SILENT AUTO GLIDING
DELUXE BASSINET
701305-2282
ASSEMBLY INSTRUCTIONS
WARNING:
CHOKING HAZARD
Adult assembly required because of
small parts. Keep assembly parts out
of reach of children under 3 years.
REQUIRED: 3 "C" Alkaline Batteries for battery compartment (not included),
Phillips Screwdriver (not included)
IMPORTANT: Read all instructions before assembly and use of the product. Keep the
instructions for future reference.
Customer Service
Tel. (800) 377-3777
www.DeltaChildren.com I Customer Service: 1-(800)-377-3777
Styles and colors may vary
DCP10202017-V2
www.DeltaChildren.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Simmons 701305-2282
Summary of Contents for Simmons 701305-2282
- Page 1 SILENT AUTO GLIDING DELUXE BASSINET 701305-2282 Styles and colors may vary ASSEMBLY INSTRUCTIONS WARNING: CHOKING HAZARD Adult assembly required because of small parts. Keep assembly parts out of reach of children under 3 years. REQUIRED: 3 “C” Alkaline Batteries for battery compartment (not included), Phillips Screwdriver (not included) IMPORTANT: Read all instructions before assembly and use of the product.
- Page 2 Check before assembly and periodically during use. Contact Simmons Customer Service Department at 1-800-218-2741 (8:00am ~ 4:30pm PST) for replacement parts, repair or instructions.
- Page 3 Parts IMPORTANT! Please remove all parts from the package and identify them before assembly. Frame Part # 50281 Back Front Base Leg (X1) Base Leg with Wire Connection (X1) Part # 50283 (For power housing and power cord attachment) Part # 50282 Power Housing (X1) Swing Arms - (X2 (Needs 2 - M6 - 3.5cm -...
- Page 4 Parts IMPORTANT! Please remove all parts from the package and identify them before assembly. Locking Casters (X4) Part # 50292 Toys Part # 50294 Mobile Wire with Connector Top Base Leg Connection Cord Power Housing Connection Cord Mobile arm Part # 50293 Power cord Part # 50295 Canopy...
- Page 5 Bottom Base Assembly M6 Screw - 1.7cm - x2 - Actual Size Fabric Storage Liner Slide Support Tube Into Fabric Storage Liner Fabric Storage Liner Back Base Leg Support Tube Fabric Storage Liner Facing Upward • Locate the two (x2) support tubes, and the fabric storage liner. •...
- Page 6 • Insert front base leg with wire connection into fabric storage liner. M6 Screw - 1.7cm - x2 - Actual Size Storage Fabric Front Base Leg With Wire Connection Base Legs Fully Attached To Support Tubes Fully Assembled Bottom Base Back Base Leg And Front Base Leg With Wire Connection Fully Attached...
- Page 7 Attaching Power Housing to Front Base Leg M6 Screw - 3.5cm - x2 - Actual Size M6 Screw Power M6 Screw insert Housing insert Magnet THIS SIDE UP FACING INWARD Front Base Leg With Wire Connection Power Housing Nub Clicked into Base Leg With Wire Connection Attach (x2) M6 Screws Power Housing Fully Attached To Front...
- Page 8 Top Frame Assembly Support Legs • Align the swing arm with the support leg • Align the second swing arm with the opposite support leg NOTE: You may need the help of another adult to help steady all parts for assembly.
- Page 9 Top Frame and Bottom Base Frame Attachment M6 Screw - 1.7cm - x4 - Actual Size Top Frame Bottom Base Frame Attach (x2) M6 Screws On Both Sides Connecting The Top Frame and Bottom Base Frame Top Frame and Bottom Base Frame •...
- Page 10 Mattress Support Board Assembly M6 Screw - 1.7cm - x4 - Actual Size BACK & FRONT FRONT FRONT Mattress Support Top View Of Bassinet Frame Board *CORRECT PLACEMENT OF MATTRESS SUPPORT BOARD* Back of Front of mattress mattress board board Mattress Board BACK FRONT...
- Page 11 Locking Casters Assembly Complete Frame Assembly BACK • Turn the assembly downward, with the bottom base facing upward. FRONT • Turn the assembly upright. • Check to be sure the legs are secure. While gently holding the base down, pull up on the top rail. The complete frame assembly should remain intact.
- Page 12 Consumer Information WARNING Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE. • A mobile is intended for visual stimulation and is not intended to be grasped by the child. • From birth to 5 months. •...
- Page 13 Battery Safety Information Battery Installation 1.5V x 3 “C” In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: Battery Compartment Cover • Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).
- Page 14 Mobile Arm Unit Operation Rotate Mobile Toys Twinkling Lights Music Music Volume AUTO Switch Auto Glide GLIDE Night Light Music Volume Mobile Functions Switch On / Off Mobile Functions On/Off Switch • Push the Mobile Functions On/Off button at the base of the mobile arm to turn on power.
- Page 15 Attaching Fabric Mobile Arm Assembly Screws Mobile Arm FRONT • Locate the fabric liner. NOTE: Side of the frame has the mobile arm attachment holes and the front of the liner has the warning label. • Remove two (x2) pre-installed screws from mobile arm. •...
- Page 16 Mattress Pad With Sheet • Place the sheet over the mattress pad. • Place the covered mattress pad into the liner. Frame Canopy Ratchet Hook and Loop Patch • Position the canopy over the top end of the bassinet opposite the warning label.
- Page 17 Wire Connection Assembly M obile Ar m Wir e Mobile Arm Wire with Conne ct or With Connector Bat t er y Wir e Top Base Leg Top Base Leg Battery Wire With Connector Connection Cord with Conne ct or Conne ction Cor d Power Housing Magnet Wir e...
- Page 18 Locking/Unlocking Bassinet Lock Arm Lock Peg • Fit the mobile to the mobile arm. Push the mobile up firmly. HINT: To disassemble the mobile for storage, press the tab on the mobile arm and pull the mobile down. • To lock the gliding mechanism, rotate the red lock arm clock wise and snap the lock arm onto the lock peg.
- Page 19 Care • The frame, mattress pad, storage basket, canopy, mobile and mobile arm may be wiped clean using a mild cleaning solution and a damp cloth. Do not use bleach. Do not use harsh or abrasive cleaners. Rinse clean with water to remove residue. Do not immerse the frame. •...
- Page 20 www.DeltaChildren.com...
