8INJ-GE-125R
Injector
Technical Specifications
No. of Channels
8
Pass Through Data Rates
10/100/1000 Mbps half/full duplex
Power over Ethernet
Pin Assignment and Polarity: Both 1/2 (-), 3/6
Output
(+)
Output Power Voltage
50V DC
Output Power: up to 125W total (15.4W
under 802.3af per port)
Input Power Requirements
AC 100-240V input, 0.5A
AC frequency: 50-60Hz
Connectors
Shielded RJ-45, EIA 568A and 568B
Safety
overload, overcurrent and overvoltage
protection, EMI protection
Dimensions
185mm x 341mm x 44mm
Mounting
1RU, 19" rack mountable
Environmental Conditions
Operating Ambient Temperature: -10 to 40℃
Operating Humidity: Maximum 85%, Non-
condensing
Storage Temperature: -30 to 70℃
Storage Humidity: Maximum 95%, Non-
condensing
Indoor rated operating device
PoE compliance
IEEE 802.3af (PoE), IEEE 802.3at (PoE+)
Gigabit Power-over-Ethernet
4
8 channels Gigabit PoE
Injector (15W/port)
802.3af compatible
8INJ-GE-125R
www.robofiber.com
User Manual
Advertisement
Related Manuals for ROBOfiber 8INJ-GE-125R
Summary of Contents for ROBOfiber 8INJ-GE-125R
- Page 1 8INJ-GE-125R Gigabit Power-over-Ethernet Injector Technical Specifications No. of Channels Pass Through Data Rates 10/100/1000 Mbps half/full duplex Power over Ethernet Pin Assignment and Polarity: Both 1/2 (-), 3/6 Output 8 channels Gigabit PoE Output Power Voltage 50V DC Output Power: up to 125W total (15.4W under 802.3af per port)
- Page 2 125W total power switch monitor Description The 8INJ-GE-125R PoE Injector is an eight port mid-span PoE injector that 8INJ-GE-125R offers a cost effective, fully IEEE 802.3af compliant solution for remote powering of wireless LAN (WAN) access points, IP Security cameras, VoIP telephone and other PoE PD equipment.
