Britax Verve User Manual page 2

1 Assembling and using your buggy
(this vehicle is intended for children from 6 months and up to 15kgs)
1a
Buggy shown in its fully closed position
(dia 1a).
1f
To open the hood, pull the front of
the hood forward then push the hood
hinges down on both sides (dia 1f).
2 Removing or re-fitting your seat unit
2a
B A
HANDY HINT – You may find it easier
to apply the brake before removing or
re-fitting the seat unit. To operate the
brake refer to (dia 1c).
A
Unfasten the press studs A on the
backrest and unfasten the hook and
loop fastenings on both sides of the
B
seat unit where it overlaps the hood B
(dia 2a).
3 Folding your buggy
3a
IMPORTANT - Always remove your
child from the buggy prior to installation,
removal or folding.
Press and hold the safety latch (at the
same time) pull up the release latches
(dia 3a).
1b
Hold the handle and lift upwards until
the chassis is fully extended ensuring
that it clicks in to position (dia 1b).
WARNING – Ensure that all locking
devices are engaged before use.
1g
B
A
To adjust your backrest, release the
backrest clip B from the backrest B
A
housing A to enable it to recline fully
(dia 1g).
IMPORTANT – Support the back of the
pushchair seat unit when adjusting the
angle.
2b
HANDY HINT – You may find it easier
to stand behind or to the side of the
buggy.
Remove the hood and bumper bar by
simultaneously pressing the buttons
on the mouldings on both sides of the
buggy and slide them upwards until they
disengage (dia 2b).
3b
Push the handle downwards until the
buggy folds in half (dia 3b).
1c
B
A
HANDY HINT - You may find it easier
to apply the brake when assembling the
buggy.
To operate the brake push the brake
lever down A . To unlock the brake, lift
the brake lever up B (dia 1c).
IMPORTANT – Always apply the
brakes when you park the buggy.
1h
C
C
B
A A
C C
Unfasten the comfort pad to reveal the
five-point harness. A five-point harness
is provided to restrain your child (dia 1h).
To secure the child in the harness, push
buckle A into buckle housing B until A B
the buckle prongs snap into position.
Carefully adjust the harness by pulling
C
the slider C until the desired fit is
achieved in the waist belt, shoulder and
crotch straps (dia 1h).
Always adjust the harness when
changing the seating position of the child.
To release the buckle, squeeze the top
A
and bottom prongs A .
WARNING – Always use the crotch strap
in combination with the waist belt.
WARNING – Fasten the harness when
not in use to prevent it becoming trapped
when folding the buggy.
2c
Unfasten the press studs and hook and
loop fastenings shown by the red circles
(dia 2c).
3c
Fully close and store in a safe, dry space
(dia 3c).
IMPORTANT - DO NOT fold and store
your buggy if it is damp. You must
ensure it is dry before folding and
storing.
1d
To attach the bumper bar, remove the
hood (if fitted). Align the bumper bar
mouldings with the fixings then slide
both bumper bar mouldings (dia 1d)
onto the buggy until fully engaged.
Check the bumper bar is securely
in place by carefully pulling on it. To
remove the bumper bar, remove the
hood (if fitted) then slide both bumper
bar mouldings off the buggy fixings by
simultaneously pressing the buttons
on the mouldings on both sides of the
buggy and slide them upwards until they
disengage.
WARNING! DO NOT lift the buggy
by the bumper bar or hood. It may
disengage.
1i
To lock the front swivel wheel, push the
front swivel lock from right to left (dia 1i).
To unlock push the front swivel lock from
left to right.
2d
Unclip the hooks on both sides of the
buggy (dia 2d).
1e
To fit the hood align with the fixings on
the bumper bar and slide down until
fully engaged (dia 1e).
The hood can be fitted without the
bumper bar by aligning the fixings on
the buggy and sliding down until fully
engaged.
To remove the hood, slide the hood
off the fixings on the buggy, or off the
fixings on the bumper bar (if fitted) by
simultaneously pressing the buttons
on the mouldings on both sides of the
buggy and slide them upwards until they
disengage.
2e
B
B
A
A
Remove the seat unit from the chassis
by sliding the base tabs A upwards A
and out of the grooves.
B
Then slide the top tabs B upwards and
out of the grooves until the seat unit is
disengaged (dia 2e).
To re-fit the seat unit reverse these
instructions.
