Page 1 (WLAN) solution is designed for both home and business use. Additional users and features can be added as your networking needs grow and change. Your Intel(R) Wireless WiFi Link 4965AGN adapter is compatible with 802.11a, 802.11b 802.11g and 802.11n wireless standards. Operating at 5 GHz or 2.4 GHz...
Page 2 In many instances Intel is required to provide test data to prove regional and local compliance to regional and governmental regulations before certification or approval to use the product is granted.
Page 3 Intel), (i) you will be solely responsible for ensuring the regulatory compliance of the products, (ii) Intel will bear no liability, under any theory of liability for any issues associated with the modified products,...
Page 4 Use Intel PROSet/Wireless as your Wireless Manager Intel(R) PROSet/Wireless is used to setup, edit and manage network profiles to connect to a network. It also includes advanced settings such as power management and channel selection for setting up ad-hoc networks.
Page 5 Taskbar icon and click Open Intel PROSet/Wireless. Taskbar Menu Options The Intel PROSet/Wireless icon displays on the Taskbar located in the lower right corner of your Windows desktop. Right- click the status icon to display the menu options.
Page 6: Taskbar Icons
No wireless networks found: There are no available wireless networks found. Intel PROSet/Wireless periodically scans for available networks. If you want to force a scan, double-click the icon to launch Intel PROSet/ Wireless and click Refresh. The icon is red.
Page 7 Once connected, the alert displays the wireless network that you are connected to, the speed of the connection, signal quality and IP address. Desktop alerts are also used to indicate if there is a connection problem. Click the alert to open the Intel Wireless Troubleshooter. Intel PROSet/Wireless Main Window The Intel PROSet/Wireless Main Window allows you to:...
Page 8 Connection Status Icons The connection status icons indicate the current connection status of your wireless adapter. The connection status icon displays in the Intel PROSet/Wireless main window. The Taskbar icon also indicates the current connection status. See Taskbar Icons for more information.
Page 9 Turn Wireless On or Off for more information. Help? Provides help information for this page. Close Closes the Intel PROSet/Wireless main window. Wireless Networks List The Wireless Networks list displays a list of wireless networks within range of the adapter. Name Description The signal strength of the wireless network access point or computer (Device to Device [ad hoc] mode).
Page 10: Network Properties
Provides help information for this page. Network Properties Click the Properties button on the Intel PROSet/Wireless main window to display the security settings for the wireless adapter. You can also add profiles to be excluded from automatic connection. If network exclusion is enabled (see Application Settings) then the Network Properties also indicates if the network is excluded from automatic connection.
Page 11 Manage Exclusions for more information. Close Closes the Network Properties. Help? Provides help information for this page. Connection Details When you are connected to a network, click the Details button on the Intel(R) PROSet/Wireless main window to display the Connection Details.
Page 12 Connection Details Description Name Description Profile Name Name of the profile. Network Name Network Name (SSID) of the current connection. IPv4 Address Internet Protocol (IP) address for the current connection. Signal Quality A radio frequency (RF) signal can be assessed by two components: signal strength (quantity) signal quality The quality of the signal is determined by a combination of factors.
Page 13 Profile Management On the Intel PROSet/Wireless main window, click Connect on a wireless network. Once connected, a profile is created in the Profiles list. The Profiles List displays the current user profiles in the order that they are to be applied. Use the up and down arrows to arrange profiles in a specific order to automatically connect to a wireless network.
Page 14 Close Closes the profile management window. Help? Provides help information for this page. Menus Use the File, Tools, Advanced, Profiles and Help menus to configure your network settings. Name Description File Exit: Close the Intel PROSet/Wireless main window.
Page 15 See Administrator Tool for more information. NOTE: The Administrator Tool is available only if it installed during a custom installation of the Intel PROSet/Wireless software. See Install or Uninstall the Software for more information on custom installation.
Page 16 Lists the network adapter that are currently available. It may be either an Intel(R) PRO/Wireless 2915ABG Network Connection or an Intel(R) PRO/Wireless 2200BG Network Connection. Advanced Settings: The following settings control how Intel PROSet/Wireless behaves and displays information. Taskbar Show application icon on the taskbar: Select to display the Taskbar status icon.
Page 17 This is helpful if you use software provided by a hotspot location (coffee shop, airport terminal). To take advantage of the Intel PROSet/Wireless features, disable this software when you leave the hotspot. Enable TLS rejected certificates notification: Select if you want a warning issued when a PEAP-TLS certificate is rejected by the authentication server.
Page 18 Select to receive an alert when connected to a network with the default network name. Save settings and return to the previous page. Cancel Closes and cancels changes. Help? Provides help information for this page. Intel Wireless Troubleshooter (Tools menu)
Page 19 Wireless Troubleshooter is supported under Windows XP and Windows 2000 The Intel Wireless Troubleshooter page contains two panes. Use your left mouse button on the left pane to display a list of available tools. The right pane displays the current connection issue in a section. Each section has two parts: the error message and the recommended action.
Page 20 An administrator can select which level of control that users have over their wireless network connections. See Administrator Tool Adapter Settings. Software Select which of the Intel PROSet/Wireless applications are installed on a user's computers. Administrator Tool Software. EAP-FAST A-ID Groups An administrator can select which Authority Identifier (A-ID) radius server to provision Protected Access Credentials (PACs) for profiles that use EAP-FAST authentication.
Page 21 Set high throughput channel width to maximize performance. Set the channel width to Auto or 20Mhz. Auto is the default setting. Use 20MHz if 802.11n channels are restricted. NOTE: This setting is available only if the adapter is an Intel(R) Wireless WiFi Link 4965AGN or Intel(R) Wireless WiFi Link 4965AG_. 802.11n Mode The 802.11n standard builds upon previous 802.11x standards by adding multiple-...
Page 22 Maximum Power Savings: Select to optimize battery life. Noisy Environment: Select to optimize performance or connecting with multiple clients. NOTE: This setting is unavailable if the adapter is an Intel PRO/Wireless 2915ABG Network Connection, or an Intel PRO/Wireless 2200BG Network Connection. Ad Hoc QoS Mode Quality of Service (QoS) control in ad hoc networks.
Page 23 802.11n 802.11g 802.11a 802.11b NOTE: This setting is unavailable if the adapter is an Intel PRO/Wireless 3945ABG Network Connection or Intel PRO/Wireless 2200BG Network Connection. Roaming Aggressiveness This setting allows you to define how aggressively your wireless client roams to improve connection to an access point.
Page 24 Advanced Statistics (Advanced menu) The Advanced Statistics provides current adapter connection information. Advanced Statistics Description Name Description Statistics Advanced Statistics: This information pertains to how the adapter communicates with an access point. Association: If the adapter finds an access point to communicate with, the value is within range.
Page 25 To change the storage location of the log file. 1. Click Browse to specify a new log file location. The current path is displayed. The default location is in the Intel PROSet/Wireless Program Files directory. 2. Click Open to close and apply the new file path.
Page 26 The Microsoft Windows XP Wireless Zero Configuration feature provides a built-in wireless configuration utility. This feature can be enabled and disabled within Intel PROSet/Wireless. Click Use Windows to manage Wi-Fi on the Advanced menu or the Taskbar menu. If Windows XP Wireless Zero Configuration is enabled, the features in Intel(R) PROSet/Wireless are disabled.
Page 27 To switch the wireless radio on or off, use one of the following: The optional hardware radio switch on your computer Intel PROSet/Wireless software Microsoft Windows NOTE: When your computer is switched on, the radio is constantly transmitting signals. In certain situations, as in an airplane, signals from the radio may cause interference.
Page 28 Taskbar. Use Intel PROSet/Wireless to Switch the Radio On or Off From Intel PROSet/Wireless, the radio can be switched on or off. The status icon on Intel PROSet/Wireless displays the current state of the radio.
Page 29 NOTE: If you plan to use Novell(R) Client(TM) for Windows, it should be installed prior to installation of the Intel PROSet/Wireless software. If Intel PROSet/Wireless is already installed, you should remove it prior to installation of Novell Client for Windows.
Page 30 Administrator Toolkit. 6. Click Install this feature and any selected subfeatures. 7. Click Modify. After installation, the feature is listed as Installed on the Intel PROSet/Wireless Installer feature list.
Page 31 Back to Top Back to Contents Trademarks and Disclaimers...
Page 32: Connect To A Wireless Network
Wireless networks found. See Taskbar Icons for more information. 1. Double-click the desktop alert to open the Intel PROSet/Wireless main window. 2. Select a network from the wireless networks list. 3. Click Connect. If the network does not require security authentication, a desktop alert notifies you that you are connected to the network.
Page 33 If you ignore the Wireless networks found desktop alert, Intel PROSet/Wireless displays a message that prompts: Do you want to connect to a wireless network? Click Yes. The Intel PROSet/Wireless main window opens. Follow the instructions above to connect to a wireless network.
Page 34 Wireless to manage Wi-Fi from the Taskbar menu. From Intel PROSet/Wireless: From the Advanced menu, click Use Windows to manage Wi-Fi in the Intel PROSet/ Wireless application. When you are finished using the Microsoft Windows XP Wireless Zero Configuration, you can switch back to Intel PROSet/Wireless. Click Enable Intel PROSet/Wireless on the Intel PROSet/Wireless main window or click Use Intel PROSet/Wireless to manage Wi-Fi from the Taskbar menu.
Page 35 Third Party Wireless Software If you use software provided by a hotspot location (coffee shop, airport terminal), Intel PROSet/Wireless notifies you and then disables itself. It cannot manage the wireless device when another wireless manager communicates with the wireless device. To take advantage of the Intel PROSet/Wireless features, you want to disable or remove this software when you leave the hotspot.
Page 36 Back to Top Back to Contents Trademarks and Disclaimers...
Page 37 Profiles List The profile list displays a list of existing profiles. When you come within range of a wireless network, Intel PROSet/Wireless scans the Profile List to see if there is a match. If a match is found, you are automatically...
Page 38 Profile List Priority Arrows Use the up-arrow to move the position of a selected profile up in the profiles list. Use the down-arrow to move the position of a selected profile down in the profiles list. Profiles List Icons The network profile status icons indicate whether the adapter is associated with a network, the type of operating mode being used, and whether security encryption is enabled.
Page 39: Create A New Profile
If a network with a lower priority profile is also in range you can force the connection to that lower profile. This is achieved from Intel PROSet/Wireless or from the Taskbar icon. Manually connect to a profile from Intel PROSet/Wireless: 1.
Page 40 To create a new profile and connect to a wireless network: 1. From the Intel PROSet/Wireless main window, click Profiles. 2. On the Profiles list, click Add to open the Create Wireless Profile General Settings.
Page 41 Profile Name Name of the wireless network profile. When you configure a wireless network that was selected from the Wireless Networks list, the profile name is the same as the Wireless Network Name (SSID). This name can be changed to be more descriptive or customized for your personal use.
Page 42 Name Description Auto Connect Automatic (Default): Select to have Intel PROSet/Wireless connect automatically to this profile when it is in range. On Demand: Select to prevent automatic connection of a profile when the network is in range. For example, if there is a cost for a wireless connection and you did not want to connect automatically when in range.
Page 43 Allows a network administrator to easily move the selected profile to other computers. When the exported file is placed in the Wireless\AutoImport directory on another computer, Intel PROSet/Wireless automatically imports the profile. NOTE: Auto Import is unavailable in the Advanced Settings when Administrator Profiles are configured.
Page 44 8. Select either Personal Enterprise Security to select the Network Authentication and Data Encryption options. Enter the encryption key settings and configure the 802.1x settings as required.
Page 45: Edit An Existing Profile
9. Click OK when you have completed the profile settings. To change or verify the profile settings, click Back. 10. If you are not currently connected to a network, Intel PROSet/Wireless detects that a new profile has been added and automatically attempts to connect to this new profile.
Page 46: Remove A Profile
8. Confirm Password: Reenter the password. 9. Click OK to save the setting and return to the General Settings page. 10. Click OK to return to the Intel PROSet/Wireless main window. Export or Import Profiles Allows you to export and import user-based profiles to and from the Profiles list. Wireless profiles can be automatically imported into the Profiles list.
Page 47 Export Profiles from the Profiles List 1. Select individual or multiple profiles from the list. 2. Select Export to export one or more profiles from the Profiles list. 3. Select the destination folder. Click Browse to search your hard disk for the destination directory. The C:\ drive is the default directory.
Page 48 4. You are notified that the profile has been successfully imported. An administrator can set profiles to be imported automatically into the Profiles list. Intel PROSet/Wireless monitors the import folder on your hard disk for new profile files. Only profiles that have been enabled...
Page 49 Set up a Client with LEAP Network Authentication Set up a Client with EAP-FAST Network Authentication Use Intel(R) PROSet/Wireless Software The following sections describe how to use Intel(R) PROSet/Wireless to set up the required security settings for your wireless adapter. See Personal Security.
Page 50 Use Personal Security if you are a home or small business user who can use a variety of simple security procedures to protect your wireless connection. Select from the list of security settings that do not require extensive infrastructure setup for your wireless network. A RADIUS server is not required.
Page 51 Security Settings If you are configuring a Device to Device (ad hoc) profile, select one of the following data encryption settings: None: No authentication required. WEP-64 bit WEP-128 bit: A network key or password is used for encryption. If you are configuring a Network (Infrastructure) profile, select: WPA-Personal (TKIP) WPA2-Personal (TKIP): WPA-Personal utilizes the...
Page 52 You can use ad hoc mode to network multiple computers in a home or small office, or to set up a temporary wireless network for a meeting. On the Intel(R) PROSet/Wireless main window, select one of the following methods to connect to a device to device network: Double-click an ad hoc network in the Wireless Networks list.
Page 53: Security Settings
To add a network key to a device to device network connection: 1. On the Intel PROSet/Wireless main window, double-click a Device to Device (ad hoc) network in the Wireless Networks list or select the network and click Connect. When connected, a profile is added to the Profiles list.
Page 54 To configure a profile with WPA-Personal network authentication and TKIP data encryption: 1. On the Intel PROSet/Wireless main window, double-click an Infrastructure network in the Wireless Networks list or select the network and click Connect. 2. Click Profiles to access the Profiles list.
Page 55 Set Password: 1. Wireless Security Password (Encryption Key): Enter a text phrase (length is between eight and 63 characters). Verify that the network key used matches the wireless access point key. 2. Click OK to return to the Profiles list. Back to Top Back to Contents Enterprise Security...
Page 56 Windows user name and password. Before connection, you are prompted for your Windows logon credentials. NOTE: This option is unavailable if Pre-logon/Common Connect is not selected during installation of the Intel PROSet/Wireless software. See Install or Uninstall the Single Sign On Feature.
Page 57 Use the following: Use your saved credentials to log onto the network. User Name: This user name must match the user name that is set in the authentication server by the administrator prior to client authentication. The user name is case- sensitive.
Page 58 Use a user certificate on this computer: Click Select to choose a certificate that resides on this computer. NOTE: Intel PROSet/Wireless supports machine certificates. However, they are not displayed in the certificate listings. Notes about Certificates: The specified identity should match...
Page 59 TLS authentication or consult your administrator. 3. Click Profiles on the Intel PROSet/Wireless main window. 4. On the Profile page, click Add to open the Create Wireless Profile General Settings. 5. Profile Name: Enter a descriptive profile name. 6. Wireless Network Name (SSID): Enter the network identifier.
Page 60 2. On the Profile page, click Add to open the Create Wireless Profile General Settings. 3. Profile Name: Enter a descriptive profile name. 4. Wireless Network Name (SSID): Type the network identifier. 5. Operating Mode: Click Network (Infrastructure). 6. Click Next to access the Security Settings. 7.
Page 61 4. Click Connect to connect to the selected wireless network. 5. Click OK to close Intel PROSet/Wireless. Set up a Client with TTLS Network Authentication TTLS authentication: These settings define the protocol and credentials used to authenticate a user. The client uses EAP-TLS to validate the server and create a TLS-encrypted channel between the client and server.
Page 62 When 802.1x Microsoft IAS RADIUS is used as an authentication server, the server authenticates the device using the Roaming Identity from Intel PROSet/Wireless software, and ignores the Authentication Protocol MS-CHAP-V2 user name. Microsoft IAS RADIUS accepts only a valid user name (dotNet user) for the Roaming Identity.
Page 63 When 802.1x Microsoft IAS RADIUS is used as an authentication server, the server authenticates the device using the Roaming Identity from Intel PROSet/Wireless software, and ignores the Authentication Protocol MS-CHAP-V2 user name. Microsoft IAS RADIUS accepts only a valid user name (dotNet user) for the Roaming Identity.
Page 64 Generic Token Card (GTC) To configure a one-time password: 1. Authentication Protocol: Select GTC (Generic Token Card). 2. User Credentials: Select Prompt each time I connect. 3. On connection prompt for: Select one of the following: Name Description Static Password On connection, enter the user credentials.
Page 65 MS-CHAP-V2 This parameter specifies the authentication protocol operating over the PEAP tunnel. 1. User Credentials: Select one of the following options: Use Windows logon, Prompt each time I connect, Use the following. 2. Click Next to open the PEAP Server settings. Transport Layer Security authentication is a two-way authentication method that exclusively uses digital certificates to verify the identity of a client and a server.
Page 66 In the Application Settings, select Intel(R) PROSet/Wireless TLS Certificate Rejected Warning, if you want a warning issued when a PEAP-TLS certificate is rejected. When a certificate has an invalid field expiration date, you are notified that you must take one of the following actions: A potential authentication problem for profile <profile name has been detected.
Page 67 RADIUS server. The LEAP profiles settings include LEAP, CKIP with Rogue AP detection integration. To set up a client with LEAP Authentication: 1. Click Profiles on the Intel PROSet/Wireless main window. 2. On the Profile page, click Add. The Create Wireless Profile General Settings opens.
Page 68 14. Click Enable Radio Management Support. Use Radio Management to detect rogue access points. 15. Click OK to return to the Security Settings. LEAP User...
Page 69 1. Select one of the following authentication methods: Use Windows logon user name and password, Prompt for the user name and password, or Use the following user name and password. 2. Click OK to save the setting and close the page. Cisco Compatible Extensions Options Cisco Options: Use to enable or disable Radio Management and Mixed Cells Mode or Allow Fast Roaming (CCKM).
Page 70 Cisco Compatible Extensions, Version 3 (CCXv3) To set up a client with EAP-FAST authentication with Cisco Compatible Extensions, version 3 (CCXv3): 1. Click Profiles on the Intel PROSet/Wireless main window. 2. On the Profile page, click Add to open the Create Wireless Profile General Settings.
Page 71 2. Click Select server to view any unauthenticated PACs that have already been provisioned and reside on this computer. NOTE: If the provisioned PAC is valid, Intel(R) PROSet/Wireless does not prompt the user for acceptance of the PAC. If the PAC is invalid, Intel PROSet/Wireless fails the provisioning automatically.
Page 72 To set up a client with EAP-FAST authentication with Cisco Compatible Extensions, version 4 (CCXv4): 1. Click Profiles on the Intel PROSet/Wireless main window. 2. On the Profile page, click Add to open the Create Wireless Profile Wizard's General Settings.
Page 73 NOTE: If the provisioned Protected Access Credential (PAC) is valid, Intel(R) PROSet/Wireless does not prompt the user for acceptance of the PAC. If the PAC is invalid, Intel PROSet/Wireless fails the provisioning automatically. A status message is displayed in the Wireless Event Viewer that an administrator can review on the user's computer.
Page 74 When 802.1x Microsoft IAS RADIUS is used as an authentication server, the server authenticates the device using the Roaming Identity from Intel PROSet/Wireless software, and ignores the Authentication Protocol MS-CHAP-V2 user name. Microsoft IAS RADIUS accepts only a valid user name (dotNet user) for the Roaming Identity.
Page 75 NOTE: If the provisioned Protected Access Credential (PAC) is valid, Intel(R) PROSet/Wireless does not prompt the user for acceptance of the PAC. If the PAC is invalid, Intel PROSet/Wireless fails the provisioning automatically. A status message is displayed in the...
Page 76 PAC distribution can also be completed manually (out-of-band). Manual provisioning enables you to create a PAC for a user on an ACS server and then import it into a user's computer. A PAC file can be protected with a password, which the user needs to enter during a PAC import. To import a PAC: 1.
Page 77: Troubleshooting
Intel Wireless Troubleshooter Description The Intel Wireless Troubleshooter contains two panes. The left pane displays a list of available tools. The right pane displays the current connection issue. This pane is divided into two sections: the error message and the recommended...
Page 78 Disable Notification/Enable Notification: Select to disable or enable alert notifications. Exit: Click to exit the Intel Wireless Troubleshooter application. View History: Displays or removes the History data on the right panel of the Intel Wireless Troubleshooter. Tools Manual Diagnostics Tool: Run diagnostic test to verify the functionality of your wireless adapter.
Page 79 The test verifies if the driver binary version is compatible with the installed version of Intel PROSet/Wireless software. The test fails if the driver binary is not found or if the driver version does not match the Intel PROSet/Wireless software version (for example, Intel PROSet/Wireless version 10.0.5 and driver version 9.0.3.9).
Page 80 The Test Summary displays whether authentication is required for the network connection. Troubleshooting Select Intel(R) Wireless Troubleshooter from the Tools menu on the Intel PROSet/ Wireless main window. Select Wireless Event Viewer to display error log records to resolve problems found with this test.
Page 81 The Wireless Event Viewer program displays a list of error log records. You can save all available log records to a binary format file for sending to customer support. To launch Wireless Event Viewer, select Intel Wireless Troubleshooter on the Tools menu. Click Wireless Event Viewer.
Page 82 Saves the available log. Use the suggested name or change it. Resolve Errors Use the following recommendations to resolve network connection issues detected by Intel Wireless Troubleshooter. Did not receive an IP address The ad hoc network is idle and no peers have joined the network The ad hoc network is idle and all peers have left the network You are connected to a network with default network name (SSID).
Page 83 3. Clear Notify when no peers have joined the ad hoc network. 4. Click OK to save your settings and return to the Intel PROSet/Wireless main window. The ad hoc network is idle and all peers have left the network If you create or join an ad hoc network with other participants, this alert will notify you when any or all participants have left the ad hoc network.
Page 84 2. Scroll down to locate SSID Notification. 3. Clear Notify when connected to a network with the default SSID name. 4. Click OK to save your settings and return to the Intel PROSet/Wireless main window. You are connected to a network that is not configured with security and there are shared folders detected in your system File and printer sharing enables other computers on a network to access resources on your computer.
Page 85 No wireless network adapter was detected in the system The system could not detect an Intel wireless adapter in the system. The adapter may be removed or not installed. First verify if there is a wireless adapter listed in the Device Manager: 1.
Page 86 The application that you specified to start when this profile connected, could not be found. Verify the path and file name in the Profile Manager Advanced Settings. To verify the path and file name: 1. From the Intel PROSet/Wireless main window, click Profiles. 2. Select the Profile. 3. Click Properties.
Page 87 Authentication failed due to an invalid user certificate: Select another certificate This authentication error can be caused by invalid server (domain) credentials. Use the following steps to resolve this error: 1. Select the appropriate profile from the Profiles list. 2. Click Properties to open the General Settings. 3.
Page 88 If Use Windows logon or Prompt each time I connect is selected, verify that the correct domain credentials information is used when you connect to the wireless network. NOTE: This option is only available if you have the Single Sign On Pre-logon/Common Connect component installed. For LEAP profiles: Select Use the following user name and password and verify the domain is correct.
Page 89 7. Verify that the correct authentication type is selected. 8. Enter the required security information. 9. Click OK. The profile is now reapplied. Intel PROSet/Wireless attempts to connect to the wireless network. Incorrect PIN for retrieving certificate: Reenter PIN The certificate retrieval failed because of an incorrect PIN.
Page 90 An administrator profile failed to authenticate This error occurs when the credentials in the profile are not accepted by the authenticator (for example, an access point or AAA server). Please contact your Administrator to resolve this problem. Administrator profile did not receive an IP address The wireless adapter failed to get a valid IP address.
Page 91 The Administrator Tool is located on the Intel PROSet/Wireless Tools menu. It must be selected during a Custom installation of the Intel PROSet/Wireless software or the feature is not displayed in the Tools menu.
Page 92 NOTE: If you do not know the original password, there is no process available to reset the password. 1. Password: Create a password (maximum 100 characters). 2. Confirm Password: Reenter the password. 3. Click OK. The Open Administrator Package displays. To change the existing password: 1.
Page 93 Administrator Tool's Profiles list. Select Insert on bottom to always place Administrator profiles at the bottom the Administrator Tool's Profiles list. 3. Click OK to close and return to the Administrator Tool. Administrator Packages Administrator Packages are used to save administrative profiles and other settings. You can copy or send this self-extracting executable file to clients on your network.
Page 94 Create a Windows Vista Create a package that can be exported to a package user's computer that has the Windows Vista operating system. This package allows export of EAP-TTLS and EAP-SIM Common profiles only. Open an existing package Select to browse for and open an existing package.
Page 95 To edit a package: 1. Access the Administrator Tool. 2. On the Open Administrator Package page, click Open an existing package to edit an existing package. 3. Click Browse. Locate the package's executable file. 4. Click Open. Make your updates. 5.
Page 96 Persistent Connection Persistent profiles are applied at boot time or whenever no one is logged on the computer. After a user logs off, a Persistent profile maintains a wireless connection either until the computer is turned off or a different user logs on. Persistent Connect key points: The following types of profiles can be created as Persistent profiles: All profiles that do not require 802.1x authentication (for example, Open...
Page 97 Pre-logon/Common profiles always appear at the top of a the Profiles list. Users can still prioritize profiles that they have created but they cannot reprioritize Pre-logon/Common profiles. Because these profiles appear at the top of the profiles list, Intel PROSet/Wireless automatically attempts to connect to the Administrator profiles first before any user created profiles.
Page 98 All non-802.1x (Open and WEP) Common or User Based profiles. A Pre-logon/Common profile is applied at Windows user log-on time. Pre-Logon/Common Connection Status Pre-logon/Common Connect support is installed during a Custom install of the Intel PROSet/ Wireless software. See Install and Uninstall the Single Sign On Feature for more information.
Page 99 DOMAIN\user NOTE: User Name Format is available only in the Advanced Settings in the Administrator Tool. It is unavailable when creating a user profile from the Intel PROSet/Wireless Create Wireless Profile manager. 10. Click OK to close the Advanced Settings.
Page 100 To create a Common Profile: 1. Click Include Profiles in this package (default). 2. Click Common. 3. Click Add to open the General Settings. 4. Profile Name: Enter a descriptive profile name. 5. Wireless Network Name (SSID): Enter the network identifier. 6.
Page 101 Administrators can designate networks to be excluded from connection. Once a network is excluded, only an administrator can remove the network from the Exclude list. The excluded network is displayed in the Intel PROSet/Wireless Exclude List Management. NOTE: Unavailable for Windows Vista packages.
Page 102 1. Select the network name in the Exclude list. 2. Click Remove. The network is deleted from the list. Voice over IP (VoIP) Connection Intel PROSet/Wireless software supports VoIP third-party soft-phone applications. Third-party VoIP applications support Voice Codecs. Codecs generally provide a compression capability to save network bandwidth.
Page 103 Intel PROSet/Wireless software supports the following International Telecommunications Union (ITU) codec standards: Codec Algorithm ITU G.711 PCM (Pulse Code Modulation) ITU G.722 SBADPCM (Sub-Band Adaptive Differential Pulse Code Modulation) ITU G.723 Multi-rate Coder ITU G.726 ADPCM (Adaptive Differential Pulse Code Modulation) ITU G.727...
Page 104: Application Settings
G711_64kbps Interactive Voice G722_64kbps Audio Conference G722_56kbps Voice Data G722_48kbps Video G722_1_32kbps Streaming Audio G722_1_24kbps G722_1_16kbps G726_16kbps G726_24kbps G726_32kbps G726_40kbps G728_16kbps G729a_8kbps G729e_11_8kbps GIPS_iPCM_VARIABLE G722_2_VARIABLE 5. Click OK to return to the Profiles list. 6. Click Close to save the profile settings to a package. Application Settings An administrator can select which level of control that users have over their wireless network connections.
Page 105 Application On Radio Enables a third-party application to Toggle disable the Intel PROSet/Wireless Wireless On or Wireless Off switch. CCXv4 Select Enable CCXx4 to Enable Cisco Compatible Extensions, version 4 (CCXv4) features for EAP-FAST profiles.
Page 106 Intel (R) PRO/Wireless 2915ABG Network Connection or an Intel(R) PRO/ Wireless 2200BG Network Connection. Cache Credentials Select to save credentials after a user logs on. If the wireless connection temporarily disconnects, the saved credentials are used upon reconnection.
Page 107 Logoff on Connect. Message On Radio Enables a third-party application to Toggle notify a user that the Intel PROSet/ Wireless Wireless On or Wireless Off switch is disabled. Microsoft Windows Select Enable Microsoft Wireless...
Page 108 Connection may take longer to connect. Profile Connectivity Select the profile connectivity level on a user’s computer. Disable Intel user-profile switching. Users are only able to connect with the first Pre-logon/ Common profile or connect with Pre- logon/Common profiles only.
Page 109 They cannot be changed or deleted by a user. Support Information Specify the support information displayed in the About box of the Intel PROSet/Wireless Software. Support URL: Enter the support center web site that you want your customers to access for technical support.
Page 110 VoIP application on a user's computer. The default setting enables this feature. NOTE: This feature is not installed through an Administrator Package when a user's computer has an Intel PRO/Wireless 2200BG Network Connection. Wi-Fi Manager Select which Wi-Fi manager controls a user’s wireless connections.
Page 111 Wireless On/Off Select Disable Wireless On/Off selection to prevent a user from accessing the Wireless On or Wireless Off control on the Intel PROSet/Wireless main window or Taskbar menu. A user is notified that The feature is disabled by the administrator if they attempt to turn on or off the radio control.
Page 112: Adapter Settings
No change: Maintains the user selected value. The administrator decides not to enforce all the settings on a user's computer. The user can change the adapter setting values from the Intel PROSet/Wireless Advanced menu. Select the value: The administrator selects the value that is to be used on the user's computer.
Page 113 Set high throughput channel width to maximize performance. Set the channel width to Auto or 20Mhz. Auto is the default setting. NOTE: This setting is available only if the adapter is an Intel (R) Wireless WiFi Link 4965AGN or Intel(R) Wireless WiFi Link 4965AG_.
Page 114 Wi-Fi networks. WMM Enabled (default) WMM Disabled NOTE: This feature is not installed through an Administrator Package when a user's computer has an Intel PRO/Wireless 2915ABG Network Connection or an Intel PRO/Wireless 2200BG Network Connection. Mixed Mode Protection Use to avoid data collisions in a mixed 802.11b and 802.11g...
Page 115 Roaming Aggressiveness Define how aggressively a wireless client roams to improve connection to an access point. Click Use default value to balance between not roaming and performance or select a value from the list. Values: 0: No Roaming: Your wireless client does not roam.
Page 116 Help? Provides help information for this page. Software Select which Intel PROSet/Wireless software components are installed on a user's computer. 1. Select Include Software in this package. 2. Place the Intel PROSet/Wireless installation CD in the CD drive. 3. Specify the Intel PROSet/Wireless Software Installation directory: Click Browse to locate the Autorun.exe file.
Page 117 Windows Vista packages. To reduce the size of the software files in your Administrator Package: 1. Copy the installation folders from your Intel PROSet/Wireless software to a local directory. 2. Remove unused language folders from the \IA32\Docs\ and the \IA32\IProLang folders.
Page 118 NOTE: This feature is unavailable if CCXv4 is not selected in the Administrator Tool Application Settings An Authority Identifier (A-ID) is the radius server that provisions Protected Access Credential (PACs) A-ID groups. A-ID groups are shared by all users of the computer and allow EAP-FAST profiles to support multiple PACs from multiple A-IDs.
Page 119 Notes about Smart Cards After a Smart Card is installed, the certificate is automatically installed on your computer and is chosen from the personal certificate store and root certificate store. Set up a Client with TLS Network Authentication Step 1: Obtain a certificate To allow TLS authentication, you need a valid client certificate in the local repository for the logged-in user's account.
Page 120 10. Click Next. 11. Click Finish. 12. Click Close. 13. Click OK. 14. In the console, click Certificates (Local Computer). 15. Click Trusted Root Certificate Authorities. 16. Click Certificates. 17. Verify that the CA you just installed is listed. 18. Click File. 19.
Page 121 NOTE: Obtain and install a client certificate, See Step 1 or consult your administrator. Specify the certificate used by Intel PROSet/Wireless 1. On the Profile page, click Add to open General Settings. 2. Profile Name: Enter a profile name.
Page 122: Glossary Of Terms
Back to Contents Glossary of Terms Numerical Term Definition 802.11 The 802.11 standard refers to a family of specifications developed by the IEEE for wireless LAN technology. The 802.11 specifies an over-the-air interface between a wireless client and a base station or between two wireless clients and provides 1 or 2 Mbps transmission in the 2.4 GHz band using either frequency hopping spread spectrum (FHSS) or direct sequence spread spectrum...
Page 123 Access Point A device that connects wireless devices to another network. For (AP) example, a wireless LAN, Internet modem or others. ad hoc A communication configuration in which every computer has the network same capabilities, and any computer can initiate a communication session.
Page 124 Short for Extensible Authentication Protocol, EAP sits inside of Point-to-Point Protocol’s (PPP) authentication protocol and provides a generalized framework for several different authentication methods. EAP is supposed to head off proprietary authentication systems and let everything from passwords to challenge-response tokens and public-key infrastructure certificates all work smoothly.
Page 125 Fragmentation The threshold at which the wireless adapter breaks the packet into threshold multiple frames. This determines the packet size and affects the throughput of the transmission. Gigahertz. A unit of frequency equal to 1,000,000,000 cycles per second. Host computer The computer that is directly connected to the Internet via a modem or network adapter.
Page 126 PEAP Protected Extensible Authentication Protocol (PEAP) is an Internet Engineering Task Force (IETF) draft protocol sponsored by Microsoft, Cisco, and RSA Security. PEAP creates an encrypted tunnel similar to the tunnel used in secure web pages (SSL). Inside the encrypted tunnel, a number of other EAP authentication methods can be used to perform client authentication.
Page 127 SSID. This is the wireless network name that appears when a DMU (Device Management Utility, such as Intel® PROSet/Wireless) scans for available wireless networks. It is commonly considered a weak security feature, in that it does not readily disclose the presence of the wireless network.
Page 128 TTLS Tunneled Transport Layer Security. These settings define the protocol and the credentials used to authenticate a user. In TTLS, the client uses EAP-TLS to validate the server and create a TLS- encrypted channel between the client and server. The client can use another authentication protocol, typically password-based protocols, such as MD5 Challenge over this encrypted channel to enable server validation.
Page 129 WPA2 Wi-Fi Protected Access 2 (WPA2). This is the second generation of WPA that complies with the IEEE TGi specification. WPA2 consists of AES encryption, pre-authentication and PMKID caching. It provides support for BSS (Infrastructure) mode and IBSS (ad hoc) mode.
Page 130: Wireless Network Overview
When you set up your wireless adapter, you select the operating mode for the kind of wireless network you want. You can use your Intel(R) PRO/Wireless Network Connection adapter to connect to other similar wireless devices that comply with the 802.11 standard for wireless networking.
Page 131: Network Name
The software application on your computer that is used to manage your wireless connections is commonly referred to as a wireless network manager or client utility. Your Dell portable computer ships with two client utilities installed: Intel PROSet/ Wireless and Microsoft Windows Zero Configuration. Intel PROSet is set by default as the utility which controls the management of your wireless connections.
Page 132 The name can be up to 32 characters long and contain letters and numbers. Profiles: When you set up your computer to access a wireless network, Intel (R) PROSet/Wireless creates a profile for the wireless settings that you specify.
Page 133 802.1x protocol and framework for communication between a client and an access point Get Connected Identify a Wireless Network Depending on the size and components of a wireless network, there are many ways to identify a wireless network: The Network Name or Service Set Identifier (SSID): Identifies a wireless network.
Page 134 There are two methods to turn the radio on and off: The hardware switch The Enable/Disable button in Intel PROSet/Wireless software A common cause for users not being able to connect to a wireless network is due to the radio being turned off. If you are unable to connect to a wireless network, verify that your radio is turned on by both the hardware switch and the software Enable/ Disable button.
Page 135 Back to Contents Security Overview WEP Encryption Open and Shared Key authentication 802.1x Authentication How 802.1x Authentication Works 802.1x Features WPA/WPA2 Enterprise Mode Personal Mode WPA-Enterprise and WPA2-Enterprise WPA-Personal and WPA2-Personal AES-CCMP TKIP TTLS Authentication Protocols PEAP Authentication Protocols Cisco Features Cisco LEAP Cisco Rogue Access Point Security Feature Fast Roaming (CCKM)
Page 136: Wep Encryption
Radio Management WEP Encryption Use IEEE 802.11 Wired Equivalent Privacy (WEP) encryption to prevent unauthorized reception of wireless data. WEP encryption provides two levels of security that use a 64-bit key (sometimes referred to as 40-bit) or a 128-bit key (also known as 104-bit).
Page 137 802.1x Authentication How 802.1x Authentication Works 802.1x Features Overview The 802.1x authentication is independent of the 802.11 authentication process. The 802.1x standard provides a framework for various authentication and key- management protocols. There are different 802.1x authentication types, each provides a different approach to authentication but all employ the same 802.1x protocol and framework for communication between a client and an access point.
Page 138 devices attached to a LAN port and prevent access to that port if the authentication process fails. What is RADIUS? RADIUS is the Remote Authentication Dial-In User Service, an Authorization, Authentication, and Accounting (AAA) client-server protocol, that is used when a AAA dial-up client logs in or out of a Network Access Server.
Page 139 NOTE: Intel PROSet/Wireless security features on Windows Vista support TTLS and EAP-SIM authentication only. WPA or WPA2 Wi-Fi Protected Access (WPA or WPA2) is a security enhancement that strongly increases the level of data protection and access control to a wireless network. WPA enforces 802.1x authentication and key-exchange and only works with dynamic...
Page 140: Authentication Protocols
NOTE: WPA-Personal and WPA2-Personal are not interoperable. AES-CCMP - (Advanced Encryption Standard - Counter CBC-MAC Protocol) The new method for privacy protection of wireless transmissions specified in the IEEE 802.11i standard. AES-CCMP provides a stronger encryption method than TKIP. Choose AES- CCMP as the data encryption method whenever strong data protection is important.
Page 141 designed for use with PPP. Password Authentication Protocol is a plain text password used on older SLIP systems. It is not secure. CHAP: Challenge Handshake Authentication Protocol is a three-way handshake protocol that is considered more secure than PAP Authentication Protocol.
Page 142 Cisco LEAP (Cisco Light EAP) is a server and client 802.1x authentication through a user-supplied logon password. When a wireless access point communicates with a Cisco LEAP-enabled RADIUS (Cisco Secure Access Control Server [ACS]), Cisco LEAP provides access control through mutual authentication between client wireless adapters and the wireless networks and provides dynamic, individual user encryption keys to help protect the privacy of transmitted data.
Page 143 EAP-FAST EAP-FAST like EAP-TTLS and PEAP, uses tunneling to protect traffic. The main difference is that EAP-FAST does not use certificates to authenticate. Provisioning in EAP-FAST is negotiated solely by the client as the first communication exchange when EAP-FAST is requested from the server. If the client does not have a pre- shared secret Protected Access Credential (PAC), it is able to initiate a provisioning EAP-FAST exchange to dynamically obtain one from the server.
Page 144 Back to Contents Trademarks and Disclaimers...
Page 145: Specifications
Back to Contents Specifications Intel Wireless WiFi Link 4965AGN Intel Wireless WiFi Link 4965AG_ Intel PRO/Wireless 3945ABG Network Connection Intel PRO/Wireless 3945BG Network Connection Intel PRO/Wireless 2915ABG Network Connection Intel PRO/Wireless 2200BG Network Connection Intel Wireless WiFi Link 4965AGN Form Factor...
Page 146 TLS, EAP-TTLS Product Safety UL, C-UL, CB (IEC 60590) Intel Wireless WiFi Link 4965AG_ (version with Draft N capabilities disabled. Draft N refers to: IEEE P802.11n(TM)/D1.0 Draft Amendment to STANDARD [FOR] Information Technology-Telecommunications and information exchange between systems-Local and Metropolitan networks-Specific...
Page 147 802.1x: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP- TLS, EAP-TTLS Product Safety UL, C-UL, CB (IEC 60590) Intel PRO/Wireless 3945ABG Network Connection Form Factor PCI Express (TM) Mini Card Dimensions Height 2.00 in x 1.18 in x 0.18 in (50.95 mm x 30 mm...
Page 148 Infrastructure or ad hoc (peer-to-peer) operating modes Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2- Enterprise, AES-CCMP 128-bit, WEP 128-bit and 64-bit; 802.1x: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP- TLS, EAP-TTLS Product Safety UL, C-UL, CB (IEC 60590) Intel PRO/Wireless 3945BG Network Connection...
Page 149 Infrastructure or ad hoc (peer-to-peer) operating modes Security WPA-Personal, WPA2-Personal, WPA- Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-bit and 64-bit; 802.1x: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP- TLS, EAP-TTLS Product Safety UL, C-UL, CB (IEC 60590) Intel PRO/Wireless 2915ABG Network Connection...
Page 150 Form Factor Mini PCI Type 3A Dimensions Width 2.85 in x Length 1.75 in x Height 0.20 in (59.75 mm x 50.95 mm x 5 mm) Weight 0.7 oz. (12.90 g.) Antenna Interface Connector Hirose U.FL-R-SMT mates with cable connector U.FL-LP- Dual Diversity Antenna On-board dual diversity switching Connector Interface...
Page 151 Intel PRO/Wireless 2200BG Network Connection Form Factor Mini PCI Type 3B Dimensions Width 2.34 in x Length 1.75 in x Height 0.20 in (59.45 mm x 44.45 mm x 5 mm) Weight 0.7 oz. (12.90 g.) Antenna Interface Connector Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066...
Page 152 Back to Top Back to Contents Trademarks and Disclaimers...
Page 153: Customer Support
Back to Contents Customer Support Intel support is available online or by telephone. Available services include the most up-to-date product information, installation instructions about specific products, and troubleshooting tips. Online Support Technical Support: http://support.intel.com Network Product Support: http://www.intel.com/network Corporate Web Site: http://www.intel.com...
Page 154 NOTE: Due to the evolving state of regulations and standards in the wireless LAN field (IEEE 802.11 and similar standards), the information provided herein is subject to change. Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein.
Page 155 Antenna Warnings Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is recommended for the Intel(R) Wireless WiFi Link 4965AGN or Intel(R) Wireless WiFi Link 4965AG_ adapter installed in a desktop or portable...
Page 156 For country-specific information, see the additional compliance information supplied with the product. Wireless interoperability The Intel(R) Wireless WiFi Link 4965AGN or Intel(R) Wireless WiFi Link 4965AG_ is designed to be interoperable with other wireless LAN products that are based on direct sequence spread spectrum (DSSS) radio technology and to comply with the following standards: IEEE Std.
Page 157 Corporation. The correction of interference caused by such unauthorized modification, substitution or attachment is the responsibility of the user. Intel Corporation and its authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise from the user failing to comply with these guidelines.
Page 158 Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. NOTE: The Intel(R) Wireless WiFi Link 4965AGN or Intel(R) Wireless WiFi Link 4965AG_ adapter wireless network device must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product.
Page 159 Dansk Undertegnede Intel(R) Corporation erklærer herved, at følgende udstyr Intel(R) Wireless WiFi [Danish] Link 4965AGN or Intel(R) Wireless WiFi Link 4965AG_ overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Deutsch Hiermit erklärt Intel(R) Corporation, dass sich das Gerät Intel(R) Wireless WiFi Link 4965AGN or [German] Intel(R) Wireless WiFi Link 4965AG_ in Übereinstimmung mit den grundlegenden Anforderungen...
Page 160 övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Íslenska Hér með lýsir Intel(R) Corporation yfir því að Intel(R) Wireless WiFi Link 4965AGN or Intel(R) [Icelandic] Wireless WiFi Link 4965AG_ er í samræmi við grunnkröfur og aðrar kröfur, sem gerðar eru í...
Page 161 NOTE: Due to the evolving state of regulations and standards in the wireless LAN field (IEEE 802.11 and similar standards), the information provided herein is subject to change. Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein.
Page 162 Antenna Warnings Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is recommended for the Intel(R) PRO/Wireless 3945ABG Network Connection adapter, or the Intel(R) PRO/Wireless 3945BG Network Connection...
Page 163 The device transmit power control (TPC) interface is part of the Intel(R) PROSet/ Wireless software. Operational restrictions for Equivalent Isotropic Radiated Power (EIRP) are provided by the system manufacturer.
Page 164 Intel(R) PRO/Wireless 3945ABG Network Connection or the Intel(R) PRO/Wireless 3945BG Network Connection adapter kit, or the substitution or attachment of connecting cables and equipment other than that specified by Intel Corporation. The correction of interference caused by such unauthorized modification, substitution or attachment is the responsibility of the user.
Page 165 Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. NOTE:The Intel(R) PRO/Wireless 3945ABG Network Connection adapter or the Intel(R) PRO/ Wireless 3945BG Network Connection adapter wireless network device must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product.
Page 166 5.15 - 5.35 GHz and 5.47-5.725 GHz (Europe ETSI) Low band 5.25 - 5.35 GHz is for indoor use only 5.47 - 5.725 GHz is current not allowed in Czech Republic and France. Declaration of Conformity...
Page 167 Connection or Intel(R) PRO/Wireless 3945BG Network Connection is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Español Por medio de la presente Intel(R) Corporation declara que el Intel(R) PRO/Wireless 3945ABG [Spanish] Network Connection or Intel(R) PRO/Wireless 3945BG Network Connection cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Page 168 Português Intel(R) Corporation declara que este Intel(R) PRO/Wireless 3945ABG Network Connection or [Portuguese] Intel(R) PRO/Wireless 3945BG Network Connection está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovensko Šiuo Intel(R) Corporation izjavlja, da je ta Intel(R) PRO/Wireless 3945ABG Network Connection...
Page 169 NOTE: Due to the evolving state of regulations and standards in the wireless LAN field (IEEE 802.11 and similar standards), the information provided herein is subject to change. Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein.
Page 170 Antenna Warnings Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is recommended for the Intel(R) PRO/Wireless 2915ABG Network Connection adapter installed in a desktop or portable computer, that the...
Page 171 The device transmit power control (TPC) interface is part of the Intel(R) PROSet/ Wireless software. Operational restrictions for Equivalent Isotropic Radiated Power (EIRP) are provided by the system manufacturer.
Page 172 PRO/Wireless 2915ABG Network Connection adapter kit, or the substitution or attachment of connecting cables and equipment other than that specified by Intel Corporation. The correction of interference caused by such unauthorized modification, substitution or attachment is the responsibility of the user. Intel Corporation and its authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise from the user failing to comply with these guidelines.
Page 173 Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. NOTE: The Intel(R) PRO/Wireless 2915ABG Network Connection adapter wireless network device must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product.
Page 176 Connection megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. Icelandic Intel lysir her med yfir að thessi bunadur, Intel(R) PRO/Wireless 2915ABG Network Connection , uppfyllir allar grunnkrofur, sem gerdar eru i R&TTE tilskipun ESB nr 1999/5/EC Italian Con la presente Intel(R) Corporation dichiara che questo Intel(R) PRO/Wireless 2915ABG Network Connection è...
Page 177 Connection atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Spanish Por medio de la presente Intel(R) Corporation declara que el Intel(R) PRO/Wireless 2915ABG Network Connection cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Page 178 - D.L.gs 1.8.2003, n. 259, article 104 (activity subject to general authorization) for outdoor use and article 105 (free use) for indoor use, in both cases for private use. - D.M. 28.5.03, for supply to public of RLAN access to networks and telecom services. L’uso degli apparati è...
Page 179 The FCC with its action in ET Docket 96-8 has adopted a safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified equipment. The Intel(R) PRO/Wireless 2200BG Network Connection meets the Human Exposure limits found in OET Bulletin 65, 2001, and ANSI/IEEE C95.1, 1992.
Page 180 Antenna Warnings Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is recommended for the Intel(R) PRO/Wireless 2200BG Network Connection installed in a desktop or portable computer, that the antenna for this device be installed so as to provide a separation distance of al least 20 cm (8 inches) from all persons and that the antenna must not be co-located or operating in conjunction with any other antenna or radio transmitter.
Page 181 PRO/Wireless 2200BG Network Connection adapter kit, or the substitution or attachment of connecting cables and equipment other than that specified by Intel Corporation. The correction of interference caused by such unauthorized modification, substitution or attachment is the responsibility of the user. Intel Corporation and its authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise from the user failing to comply with these guidelines.
Page 182 l'intérieur et devrait être placé loin des fenêtres afinde fournir un écran de blindage maximal. Si le matériel (ou son antenne d'émission) est installé à l'extérieur, il doit faire l'objet d'une licence. » Europe—EU Declaration of Conformity Europe Frequency Bands 2.400 - 2.4835 GHz (Europe ETSI)
Page 184 Connection in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Bij deze verklaart Intel(R) Corporation dat deze Intel(R) PRO/Wireless 2200BG Network Connection voldoet aan de essentiële eisen en aan de overige relevante bepalingen van Richtlijn 1999/5/EC.
Page 185 Connection ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ. Icelandic Intel lysir her med yfir að thessi bunadur, Intel(R) PRO/Wireless 2200BG Network Connection , uppfyllir allar grunnkrofur, sem gerdar eru i R&TTE tilskipun ESB nr 1999/5/EC. Italian Con la presente Intel(R) Corporation dichiara che questo Intel(R) PRO/Wireless 2200BG Network Connection è...
Page 186 2.420 - 2.4835 GHz (canaux 5 à 13) autorisé en usage extérieur Pour tout le territoire Français: Seulement 5.15 -5.35 GHz autorisé pour le 802.1 Belgique Dans le cas d'une utilisation privée, à l'extérieur d'un bâtiment, au-dessus d'un espace public, aucun enregistrement n'est nécessaire pour une distance de moins de 300m.
Page 187 Pakistan Telecommunication Authority (PTA) Approved Radio approvals To determine whether you are allowed to use your wireless network device in a specific country, please check to see if the radio type number that is printed on the identification label of your device is listed in the manufacture OEM Regulatory Guidance document.
Page 188: Limited Warranty
If such a defect appears within the warranty period, you may return the defective media to Intel for replacement or alternative delivery of the software at Intel's discretion and without charge. Intel does not warrant or assume responsibility for the accuracy or completeness of any information, text, graphics, links or other items contained within the software.
Page 189 ICS center, you must include the RMA number on the outside of the package. Intel will not accept any returned Product without an RMA number, or that has an invalid RMA number, on the package. You must deliver the returned Product to the designated ICS center in the original or equivalent packaging, with shipping charges pre-paid (within the USA), and assume the risk of damage or loss during shipment.
Page 190 Intel within a reasonable period of time after receipt of the returned Product by ICS. The returned Product shall become Intel’s property on receipt by ICS. The replacement product is warranted...
Page 191 PRODUCTS SOLD HEREUNDER ARE NOT DESIGNED, OR INTENDED FOR USE IN ANY MEDICAL, LIFE SAVING OR LIFE SUSTAINING SYSTEMS, TRANSPORTATION SYSTEMS, NUCLEAR SYSTEMS, OR FOR ANY OTHER MISSION CRITICAL APPLICATION IN WHICH THE FAILURE OF THE INTEL PRODUCT COULD CREATE A SITUATION WHERE PERSONAL INJURY OR DEATH MAY OCCUR.

Intel 4965AGN User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intel 4965AGN

Summary of Contents for Intel 4965AGN

Table of Contents
