2. Line/MP3 Selector: Push down to use the USB/SD Bluetooth signal.
Push the selector up to use the Mic/Line input signal .
3. Signal Input Volume Knob: Adjusts the volume for MP3 or MIC/Line signal input.
4. Master Volume Knob: Adjusts all the output signal for the powered mixer.
5. Indicator: Displays the signal volume for output.
6. Phantom Power: Press this button to activate the 15V phantom power necessary
for a condenser (capacitance) Microphone which might require 15V power
supply from the mixer Channel 1-4 input.
7. 5 Band Graphic Equalizer: Adjusts the frequency of output signal.
8. Depth Knob: Adjusts the depth e ects level of 1-4 Channel for Microphone input.
9. ECHO Volume knob: Adjusts the ECHO Level for MIC input.
10. Peak Indicator: Signal display indicator for Channel 1-4, when input signal is
too high, the red light will be on.
11. Channel 1-4 XLR Connector: Connect Microphone and Line input, use the XLR
cables.
12. Mic / Line Input Selector Channel: When connecting a microphone set the
selector to MIC. When connecting a Line input set this selector to Line.
13. Treble Knob Channel: 1-4 have individual treble controls per channel. Use this
knob to adjust the treble levels for the selected channel.
14. Bass Knob: Channels 1-4 have individual bass controls per channel. Use this
knob to adjust the bass levels for the selected channel.
15. E ects Knob: Channels 1-4 have individual e ects controls per channel.
Use this knob to adjust the reverb e ect levels for the selected channel.
16. Volume Knob: Channels 1-4 have individual volume controls per channel.
Use this knob to adjust the volume levels for the selected channel.
17. 1/4" Line Input: Connect your sound source to this 1/4" input. The line volume
will be controlled channel 5/6 volume control and master volume Knob.
Only passive signals should be the connected input.
18. RCA Line Input: Connect your sound source to this RCA input(6/7 Channel).
Only passive signals should be the connected input.
19. RCA Line Output: Use this connector to connect other ampli er.
DO NOT connect directly to a passive speaker.
