- Page 1 GOLDMASTER 24k A D VA N C E D G U I D E White’s Electronics, Inc. 1011 Pleasant Valley Road Sweet Home, OR 97386 USA whiteselectronics.com ©White’s Electronics, Inc.
- Page 2 Introduction White’s Electronics, Inc.’s Goldmaster® platform has served electronic prospectors well over the last 20 plus years, resulting in income for professional miners and diversion for hobbyists. With modern advances in DSP, improved ergonomics, and performance increases, the Goldmaster® 24k represents the next generation of high-frequency induction-balance gold nugget detectors.
-
Page 3: Table Of Contents
GMT Table of Contents Chapter 1 Assembly................2 Assembly Instructions ........................3 Chapter 2 Batteries................4 Standard Battery Holder ........................4 Using the Standard Battery Holder ....................4 Rechargeable Battery.........................5 Battery Meter ...........................5 Chapter 3 GMT Quick Start ...............6 Quick Start Instructions........................7 Chapter 4 Controls................8 Sensitivity Control..........................8 Sensitivity Adjustment........................8 Sensitivity Adjustment (cont’d) ......................9... -
Page 4: Chapter 1 Assembly
Chapter 1 GM24k Assembly Assembly Included with your GM24k: 1. Detector s-rod body 2. Middle rod 3. Lower fiber rod 4. Coil hardware (washers, nut, bolt) 5. 6x10” DD Coil 6. 6” Concentric Coil 7. 8x AA holder (batteries included) 8. -
Page 5: Assembly Instructions
Chapter 1 GM24k Assembly Assembly Instructions 5. Grip the instrument by the handle, with your arm in the elbow cup with strap secure, and sweep the coil over the floor. If the instrument 1. Remove all parts from shipping carton and fit feels uncomfortable, adjust the elbow cup by check the assembly page to make sure all parts removing and repositioning the bolt and install-... -
Page 6: Chapter 2 Batteries
Chapter 2 GM24k Batteries Batteries Using the Standard Battery Holder 1. Slide open the battery holder lid (decal side of battery holder) by applying gentle upward pressure on the tab of the door so that it un- locks. Slide the door away from the battery box exposing the cell positions. -
Page 7: Rechargeable Battery
Chapter 2 GM24k Batteries Battery Meter Rechargeable Battery A rechargeable battery can give you the most flexibility possible when heading out to look for gold. Rechargeable batteries deliver fairly constant voltage until they’re nearly dead. If you use them until they are dead, they will deteriorate more quickly than if you only use them till their voltage starts to drop significantly. -
Page 8: Chapter 3 Gmt Quick Start
Chapter 3 GM24k Quick Start GM24k Interface Target ID # Visual Target ID Ground strength in Higher number, Ground Scan mode Better chance of gold Beep Mode On Backlight On Iron Cancel On TracLock On Sensitivity Volume Level SAT/Threshold Level Power On/ Audio Mode Backlight... -
Page 9: Quick Start Instructions
Chapter 3 GM24k Quick Start Quick Start * SPECIAL NOTICE Instructions With the GM24k properly assembled and the If you attempt to demonstrate or test the batteries installed, follow the instructions below GM24k by waving targets in the air in to start finding those nuggets! front of the search coil, it is ESSENTIAL to have the GROUND BALANCE toggle... -
Page 10: Chapter 4 Controls
Chapter 4 GM24k Controls Controls Sensitivity Control With the SENSITIVITY control, you increase the signal strength coming from the ground. You might expect increased signal strength to always find more nuggets at greater depths. However, high Current ground mineralization will “bounce” the signal back and mask good targets. -
Page 11: Sensitivity Adjustment (Cont'd)
Chapter 4 GM24k Controls Sensitivity Adjustment (cont’d) 5. The object of increasing the SENSITIVITY is to get the maximum available depth from the detector WITH-OUT causing the overload message to appear, which indicates an overload of the circuit. 6.In addition, any increase in SENSITIVITY adjustment should NOT BE at the expense of maintain- ing a smooth and constant THRESHOLD “hum”. -
Page 12: Volume/Threshold Adjustment
Chapter 4 GM24k Controls Volume/Threshold Adjustment The VOLUME control on your GM24k only adjusts the sound level of target sounds and confirmation beeps. It is used in conjunction with the THRESHOLD to give you the most control over the dynamic range of you detec- tor. -
Page 13: Hot Rocks
Chapter 4 GM24k Controls V-SAT Speed Control The Variable SAT (Self Adjusting Threshold) Speed control adjusts the speed that the GM24k recovers its threshold hum when the search- coil passes over changes in mineralization. This setting is adjusted by holding the MUSIC button and then adjusting the SAT up or down between 0 (off), 1 (medium), or 2 (fast). -
Page 14: Target Id
Chapter 4 GM24k Controls Target ID The GM24k features two types of Target ID. The most obvious is the large numbers displayed in the center of the screen when the coil passes over a target. These two digits represent a scale from 0 to 99, with higher numbers equalling a higher chance that the target is non-ferrous. -
Page 15: Iron Cancel
Chapter 4 GM24k Controls Iron Cancel (Discrimination) When detecting for gold nuggets it is often best to “dig it all.” Gold can have various shapes, Disc Setting sizes, be embedded in iron rock, so it’s impos- (2 bars) sible to account for every nugget in the ground and only dig gold. -
Page 16: Ground Balance Xgb
Chapter 4 GM24k Controls Ground Controls Ground strength Gold is usually found in mineralized in GroundScan ground, and the GM24k has XGB enabled by default when the machine Ground Phase is powered on. This makes it easy in Ground Scan to get started prospecting, as the machine automatically cancels out TracLock ON... -
Page 17: Traclock/Ground Grab
Chapter 4 GMT Controls TracLock TracLock on the GM24k is the locked, “manual” ground setting. It functions similar to the original GMT. To LOCK the ground tracking to the current setting, TAP the LOCK button. A padlock will display on the screen. -
Page 18: Chapter 5 Searching
Chapter 4 GM24k Controls Searching Pinpoint Technique Due to the wide scan nature of elliptical search- coils it can be difficult to locate small targets under the physical center of the loop. Use an “X” marks the spot technique as shown in the diagram to identify the portion of ground the nugget is in. -
Page 19: Headphones
Chapter 5 GMT Searching Headphones The headphone jack on the GM24k is located on the rear of the battery box. There is a dust cover for the headphone jack (in your parts kit) that should be used when not running headphones. Most prospectors prefer high quality stereo headphones so White’s has chosen to wire the headphone jack for stereo. -
Page 20: Field Use & Tuning Tips
Chapter 4 GMT Searching Chapter 5 GMT Searching Field Use & Tuning Tips Any of these metals can simulate the sound of a gold nugget and must be dug. Keep a particular lookout for the tiny lead bird-shot so common in mining areas. - Page 21 Chapter 5 GMT Searching phase shifting rapidly under the coil. The first Backlight and Battery Life step you should take is to increase your SAT set- With a short tap of the power button, the ting by holding the Music Note button, and then GM24k’s backlight will turn on, giving in- tapping the Up button to set the SAT to a higher creased visibility in low light conditions.
-
Page 22: Field Use & Tuning Tips (Cont'd)
Chapter 5 GMT Searching Field Use & Tuning Tips out automatically. Using a higher SAT setting can also decrease your GM24k’s response to these positive hot rocks. Using a Double D coil Negative Hot Rocks: on the GM24k will allow the detector to operate amongst hot rocks better than a concentric. - Page 23 Chapter 5 GMT Searching target (possible nugget) from pieces of mineral, Pinpointing or “X” ing the target: commonly referred to as “hot rocks.” In most cases, pinpointing is easily performed by merely “X-ing” or criss-crossing. You can It is not wise to keep a high level of SENSITIV- also use the new non-motion pinpoint mode on ITY if the detector will not operate smoothly.
-
Page 24: Field Use & Tuning Tips (Cont'd)
Chapter 5 GMT Searching Field Use & Tuning Tips large pieces of iron, and small solid pieces of iron like heavy washers. Because this is a gold detector, it was essential to design it so that it would tend to call doubtful targets “non-ferrous” Overload: or “possible gold”. - Page 25 Chapter 5 GMT Searching Multiple tools in one machine: White’s Electronics believes that in the hands of a knowledgeable prospector, the GM24k should be capable of operating in a wide variety of conditions as a useful prospecting tool. As part of our design approach, we chose to make as many tools as possible available to aid you in your search for gold.
-
Page 26: Chapter 6 Information
Chapter 6 GMT Information Information Proper care B. If you plan on storing your detector for I. Cleaning long, remove the battery holder from the A. Both the coil and rod are waterproof and instrument and remove the batteries from the can be cleaned with fresh water and mild holder. -
Page 27: Service
Chapter 6 GMT Information Service White’s reputation has been built on quality products backed by quality service. Our Factory Authorized Service Centers are factory trained and equipped. They offer the same quality service as the factory. Service before and after the sale is the cornerstone of our customer relations. White’s Authorized USA Service Centers: Before shipping detectors for service: Centerville Electronics 13810 B Braddock Road... -
Page 28: Warranty
Chapter 6 GMT Information Warranty If within two years (24 months) from the original date of purchase, your White’s detector fails due to defects in either material or workmanship, White’s will repair or replace at its option, all necessary parts without charge for parts or labor. -
Page 29: Warranty Transfer
Chapter 6 GMT Information Warranty Transfer If for any reason you should sell your GMT prior to the date the warranty expires, the remaining warranty is transferable. This transfer is authorized by calling 1-800-547- 6911, and getting an Authorization Number. Simply fill out the following information, including the Authorization Number, seal it in a stamped envelope, and send it to White’s Electronics, 1011 Pleasant Valley Road, Sweet Home, Oregon 97386. -
Page 30: Videos And Owner Information
Chapter 6 GMT Information Videos and Help Videos of the GM24k will be available on White’s Electronics’ Youtube page: https://www.youtube.com/user/WhitesElectronics In addition you can find more information on our website and forums. whiteselectronics.com forums.whiteselectronics.com Owner Information Serial Number: __________________________ (inside of battery compartment) Purchase Date: __________________________ (The date on the sales receipt) Dealer Name: _____________________________________________________________________ Address: ___________________________________________________________________... - Page 31 ® White’s Electronics, Inc. 1011 Pleasant Valley Road Sweet Home, OR 97386 USA Distribution: 1-800-547-6911 Factory: 1-541-367-6121 FAX: 1-541-367-2968 Web Site: http://www.whiteselectronics.com ©White’s Electronics, Inc. P/N 621-xxxx Printed in USA Rev. 1/2018...
