  • Page 1 Fog machine DSK-1500VS User’s Manual...

  • Page 2: Table Of Contents

    Fog machine DSK-1500VS Art.No.: 115654 Table of contents Safety instructions ....................3 1.1. For safe and efficient operation..............3 Intended use of the device ................4 2.1. Overhead installation ..................5 2.2. Connections ....................6 2.2.1. Electrical connections ................6 2.2.2.

  • Page 3: Safety Instructions

    Fog machine DSK-1500VS Art.No.: 115654 1. Safety instructions • This device is suitable for indoor use (not outdoors) only. • Unauthorized modifications will invalidate the warranty. • Repairs are to carry out by skilled workers only. • Use only fuses of the same type and original parts as spare parts.

  • Page 4: Intended Use Of The Device

    Fog machine DSK-1500VS Art.No.: 115654 2. Intended use of the device This device was developed for professional use on stages, in discos, theatres etc. The device is only approved for a connection up to 230 V 50/60 Hz alternating current and only for indoor use.

  • Page 5: Overhead Installation

    Fog machine DSK-1500VS Art.No.: 115654 Never use solvents or aggressive detergents for cleaning. Use instead of this a damped cleaning rag. To prevent damages during transport use for transport the original packing or provided accessories. For reasons of safety unauthorized changes are forbidden! A usage of the device which differs from usages which are described in this manual can cause damages of the device.

  • Page 6: Connections

    Fog machine DSK-1500VS Art.No.: 115654 It is not allowed to install the device in the grip area of people. If the device may hang from the ceiling or from high beams, the use of truss systems is mandatory. The device may not be installed so it can swing freely in the room.

  • Page 7: Dmx Connections

    Fog machine DSK-1500VS Art.No.: 115654 2.2.2. DMX connections Make sure that you use shielded cable. 3pol or 5pol XLR cables are suitable. 2.3. DMX connection with terminator Where the DMX cable has to run a long distance or the equipment is operated in an electrically noisy environment like a disco for installations, we recommend using a DMX terminator.

  • Page 8: Introduction

    As the world’s first company DJPOWER has further developed the vertical fog machine DSK-1500VS so that it a higher and brighter fog output is possible. The patented technology makes it possible to color the fog in two different colors to create a unique flame effect.

  • Page 9: Product Description

    Fog machine DSK-1500VS Art.No.: 115654 3.3. Product description 1. Fluid tube 2. Tank baffle 3. 32x 3W LEDs 4. Fan 5. On/Off switch 6. Fuse 7. Power supply 8. Tank 9. Nozzle 10. XLR 3pol INPUT/OUTPUT 11. Display 12. Fog button 13.

  • Page 10: Overhead Installation Of The Device

    Fog machine DSK-1500VS Art.No.: 115654 3.4. Overhead installation of the device Remove the screws and the bottle lock to take out the tank. Turn the machine upside down and remove the screws to release the plate. Fix the removable plate to the opposite side and fit the tank with the bottle lock again.

  • Page 11: Start-Up

    Fog machine DSK-1500VS Art.No.: 115654 4. Start-up Attention! Remove before start-up every packing material. 1. After verifying that the unit is intact and complete, please place it on a level surface. 2. Fill the tank with fluid (Please use fog fluid CO2). Please use only the recommended fluid as the device may be damaged and warranty void.

  • Page 12: Structure Of The Menu

    Fog machine DSK-1500VS Art.No.: 115654 4.1.1. Structure of the menu Menu Settings Function Addr 0 – 512 Setting the DMX address. Advising the color settings for the single channels. Every button on the remote represents a channel: A = CH-1, B = CH-2, C = CH3 und D = CH4.

  • Page 13: Dmx Chart

    Fog machine DSK-1500VS Art.No.: 115654 4.1.2. DMX chart If the device is controlled by DMX the display shows the set DMX address. Please note that the LEDs will get out after approx. 10 seconds and the channel 8 must be activated again.
  • Page 14 Fog machine DSK-1500VS Art.No.: 115654 No function Color change slow – fast No function Strobe slow – fast No function Dimmer 0 – 100% 14 / 21...

  • Page 15: Remote

    Fog machine DSK-1500VS Art.No.: 115654 4.1.3. Remote 1. Activate the remote. (Cf. chapter 4.1.1). 2. Power off the device. 3. Power on the device again. The display shows a bar diagram. Press, while the bar diagram is shown in the display, any key on the remote.

  • Page 16: Technical Data

    Fog machine DSK-1500VS Art.No.: 115654 5. Technical data Voltage AC 220 V – 240 V; 50/60 Hz Power consumption max. 1500 W Fuse 8 A/250 V LM type LED single color (11x red, 10x green and 11x blue) Power 96 W...
  • Page 17 Fog machine DSK-1500VS Art.No.: 115654 For your notes: 17 / 21...
  • Page 18 Fog machine DSK-1500VS Art.No.: 115654 For your notes: 18 / 21...
  • Page 19 Fog machine DSK-1500VS Art.No.: 115654 For your notes: 19 / 21...
  • Page 20 Fog machine DSK-1500VS Art.No.: 115654 For your notes: 20 / 21...
  • Page 21 Fog machine DSK-1500VS Art.No.: 115654 Importer: B&K Braun GmbH Im Stöckmädle 27 D-76307 Karlsbad www.bkbraun.com info@bkbraun.com 21 / 21...
