Summary of Contents for JOSEF DAVIDSSONS Viking 40
- Page 1 Viking 40 Installation and Maintenance Manual...
-
Page 2: Table Of Contents
Technical facts What is included in the range Wood burning range Viking 40 dimensions and installation About Viking 40 10 Here's how your Viking 40 works Installation and mounting Installation instructions for convection cabinets 12–14 Rear fire protection kit Interchangeable details... - Page 3 However, remember to read the installation and maintenance manual carefully before commencing assembly and before putting the range to use. Warm regards, Josef Davidssons...
-
Page 4: Technical Facts
Heating surface (approx. m²) up to 110 The manual contains instructions on how to mount and Weight (kg) install the Viking 40. To ensure the function and safety Size (HxWxD mm) 850–920x400x600 of the range, we recommend that installation be carried Hearth dimensions (HxWxD mm) 250x215x350 out by a professional. -
Page 5: What Is Included In The Range
§15a Reading and obeying the operating DIN+ instructions/ BimschV. 1+2 Läs och följ eldningsinstruktioner i manualen Josef Davidssons Eftr. AB Jättevägen 1 333 75 REFTELE Sweden 1. Installation manual 4. Wall lining (for back connection / side connection) Guide to installation and maintenance of your wood For installation instructions see page 11. -
Page 6: Wood Burning Range Viking 40
WOOD BURNING RANGE VIKING 40 DIMENSIONS AND INSTALLATION Here are the most important dimensions required for proper installation and optimal operation. All measurements are indicated in millimetres. VIKING 40 VIKING 40 Ø120 Ø120 Ø120 Ø120 Vy uppifr Front view Vy framifrån Vy från sidan... - Page 8 Installation distance The firewall at the back must extend at least 100 mm on with brick sides each side of the range. 100 mm 100 mm The stove is tested and approved with a 100 mm firewall, Please consider the safety installation distance. lightweight concrete or similar material for insulation.
- Page 9 Installation distance with convection sides The stove is approved with 55 mm convection sides. The convection sides are also available in 100 mm if you have a wider space to fill. NOTE! When using convection sides, a fire protection kit must be used in the back.
-
Page 10: About Viking 40
General on the hob and finally flows into the room. This allows Viking 40 is made in Austria with a tradition dating back the hot air to spread more easily around the room. to the 1930s. The range consists of high quality steel with cast iron doors. -
Page 11: Installation And Mounting
INSTALLATION AND MOUNTING The wood burning range meets the requirements for A flue with narrow bends and horizontal draught reduces connection to a chimney designed for 350°C smoke the draft in the chimney. The maximum horizontal flue is temperature. 500 mm, provided that the vertical flue length is at least 5 m. -
Page 12: Installation Instructions For
INSTALLATION INSTRUCTIONS FOR THE CONVECTION CABINET 50/100 50/100 Byggmått = 55mm Byggmått = 105 mm Byggmått = 55mm Byggmått = 105 mm 850-920 850-920 100-160* Above you will see the finished convection side Begin by opening the package and lifting the cabinet 100-160* assembled with dimensions. - Page 13 50/100 Max 15 mm Byggmått = 55mm Byggmått = 105 mm Detalj X Fit the base plate to the front panel of the convection Place the convection cabinet so that the spacer rests cabinet as shown in figure A. Then slide the front panel on the side plate.
-
Page 14: Rear Fire Protection Kit
Tighten the screws from no 3 when the cabinet is aligned Fit the outer plate and tighten it with the short screws. with the range. REAR FIRE PROTECTION KIT NOTE! Must be installed when using a convection cabinet due to the radiant heat on the sides. Take the fire protection kit and hang it on the back of the range with the hooks. -
Page 15: Interchangeable Details
INTERCHANGEABLE DETAILS – VIKING 40 The Viking 40 is built to be used for decades to come, but do not forget to replace wear details when needed. Keep an eye on fireproof bricks, grids and sealing strips and replace the parts when worn out. -
Page 16: Maintenance, Sweeping The Range
MAINTENANCE Steel hob The hob is face grinded and oiled on delivery to prevent The grid should be shaken and cleaned from ashes rusting. The oil evaporates at the first use and may regularly. smoke a bit. The heat will make the steel hob darken, and after a while it will obtain an evenly dark colour. -
Page 17: How To Use The Range Correctly
HOW TO USE THE RANGE CORRECTLY Adding firewood First fire When the intensity of the fire has decreased, it is time to A new wood burning range should be fired with care replenish. Open the door carefully. That way, you avoid during the first few occasions. -
Page 19: Problem Solving
FIRING PROBLEMS AND SOLUTIONS Poor draft • The connection to the chimney has not been properly sealed. Ask the sweeper to check that the connection between the range and the chimney is completely sealed. • The flue pipe is clogged. Clean the flue pipe and combustion chamber. •... -
Page 20: Warranty Certificate
WARRANTY TERMS Josef Davidssons Eftr AB is responsible for ensuring that the products are not defective in way that can be attributed to manufacturing or storage at the factory. The warranty is valid from the date of delivery to the customer. - Page 24 CUSTOMER SERVICE & CONTACT Our Customer Service offers you personal help and answers to your questions. Contact us by phone or email. Josef Davidssons, Jättevägen 1, 333 75 Reftele, SWEDEN Phone: +46 371 – 200 01 info@josefdavidssons.se josefdavidssons.se/en...
