Material: 80 GSM Bond Paper or 50# Bond Paper White
Ink: Black
Resolution: 150 DPI or above
Printing method: Offset Printing
Binding: Saddle Stitch
Folded size: 100 x 60 mm (W x H)
This drawing contains proprietary information and trade secrets of The Furrion Company, Inc.
METRIC
[INCH]
METRIC [INCH]
CRITICAL DIMENSION
CHECKING IS COMPULSORY
3
VOLUME
cm
MASS
grams
3
DENSITY
g/cm
GENERAL TOLERANCES
EXCEPT AS NOTED
0 TO 6mm = ±0.1
>6 TO 30mm = ±0.2
>30 TO 80mm = ±0.3
>80 TO 180mm = ±0.4
>180mm = ±0.5
ANGULAR = ± 3°
DO NOT PRINT THIS PAGE
Printing Notes:
Unauthorized use or copying is prohibited.
V1.0
28-May-18
REV.
DATE
MATERIAL:
FINISH SPEC:
SCALE:
DATE:
28-May-18
NAME:
Instruction Manual for DV7200 Entertainment Systerm
NEW
MODIFICATIONS
COMPOSITE-NO
DRAWN BY:
APPROVED BY:
Sally Peng
Sally Peng
NAME
The Furrion Company, Inc.
SHEET 1 OF 1
Ricky Deng
PART NO.
IM-FAV00033
XX
ECN NO.
REVISION:
1.0
Advertisement
Table of Contents
Related Manuals for Furrion DV 7200
Summary of Contents for Furrion DV 7200
- Page 1 Resolution: 150 DPI or above Printing method: Offset Printing Binding: Saddle Stitch Folded size: 100 x 60 mm (W x H) This drawing contains proprietary information and trade secrets of The Furrion Company, Inc. Unauthorized use or copying is prohibited. METRIC [INCH]...
- Page 2 Entertainment System DV 7200 Instruction Manual...
-
Page 3: Welcome
Welcome Thank you for purchasing this Furrion Entertainment System. Before placing your new product ® into operation, please read these operating instructions carefully. They contain important information for safe use, installation and maintenance of the product. Please keep this instruction manual in a safe place for future reference. Pass it onto possible new owners of the product. -
Page 4: Table Of Contents
Contents Welcome ....................1 Contents ....................2 Locations and Names of the Controls ........... 3 Remote Control ..................5 Installation ................... 7 Connections ..................9 Operation .................... 14 Common Operation .................14 Radio Operation ................17 USB Operation .................18 Bluetooth Operation ................20 Specification .................. -
Page 5: Locations And Names Of The Controls
Locations and Names of the Controls Item Button Power & Mute LCD Display Volume + Volume - ZONE 1... - Page 6 Locations and Names of the Controls Item Button Item Button Item Button Item Button Next 4/RDM Aux In Jack ZONE 2 5/Backlight/ HDMI In Previous AM/FM Hang up Jack 1/Play/ 6/Clock Adjust/ Microphone Pause Alarm/TEL USB Socket RESET 2/STOP NFC Detection Headphone SOURCE/ 3/RPT...
-
Page 7: Remote Control
Remote Control Item Button Item Button POWER MODE Number(0-9) 1/ PLAY/ PAUSE SCAN /TOP Button 2/INT Button 3/RPT Button CLOCK 4/RDM Button Z ONE1 Z ONE2 AL ARM BAND * Button... - Page 8 Remote Control Item Button Item Button Item Button MUTE LOUD ALARM CALL LOG LOCAL ZONE 1 UP & DOWN HANG UP ZONE 2 # Button + & -...
-
Page 9: Installation
Installation Location ● Choose a mounting location away from humid areas, water sources, burning products or any equipment that can radiate heat. ● Select an area on the wall or cabinet, which is free from cable, fuel or brake lines. There is a vent hole at the back of the unit for cooling purpose, do not block it. - Page 10 Installation 1. Remove plastic frame of the front panel from the unit. Screw 2. Fix the unit to the wall with 4 #8 pan head self-tapping screw. 3. Replace the plastic frame of the front panel to the unit. Screw Plastic frame of the front panel...
-
Page 11: Connections
Connections Supported Audio Format File Extension .mp3 .wma Audio Code Bit Rate 16kbps - 320kbps CBR/VBR 16kbps - 320kbps Sampling 8k - 48kHz 8k - 48kHz Rate WMA only support WMA7/WMA8/WMA9/ Remark (CBR/VBR)(only support 353 format) NOTE: Reading the above file formats is not guaranteed. - Page 12 Connections Wiring Diagram HDMI OUT JACK AV IN AV OUT SUBWOOFER OUT IR REMOTE JACK AUDIO IN ANTENNA WIRING CONNECTING SOCKET...
- Page 13 Connections Wiring connecting socket view Item Color Function Green Zone 2 Left Speaker(+) Purple/ Zone 2 Right Speaker(-) Black White Zone 1 Left Speaker(+) Gray/ Zone 1 Right Speaker(-) Black Gray Zone 1 Right Speaker(+) White/ Zone 1 Left Speaker(-) Black...
- Page 14 Connections NOTE: All speakers must be connected as Item Color Function shown. If one wire is removed or not connected properly, all speakers on relevant zone will fail to work. It is of importance to pay attention in Purple Zone 2 Right Speaker(+) speaker polarity.
- Page 15 Connections 4-Speaker (2 ZONE) Wiring 2-Speaker Mono (2 ZONE) Wiring WHITE WHITE(+) ZONE 1 ZONE 1 ZONE 1 LEFT SPEAKER(+) WHITE/BLACK GRAY/BLACK(-) LEFT LEFT ZONE 1 LEFT SPEAKER(-) GRAY GRAY ZONE 1 ZONE 1 RIGHT SPEAKER(+) LEAVE NOT WHITE/BLACK RIGHT GRAY/BLACK CONNECTED ZONE 1 RIGHT SPEAKER(-)
-
Page 16: Operation
Operation Common Operation 1. To turn the unit On/Off When the unit is powered Off, it may be switched On by pressing the POWER button. When the unit is switched On, press and hold the POWER button to switch if off. 2. - Page 17 Operation Press and hold SEL button to turn on BASS, then press SEL button repeatedly to select or circulate through TRE (treble), EQ OFF (FLAT/...AMERICA3/AUSTRALIA/EUROPE (in radio mode), press VOLUME+/- to change the settings. Press SEL button to confirm your selection. –...
- Page 18 Operation (NOTE: This button is only for FM reception. In AM mode, LOC is invalid.) 7. To display and adjust the time Press and hold 6 button until the clock becomes flashing. Use VOLUME+/- button to adjust the hour, and button to adjust the minute.
-
Page 19: Radio Operation
Operation – 2) In AUX mode, press and hold 2/STOP button until the LCD displays “RESET III”, then press and hold 3/RPT button to reset to the factory default settings. Radio Operation 1. To select radio band Press AM/FM button repeatedly to select a desired radio band in sequence and circulating as: -->FM1-->FM2-->FM3-->AM1-->AM2-->. -
Page 20: Usb Operation
Operation available stations and check the signal strength from the lowest frequency. The top 6 strongest stations will be saved to the corresponding preset numbered band 1~6. 5. To set the frequency Press and hold SEL button to turn on BASS, then press SEL button repeatedly to select AMERICA3, AUSTRALIA or EUROPE area, press VOLUME+/- button to select your desired frequency. - Page 21 Operation During playback, press 1/PLAY/PAUSE button to pause playback, press 1/PLAY/PAUSE button again to resume, press and hold 1/PLAY/PPAUSE button to select the first track to play. 6. To repeat track(s) – During playback, press 3/RPT button briefly to play the current track repeatedly. RPT ONE will be displayed on LCD.
-
Page 22: Bluetooth Operation
Connections). 4. Ensure Bluetooth is turned On. 5. Select FURRION DV7200-XXXX (where X can be any alphanumeric number A-Z or 0-9). In Android devices, you will see another similarly-named devices under DV7200-4.0-XXXX. DO NOT use that one. It is used for Apps control to be described later. If you click on it accidentally, please clicke the gear icon to forget (or unpair) it. - Page 23 Operation NOTE: DV7200 supports NFC pairing. The NFC detection area is on the right of the Power button. Disconnect and Reconnect ● Bluetooth connection of mobile devices typically covers a 33 ft (10 m) open-field range. And DV7200 “remembers” the last connected mobile. For any out-of-range disconnection, DV7200 will auto-reconnect to your mobile once it is back in range again.
- Page 24 Operation DV7200 will be properly notified and all settled. ● If you do that after an out-of-range disconnection, DV7200 will repair and reconnect the mobile. In that case, you can press and hold the BT button for ~ 2 seconds in DV7200 to clear its memory.
- Page 25 Mobile App ● You can use the Furrion ES Control App (both Android and iOS versions) and thus your mobile as a remote control. ● The app uses BT Low Energy (BLE) technology to connect to DV7200 instead of infrared in the physical remote control, and thus not limited by line-of-sight connection.
-
Page 26: Specification
Specification GENERAL AM SECTION Supply Voltage DC 12V 522KHz - 1620KHz (Europe) Frequency 530kHz - 1710KHz (U.S.A.) Range 522KHz - 1710KHz (Australia) Current Max.5A Consumption 4 x 9 W RMS Effective Power Output 40dBu (4 Ohm speakers). Sensitivity Number of 4 channels Channels Preamp... - Page 27 Specification FM SECTION USB PLAYBACK Audio Format MP3, WMA 87.5MHz - 108MHz (Europe) Frequency 87.5MHz - 107.9MHz (U.S.A.) Range 87.5MHz - 108MHz (Australia) 20Hz -100Hz <=5dB Frequency Characteristics 10KHz-20KHz <=5dB Effective 12dBu Signal to Noise Sensitivity 50dB [1KHz] Ratio (SNR)
-
Page 28: Warranty
Warranty FURRION WARRANTS FOR A PERIOD OF 1 YEAR FROM DATE OF RETAIL PURCHASE BY THE ORIGINAL END-USE PURCHASER, THAT THIS PRODUCT, WHEN DELIVERED TO YOU IN NEW CONDITION, IN ORIGINAL PACKAGING, FROM A FURRION AUTHORIZED RESELLER AND USED IN NORMAL CONDITIONS, IS FREE FROM ANY DEFECTS IN MANUFACTURING, MATERIALS, AND WORKMANSHIP. - Page 29 AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. No Furrion reseller, agent, or employee is authorized to make any modification, extension, or addition to this warranty. FURRION IS NOT RESPONSIBLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR...
- Page 30 WARRANTIES OR CONDITIONS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY BY STATE OR (WHERE APPLICABLE IN THE COUNTRIES WHERE FURRION HAS NON-US/CANADIAN AUTHORIZED DEALERS) COUNTRY. NO ACTION OR CLAIM TO ENFORCE THIS WARRANTY SHALL BE COMMENCED AFTER THE EXPIRATION OF THE WARRANTY PERIOD.
- Page 33 ● 52567 Independence Ct., Elkhart, IN 46514, USA ● Toll free:1-888-354-5792 ● Email: support@furrion.com ©2007-2018 Furrion Ltd. Furrion and the Furrion logo are trademarks licensed for ® use by Furrion Ltd. and registered in the U.S. and other countries. FURRION.COM IM-FAV00033 V1.0...
