Summary of Contents for SGM Pilot 3000
-
Page 2: Table Of Contents
SGM Technology for lighting Sommario .............................3 YMBOLS USED ........................3 HANGES TO THIS MANUAL ..........................4 AFETY NFORMATION ......................5 ENERAL ARRANTY ONDITIONS ........................6 NTRODUCTION ......................6 YSTEM HARACTERISTICS ........................6 AFETY INFORMATIONS ........................6 SING THE MANUAL ........................7 ARDWARE LAYOUT ..........................7 ERMINOLOGY ........................8 OWERING THE DESK ............................8... -
Page 3: Symbols Used
THIS SYMBOL INDICATES ELECTRIC SHOCK RISK Changes to this manual SGM has an on-going product development policy, so the information printed in this manual may not be completely up to date. If any doubts arise regarding the topics covered in this manual or should any further help be required, our... -
Page 4: Safety Information
UNIT NOT FOR HOME USE; ONLY FOR PROFESSIONAL USE • AFTER HAVING REMOVED THE PACKAGING, MAKE CERTAIN THE UNIT IS NOT DAMAGED IN ANY WAY. WHEN IN DOUBT, DO NOT USE THE UNIT, AND CONTACT AN AUTHORIZED SGM TECHNICAL ASSISTANCE CENTRE. •... -
Page 5: General Warranty Conditions
The validity of the guarantee is effective to all effects only on presentation of the guarantee to the manufacturer or the SGM technical assistance centre Always quote unit serial number and model when contacting the dealer for information or assistance Safeguard the environment: do not throw away the remaining packaging, but consign them to your dealer, or a special waste collection point. -
Page 6: Introduction
This manual explains operations for using the console with the software version shown on the frontispiece. SGM Elettronica reserves the right to make any variations without prior notice. To allow an easier consultation to the utmost according to needs, the manual is divided into various areas. -
Page 7: Hardware Layout
SGM Technology for lighting 1.4 Hardware layout The standard hardware features for Pilot3000 consists of: 2 DMX Universes allowing 1024 DMX ouput channels Midi IN OUT THRU DMX IN SMPTE IN 20 Playback Registers 6 Registers for Playback Control 4 encoders used for handling attributes and Speed... -
Page 8: Powering The Desk
URNING N THE ILOT Pilot3000 does not require any specific procedure to turn the power ON. To turn the Pilot 3000 ON or switch it OFF: Push the ON/OFF switch located onto the rear panel. - 8 - Pilot 3000... -
Page 9: Quick Start
Select Address Patch to enter the Console’s patching area. Select the Manufacturer brand name (e.g. SGM) which contains the fixture needed, the list of fixtures available will be displayed by the 2 left hand columns on the touch panel. The list can be vertically scrolled through the use of the encoder Wheel 1 named as “Brands Scroll”... -
Page 10: Programming A Cue
SGM Technology for lighting 2.2 Programming a Cue Make sure the Grand Master is positioned at 100%. Select the desired fixtures (e.g. the first 3) by pushing the related keys onto the touch panel. A bar inside the fixture key will shows the selection. When the bar is red coloured, then the fixture is selected. -
Page 11: Creating A Cue-List
SGM Technology for lighting 2.3 Creating a Cue-list Each Pilot3000 Register can control a maximum number of 999 Cues. That means a Register is handling the Cue- list. The Store Cue command saves the status of the Attributes into a Cue. -
Page 12: Cue-List Playback
SGM Technology for lighting 2.4 Cue-list Playback IMPORTANT !! Before running a Cue or Cue-list, make sure the “Live Editor” doesn’t still involve any fixtures. Push Clr all twice to close the Editor. Pushing the Register’s key, will automatically run the related Cue. -
Page 13: Ystem Rchitecture
SGM Technology for lighting YSTEM RCHITECTURE This chapter describes both Hardware and Software features of the Console. 2.5 External connections The first operations to be carried out during set-up are the external connections on the rear panel of the Console. - Page 14 SGM Technology for lighting Tool-bars. There are two tool-bars, at the top and bottom of the screen. Each contains 6 buttons, some of which have functions that vary according to the operating environment (Editor, Shape Engine, Playback). Selection and Operating window Is it located in the middle of the Touch-Screen.
-
Page 15: Lcd Dispaly
SGM Technology for lighting Parameters window. The lowest part of the Touch-Screen, is used to display the information regarding the Attributes assigned to 4 Encoder Wheels. Those information might be related either to the programming or times handling during the palyback mode. - Page 16 SGM Technology for lighting - 16 - Pilot 3000 User Manual V. 1.00...
