Omker OMK-K373 Instruction Manual

OMK-K373 Resistance Rebound Intelligent Built-in Controller for
INSTRUCTION MANUAL
As newly developed product, OMK-K373type resistance rebound intelligent built-in
controller for sliding door is controlled by microcomputer with reliable performance,
resistance rebound compared with other liking products, it covers the following
advantages：
1. Anti-collision design: when the door body travel is completed, only after press reverse
key, the motor can be activated so that the over-travel can be avoided.
2. Motor time protection: the default value is 90s, if want to change this value, you
may reset as follows(When setting this value,the RED DIP switch 3 should be turn on
to OFF (This is very important)): Turn on Red DIP switch 6 to ON, press function key F
more than 5s,power indicator light will be off,after a sound of the controller,release function
key F, the door will automatically open to the limit and stop,then perform close
action,closing to close limit and then stop,complete setting of motor time protection.
After setting,you should turn on Red DIP switch 6 back to off. Noted: when setting travel
protection time,travel open and close limit should be installed and run normally. (Press
function key F more than 5s,if power indicator light do not turn off,you should cut off power
for 5s, and then connect power, entering this function).
3. Auto Close Function: If you need auto close when external card reader or other auto
release system is added, you should turn on RED DIP switch 3 (Auto close) to ON,star auto
close function.Then turn on RED DIP switch 6 (set) to ON, each time you press F,you will
hear a sound.How much time you want for the auto close how many times you press F.After
setting,you should turn on RED DIP switch 6 back to off,and will hear a sound. Auto close
time setting is finished. When door reach to the open limit, stop indicator light of the
controller will flash and timing ,when reach the setting time,the door will auto closed to
realize remote control function.(Noted setting of auto close function: you should reconnect
the power, otherwise it will have no reaction). It's strongly recommended to add infrared
protection, especially when performing auto close function to avoid unnecessary loss.
4. Single key remote control and three key remote control interchange: This function
can be set by RED
DIP switch 1. Turn on RED DIP switch 1 (single key remote control )to off, remote
control perform in this way: OPEN-STOP-CLOSE-LOCK four keys controlled
independently.Turn on RED DIP switch 1 to ON, remote control perform single key cycle
operation, i.e.coded with which key,that is the key perform cycle operation.
For example:use OPEN key to coded
Press OPEN key=door open
Press OPEN key again =door stop
Sliding Door
Read carefully
1
