plug the harness into the amplifier and route the speaker wires to their respective locations (1) a. Separate the speaker connectors and plug in the amplifier harness to each speaker 10. Plug the switched power harness into the 2-place amp connector on the right side (2) 11. Plug the blue wire on the kicker harness into the switched power harness lead with one wire a. This allows for an accessory 12V port to remain available...
