- Page 1 C.da Cerreto, 55 - 66010 MIGLIANICO (CH) – Italy Tel. (+39) 0871/950329 Fax (+39) 0871/950687 http://www.caldaiedalessandro.it e-mail: info@caldaiedalessandro.it Heat generator with mobile grid burner for woody biomasses Serie CSA 30-100 GM USE and MAINTENANCE MANUAL Ver. 1.0 - QCGM30100UK0313...
- Page 2 ATTENTION Refer to section 6 in this manual to install the boiler. Make sure to have fulfilled the following obligations before switching on the ma- chine: Electric Connections The following connections are compulsory upon installation: Mains power supply Ambient thermostat Circulation pump N.B.
- Page 3 Figure A Flue The flue represents one of the fundamental elements of the heat gen- erator. The correct designing, in the form and dimensions of the fumes evacuation system guarantees the correct and always efficient generator functioning and prevents potentially dangerous situations for the user. For correct installation, refer to section 6.5 at page 23 of this manual and, however, use experienced staff.
-
Page 4: Table Of Contents
INDEX MAIN INFORMATION Identification and purpose of the document Technical data plate CE Marking Standard of reference Typographical conventions Warranty and responsibility SAFETY AND RESIDUE RISKS Risks linked to using the generator Residue risks Intended use of generator Improper use of generator TECHNICAL FEATURES AND DIMENSIONS Illustration of generator functioning Description of generator functioning... - Page 5 Frequent heat request condition Occasional heat request condition Regulation Primary and secondary comburent air regulation Conical screw fuel regulation Grid speed regulation 7.10 Switch-off CLEANING Generality Table of the periodical maintenance operations MAINTENANCE Generality Table of the periodical cleaning operations ANOMALIES, FAULTS AND MALFUNCTIONING, FAQ and Answers 10.1 Anomalies and Faults Table 10.2 Malfunctioning table...
-
Page 6: Main Information
1. MAIN INFORMATION Identification and purpose of the document This instructions manual, drawn up by D'ALESSANDRO TERMOMECCANICA, is integrating part of the heat generator, which reproduction, even partial, is forbidden. The purpose of this document is to supply the users of the generator all information necessary for its correct use, in the safest conditions for persons, animals and things. -
Page 7: Standard Of Reference
The warranty is only valid towards the original client and only when he has fully become the ow- ner of the generator. Controversies between D'Alessandro Termomeccanica and the purchaser will be solved by means of arbitration; in case of no agreement on the arbitration panel, the competence will be of the Court of Chieti. -
Page 8: Safety And Residue Risks
2. SAFETY AND RESIDUE RISKS 2.1 Risks linked to using the generator The generator is manufactured in compliance with the essential safety requisites requested by the European Directives applicable to it. The European and National Regulations relating to the safety concerning said type of machine have been considered during designing, bearing in mind the state-of-the-art. -
Page 9: Intended Use Of Generator
PROTECTION HELMET OBLIGATION During all handling and transport of generators. PROTECTION MASK OBLIGATION During all maintenance and cleaning of the flues. 2.3 Intended use of generator The generator produces low pressure hot water, it is suitable for non-powdered solid fuel combustion with mechanical feeding. Any other use constitutes improper use. -
Page 10: Technical Features And Dimensions
3. TECHNICAL FEATURES AND DIMENSIONS 3.1 Illustration of generator functioning Il The generator body is of "Marina" type while the burner consists of a thick metal base with insulating cast which lower part houses the mobile grid. The fuel fumes released on the grid make four smoke turns transferring heat to the generator body's metal walls and constitute a system for the production of hot water for civil and industrial heating. -
Page 11: Description Of Generator Functioning
3.2 Description of generator functioning The fuel in CSA GM type generators is extracted from the circular hopper through specific motorised blades that convey it towards the drop hole in the upper screw. The rotary valve has the function of interrupting the fuel's continuity between the two screws, preventing return of eventual flames that might rise back up to the fuel hopper. -
Page 12: List Of Components And Spare Parts
3.3 List of components and spare parts The following figures illustrate the CSA GM generator's main components. The list of the parts will be subsequently quoted for the identification of the spare parts and as reference for the descriptions in the subsequent chapters. Fig.3.3.1.A... - Page 13 Fig.3.3.1.B...
- Page 14 CSA GM MODEL COMPONENTS KEY POS. DESCRIPTION CODE Boiler body Burner base Lower door safety end run Secondary air electric fan Ashes extraction screw motor Combustion check lower inspection hole Ash collection draw Lower door Mobile grid cast iron firebars Fire-resistant panels Inspection hole Upper door...
-
Page 15: Technical Features
3.4 Technical features Tab.3.4.1 details all technical features of the ”CSA GM” mod. generators. Tab.3.5 shows the overall dimensions of all models. For any other information, please contact the technical department of D’ALESSANDRO TERMOMECCANICA s.r.l. CSA30 CSA45 CSA60 CSA80 CSA100 BOILERS MODELS nominal power (kW) -
Page 16: Main Dimensions
Main dimensions tab. 3.5 Dimension K* refers to the rear stub dimensions in case of disassembly for screws maintenance/replacement. This dimension is to be considered during the generator's design and/or insertion in the thermal power stations. - Page 17 3.6 Connections / connessioni The dimensions of all connections present on the generators, based on the model, are summa- rised in tab.3.6 with reference to fig.3.5. Connessioni Idrauliche POS. Q.tà DESCRIZIONE TIPO UNITA' DIMENSIONI Pos. Q.ty description type unit dimension mandata manicotto ISO7/1 - DN...
-
Page 18: Fuel
4. FUEL 4.1 Fuels usable by CSA GM model Wood original solid fuel is admitted for use, which: Vegetable material produced by forestry, forest maintenance and by pruning interventions, from the machining of raw wood: cortex, sawdust, chippings and firewood chippings, flakes and wood chippings from the wood industry machining or from woodworking without glues or other chemical substances. -
Page 19: Transport And Handling
5. TRANSPORT AND HANDLING 5.1 Generality The heat generator is supplied fully assembled and ready for installation. It is protected with packaging material and fixed on wooden platforms for handling with forklift . 5.2 Transport and handling The generator transport and handling operations must be carried out by qualified staff us- ing suitable hoisting means. -
Page 21: Installation And Testing
6. INSTALLATION AND TESTING 6.1 Main installation prescriptions The electric and thermo-hydraulic installation of the heat generator and any other assistance and extraordinary maintenance intervention, must be carried out by persons registered in the installing companies register instituted with C.C.I.A. (Chamber of Commerce, Industry, Craftsman and Agri- culture). -
Page 22: Flue And Draught
6.5 Flue and draught The flue represents one of the most important elements for the correct functioning of the genera- tor. Usually, to obtain a good draught, the flue must be thermally insulated, possibly designed with double insulated wall to avoid the cooling of the fumes and, therefore, maintain that pressure dif- ferent enabling the fumes to rise along the chimney pipe up to the external output. -
Page 23: Electric System And Connections
fig. 6.6.3 6.6 Electric system and connections. The generator is equipped with non automatic main switch. We recommend protecting the plant's power supply line by means of a differential mag- neto-thermal switch with intervention threshold not higher than 30 mA. All foreign masses and piping will be connected by means of equipotential pipe to a ground node. -
Page 24: Start-Up, Ignition And Check
7. START-UP, IGNITION AND CHECK This is also a description of the ignition process and fuelling. In this case, the actions to be taken depend on the control unit, therefore refer to its manual for further details. See attachment “A” or attachment “B” 7.1 Commissioning checks Before generator commissioning it is essential to check that: The installer has issued regular Certification of Conformity... -
Page 25: Occasional Heat Request Condition
7.5 Occasional heat request condition The control unit allows connecting an external timer to avoid the fuel inside the firebox going out and the consequent re-ignition operations, in the event of no hot water request for long periods. This device allows the control unit to activate the screw at regular inter- vals, providing sufficient fuel to maintain the firebox ignited. - Page 26 (fig. 7.8.1) with reference to arrow (A) on the carter. These nominal regulation values are shown in tab. 7.8. fig. 7.8 REGOLAZIONE NOMINALE MODELS (no. turns/min.) CSA30 GM 0.24 CSA45 GM 0.36 CSA60 GM 0.49 CSA80 GM 0.64...
-
Page 27: Switch-Off
ATTENTION!! It is forbidden to exceed the maximum regulation values in case of using fuel with higher l.h.v. by 4.9 kWh/kg. 7.9 Mobile grate speed regulation The mobile grate is moved by gear motor that turn a threaded bar giving an alternate hor- izontal move to the structure of the grid mobile placed in the lower part of the basement. -
Page 28: Cleaning
8. CLEANING 8.1 Generality The grid's firebox and the fumes pipes of the generator must be periodically cleared from solid fuel residues (ash). The maintenance of fumes pipes cleared by ash guarantees draught efficiency and, therefore, greater yield of the heat generator. Tab. 8.2 lists the cleaning operations in chronological order. - Page 29 ASH COLLECTION DRAW OPERATION: removal of ashes from the side collection draw. PERIODICITY: visual check by lifting the seal lid, however no later than 2/3 days of continuous functioning. NOTES: open the two side hooks "A" and remove the draw from the handles, to disassemble. REFERENCE: fig.
-
Page 30: Table Of The Periodical Maintenance Operations
9. MAINTENANCE 9.1 Generality The heat generator must be submitted to regular maintenance to guarantee the efficiency of all components determining the correct operating of the generator and its main yield. Tab. 9.1 sum- marises the main operations. ATTENTION!! MAINTENANCE MUST ONLY BE CARRIED OUT BY QUALIFIED STAFF ATTENTION!! BEFORE MAINTENANCE, DISCONNECT THE ELECTRIC ENERGY... -
Page 31: Anomalies, Faults And Malfunctioning, Faq And Answers
10. ANOMALIES, FAULTS AND MALFUNCTIONING - FAQ AND ANSWERS ATTENTION!! BEFORE PERFORMING THE OPERATIONS DESCRIBED IN CHAP. 9, DISCON- NECT THE ELECTRIC ENERGY FROM THE GENERATOR BY INTERVENING ON THE MAIN SWITCH AND ENSURE THAT THE RESIDUE FUEL INSIDE THE FIREBOX IS OFF AND HAS COOLED DOWN 10.1 Anomalies and faults table. -
Page 32: Malfunctioning Table
10.2 Malfunctioning table. FAQ and answers. SIGN PROBABLE CAUSES SOLUTIONS Smoke flows back inside the a) check the flue's draught depression is that a) In which case, take technical precau- fuel hopper. requested in paragraph 6.5 tions from sector qualified staff. a) check balancing between fuel capacity and a) If phenomenon persists, call the tech- Incorrect combustion... - Page 33 NOTES...
- Page 34 The Harmonised Standards or technical specification (allocations) that have been applied in compli- ance with the "state-of-the-art", with regard to the safety of the products, in force in the EU, are: EN 60335.1 EN 6100-3-2 EN 55014.1 EN 50165 EN 6100-3-3 EN 55014.2 Miglianico lì------------------------ D'Alessandro Termomeccanica S.r.l.
- Page 35 B. PARTIAL SWITCHING OFF DECLARATION C.da Cerreto, 55 - 66010 MIGLIANICO (CH) – Italy Tel. (+39) 0871/950329 Fax (+39) 0871/950687 http://www.caldaiedalessandro.it e-mail: info@caldaiedalessandro.it D’ALESSANDRO TERMOMECCANICA S.r.l. declares that: the heat generators fed with non-powdered solid fuels with mechanical feeding manufac- tured by D’ALESSANDRO TERMOMECCANICA S.r.l.
