- Page 1 GAS COOK TOP Installation - Use - Maintenance Gas Cook top models: 60cm and 90cm Gas Cook tops 539.07.531 539.07.241 539.07.253...
- Page 2 Dear customer, We thank you and congratulate you on your choice. This new carefully designed product, manufactured with the highest quality materials, has been carefully tested to sa- tisfy all your cooking demands. We would therefore request you to read and follow these easy instructions which will allow you to obtain excellent results right from the start.
-
Page 3: Installation
INSTRUCTIONS FOR USE FOR VITROCERAMIC HOBS SEE ADDITIONAL INSTRUCTIONS Installation All the operations concerned with the installation must be carried out by authorised personnel, in terms with the standards in force. For specific instructions, kindly read the part titled, Instructions for the installer. Gas burners (Fig. - Page 4 Fig. 2 1 2 3 4 5 1 2 3 4 5 Fig. 2...
- Page 5 Fig. 2 1 2 3 4 FRONT FIXING REAR FIXING Fig. 2...
- Page 6 1 2 3 4 5 6 Fig. 2 Maintenance Gas/Electric Prior to any operation, disconnect the appliance from the electrical system. For long-life to the equipment, a general cleaning operation must take place periodically, bearing in mind the following: • the glass, steel and/or enamelled parts must be cleaned with suitable non-abrasive or corrosive products (found on the market).
- Page 7 Fig. 3 WARNING CRYSTAL HOBS ‘A’ ‘B’ DO NOT TIGHTEN SCREW EXCESSIVELY ONE TURN MAX WILL BE SUFFICIENT AFTER CORRECTLY FITTING SHAFT INTO PLACE AS SHOWN IN THE PICTURE ENSURE THAT THE SUPPORTING SURFACE IS PERFECTLY EVEN FIT THE APPROPRIATE EXPANDED SEAL CRYSTAL HOBS MUST NOT BE SUBJECTED TO STRAINS CAUSED BY UNEVEN SUPPORTING SURFACES...
-
Page 8: Instructions For The Installer
INSTRUCTIONS FOR THE INSTALLER Installation These Instructions are for authorised personnel, as a guide to the installation, adjustment and maintenance, according to the laws and standards in force. Any of these operations must always be carried out when the appliance has been disconnected from the electric system. -
Page 9: Abnormal Operation
position and observe stability of the flame for each burner individually and concurrently. When satisfied with the hotplate, please instruct the user on the correct method of opera- tion. In case the appliance fails to operate correctly after all checks have been carried out, refer to the authorised service provider in your area. abnormal operation Any of the following are considered to be abnormal operation and may require servicing: Yellow tipping of the hob burner flame. Sooting up of cooking utensils. Burners not igniting properly. Burners failing to remain alight. Burners extinguished by cupboard doors. Gas valves, which are difficult to turn. In case the appliance fails to operate correctly, contact the authorised personnel in your area. data label The Data Label is located on the bottom cover of the appliance. Where the bottom cover is not visible in the installed position, a duplicate Data Label is supplied to ad here in an accessible area adjacent to the appliance. Ensure that the available gas supply matches the gas types listed on the Data Label. Electrical connection (Fig. 5) Prior to carrying out the electrical connection, please ensure that: • the plant characteristics are such as to follow what is indicated on the matrix plate placed at the bottom of the working area;... -
Page 10: Cable-Clamp
CABLE-CLAMP Fig. 5 Adaptation to various types of gas (Fig. 6-7) Should the appliance be pre-set for a different type of gas than that available, proceed as follows: • replace the injectors (Fig. 5) with the corresponding type of gas to be used (see table "Uses characteristics"). -
Page 11: Gas Burners
USER CHARACTERISTICS GAS BURNERS FEED BURNER Ø INJECTORS CONSUMPTION TYPE PRESSURE kPa 1/100 mm MJ/h fast 11.7 Natural gas semifast auxiliary Wok (C3) 13.0 fast 11.9 Universal LPG semifast G30/G31 2.75 auxiliary 12.0 Wok (C3) - Page 12 Warranty Note: Should you require warranty service please contact Häfele on 1800 755 890 or by emailing info@hafele.com.au. Please refer to the warranty card that came with appliance for the full terms and conditions of this warranty. The manufacturer declines all responsibility for possible inaccuracies contained in this pamphlet, due to printing or copying errors.
