INJ-GE-30R
Technical Specifications
No. of Channels
1
Pass Through Data Rates
10/100/1000 Mbps half/full duplex
Power over Ethernet
Pin Assignment and Polarity: Both 1/2 (-), 3/6
Output
(+) and 7/8 (-), 4/5 (+)
Output Power Voltage
50V DC
Output Power: up to 30W (15.4W under
802.3af)
Input Power Requirements
AC 100-240V input, 0.5A
AC frequency: 50-60Hz
Connectors
Shielded RJ-45, EIA 568A and 568B
Network Cable Type
Outdoor type Shielded category 5 (or higher)
Dimensions
145mm x 60mm x 40mm
Mounting
Wall or shelf
Environmental Conditions
Operating Ambient Temperature: -10 to 40℃
Operating Humidity: Maximum 85%, Non-
condensing
Storage Temperature: -30 to 70℃
Storage Humidity: Maximum 95%, Non-
condensing
Indoor rated operating device
PoE compliance
IEEE 802.3af (PoE), IEEE 802.3at (PoE+)
Gigabit Power-over-Ethernet Injector
4
Gigabit PoE Injector
802.3af/802.3at compatible
INJ-GE-30R
www.robofiber.com
User Manual
Advertisement
Related Manuals for ROBOfiber INJ-GE-30R
Summary of Contents for ROBOfiber INJ-GE-30R
- Page 1 INJ-GE-30R Gigabit Power-over-Ethernet Injector Technical Specifications No. of Channels Pass Through Data Rates 10/100/1000 Mbps half/full duplex Power over Ethernet Pin Assignment and Polarity: Both 1/2 (-), 3/6 Output (+) and 7/8 (-), 4/5 (+) Gigabit PoE Injector Output Power Voltage 50V DC Output Power: up to 30W (15.4W under...
- Page 2 Description 4 x INJ-GE-30R The INJ-GE-30R PoE Injector is a single port mid-span PoE injector that offers a compact and cost effective, fully IEEE 802.3at/af compliant solution for remote powering of wireless LAN (WAN) access points, IP Security cameras, PoE cameras VoIP telephone and other low port density installations.
