Congratulations on purchasing SIXY™ by Molten Voltage
SIXY™ is a programmable PedalBoard Tempo Controller for Line 6 Devices, Behringer Devices;
T-Rex's Replica Delay, and Free The Tone's Flight Time Delay that connects to the MIDI IN Jack of
compatible Line 6 Devices and sends Line 6 tempo data to sync your effect with the incoming MIDI Clock
at one of nine (9) musical ratios.
Key Features
•
Synchronize your PedalBoard's Line 6, Behringer, T-Rex, and Free The Tone Devices to MIDI Clock
•
Works with numerous Line 6 Devices including POD, Vetta II, and Flextone III
•
Ratio control multiplies or divides the output
against the incoming clock into one of nine (9)
musical ratios
•
Tap "One-Shot" Button sends tempo data
when no MIDI Clock is present
•
Stores and recalls distinct Output Ratio for each
of 128 MIDI programs
•
Simple to program - hold down the button!
•
Optically Isolated Connection ensures 100%
electrical isolation of audio and digital signals
•
Compact design for modular PedalBoard layouts
•
Solid, Professional-Grade construction, including
Riveted Steel MIDI Jacks
•
Molten Voltage MIDI technology allows remote, synchronized self-programming
•
Robust, 128 program storage
questions@MoltenVoltage.com
OWNER'S MANUAL
© 2014 - MoltenVoltage.com - All Rights Reserved.
v 1.3
Advertisement
Table of Contents
Related Manuals for MoltenVoltage Sixy
Summary of Contents for MoltenVoltage Sixy
- Page 1 OWNER’S MANUAL Congratulations on purchasing SIXY™ by Molten Voltage SIXY™ is a programmable PedalBoard Tempo Controller for Line 6 Devices, Behringer Devices; T-Rex’s Replica Delay, and Free The Tone’s Flight Time Delay that connects to the MIDI IN Jack of compatible Line 6 Devices and sends Line 6 tempo data to sync your effect with the incoming MIDI Clock at one of nine (9) musical ratios.
- Page 2 Plus, POD 2.0, POD Pro, POD XT, Bass POD XT, POD X3 Live, POD X3 Pro, Vetta II, Vetta II HD, Flextone III, HD 147, Pocket POD, and Gear Box Software. SIXY also works with works with Behringer V-Amp, T-Rex Replica Delay, and Free The Tone Flight Time Delay.
- Page 3 Connect a standard 5-pin MIDI cable from the MIDI OUT Jack (A) to the MIDI IN Jack on your compatible Line 6 device. SIXY transmits Tap Tempo data which is synchronized to the incoming MIDI Clock. Note: Tap Tempo Data is only sent while MIDI Clock data is being received, or when the Tap Button (F) is pressed, as discussed below.
- Page 4 Program Storage SIXY stores the distinct Output Ratio for each of 128 programs. Holding down the first press of the TAP/SAVE Button (F) for more than 2.5 seconds causes SIXY to save the current ratio at the current Program location.
- Page 5 Note: the primary MIDI channel for the Molten Voltage system is MIDI Channel 15, but Program Change messages on that channel are re-transmitted on Channel 1 which is the common Line 6 MIDI Channel. MIDI Phantom Power SIXY does not use MIDI Phantom Power. questions@MoltenVoltage.com © 2014 - MoltenVoltage.com - All Rights Reserved. v 1.3...
-
Page 6: Midi Implementation Chart
Plug in 9 volt DC, 2,1mm Tip Negative Power Supply. Clicking or Noise Use a separate or isolated Power Supply for SIXY SIXY is not receiving MIDI Clock Make sure your other MIDI device is configured to send MIDI Clock. Consult the User’s Guide for that device. - Page 7 Line 6, Behringer, T-Rex, Free The Tone, and their product names are trademarks of their respective companies which are unrelated to Molten Voltage. SIMI, SIXY, CTL-Sync, MASTER CONTROL, MIDI Splitty, TEMPODE, NODE, Tru-Foot, Molten Voltage, Visionary Effects, ReMute, “Sturdy Scalable Simple”, “streamline your sound”, “Design simple Design sublime”, and “the future just showed up”...
