Ozito PWB-2800 Instruction Manual

OPERATION

TROUBLESHOOTING

Detergent Siphon

Most cleaning tasks can be completed with the pressure washer
alone. For others, it is advantageous to use detergent. Use only liquid Symptom Possible Cause
detergents designed specifically for use with pressure washers.
Engine wil not Low-oil shutdown Fill engine with oil
1. Attach siphon
start or stops
On/Off Switch not in Turn switch "ON"
tube to the while operating
"ON" position
detergent siphon
Pressure built up in Squeeze trigger while starting
connector on the
hose
pump.
Engine is Nozzle partially Clean Nozzle
overloaded blocked
Pressure Bypass valve blocking Clean the bypass valve
increases when
gun is locked
2. Ensure the strainer at the end of the siphon tube is not clogged or Engine is running Tap supplying water Turn on tap
obstructed in any way. but pump won't is off
build maximum
Inadequate water Provide a minimum of 15L/min
3. Insert the siphon tube pressure or has
supply at 20 PSI
to the bottom of the irregular pressure
Kink in garden hose Straighten garden hose
detergent container
Spray Nozzle worn or Replace Nozzle
damaged
Air in pump Run with Gun on & Spray
Nozzle removed until a steady
stream of water is released
4. Install the
black spray Pump inlet or outlet Clean the pump inlet or outlet
blocked
nozzle onto
the lance.
No intake of Siphon tube not Push tube firmly onto
chemicals securely inserted into connector
unit
Tube cracked or split Replace tube
5. The detergent will automatically mix with the water and discharge
through the nozzle. Wrong Spray Nozzle Switch to low pressure (Black)
Spray Nozzle
6. After using the detergent siphon, remove siphon tube from soap
Trigger will not Gun safety lock Release safety lock
container, and place into a container of clean water to flush out
move engaged
any residual soap.
Rough/vibrating Pump inlet restriction Check system for stoppages,
CAUTION: operation with air leaks, correctly sized inlet
USE ONLY LIQUID DETERGENTS DESIGNED
pressure loss plumbing to pump
SPECIFICALLY FOR USE WITH PRESSURE WASHERS.
ONLY USE CHEMICALS COMPATIBLE WITH THE ALUMINUM Air in pump/water Check inlet lines for restrictions
and or proper sizing
AND BRASS PARTS. POWDERED SOAPS MAY CLOG
THE INJECTION SYSTEM. ALWAYS USE CHEMICALS
ACCORDING TO THE MANUFACTURERS DIRECTIONS.

SPARE PARTS

CLEANING OF PAINTED SURFACES
Application of Soap
• Wetting the surface first is not recommended, it dilutes the detergent and High Pressure Hose SPPWB2800-07
reduces its effectiveness.
High Pressure Gun & Lance SPPWB2800-36
• Apply horizontally from side to side starting from bottom to avoid streaking.
Spray Nozzle Set SPPWB2800-42
• Avoid working on hot surfaces or in direct sunlight to minimize the chances
of the soap damaging painted surfaces. Spare parts can be ordered from the Special Orders Desk at your local
• Damage may occur to painted surfaces if the soap is allowed to dry on the Bunnings Warehouse.
surface. For further information, or any parts not listed here, visit www.ozito.com.
• Hold the nozzle far enough away from surface to prevent damage to the au or contact Ozito customer service
surface. Australia 1800 069 486
• Allow soap to remain on the surface for a short time before rinsing. New Zealand 0508 069 486
Rinsing E-mail: enquires@ozito.com.au
Rinse with clean water under high pressure. On a vertical surface, first rinse
from the bottom up, then rinse from top down. Hold nozzle minimum of 150mm

CARING FOR THE ENVIRONMENT

(6") from the work surface at a 45° angle using the flat spray.
DESCRIPTION OF SYMBOLS
Petrol tools that are no longer usable should not be disposed
of with household waste but in an environmentally friendly way.
Please recycle where facilities exist. Check with your local council
/min Revolutions or authority for recycling advice.
Hp Horse power
reciprocation per minute
Recycling packaging reduces the need for landfill and raw
l Litres dB Decibel level
materials. Reuse of recycled material decreases pollution in the
psi Pounds per square inch BAR Pressure rating environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
Read instruction manual Warning
Hot Surface Do not expose to rain
cc Cubic Centimeters (the standard measure of displacement in Europe
and Asia)
Regulator compliance mark
MAINTENANCE
Recommended Check & Maintenance Chart
Corrective Action
Every Operation/ After 20 Hours
Time
Item
Daily or 1 Month
Inspect and Tighten All Nuts and Bolts
Engine Oil
(top up if required and (only required after first
check for leaks) 20 hours / 1 month of use)
Air Filter
(Frequency depends on pump location. i.e. High dust environment every 10 Hrs)
Fuel Tank
Fuel Tank Nozzle
Fuel lines
(check for leaks)
Spark Plug
Adjust Inlet and Exhaust Valves
(required after first
20 hours / 1 month of use)
Remove Carbon in Combustion CWhamber Chamber
Check Change Clean * To be performed by qualified service centre
Storing the Water Blaster Removing, installing and inspecting the spark plug
When the water blaster is not being used or is being stored for a extended 1. Remove the spark plug lead.
period of time follow these instructions:
1. Replenish engine oil to upper level.
2. Drain fuel from fuel tank, fuel line, fuel valve and carburetor.
3. Pour about one teaspoon of engine oil through the spark plug hole. Pull
the recoil starter slowly until you feel increased pressure which indicates
the piston is on its compression stroke. Leave it in this position. This
closes both the intake and exhaust valves to prevent the inside of the
cylinder from rusting.
2. Remove the spark plug using the spanner
4. Remove breather and refit hex bolt.
supplied.
5. Cover the pressure washer and store in a clean, dry place that is well
ventilated and away from open flame or sparks.
3. Clean the electrode with a metal brush and
remove any carbon build-up.
Changing the Oil
The water blaster is shipped without oil. Before starting ensure an oil
inspection is conducted.
After the first 20 hours of use the engine oil must be replaced, and then
4. Using a thickness gauge, check the spark plug
every 50 hours after that.
for the correct gap
Always use high quality oils, choosing their viscosity grade according to
center electrode and side electrode.
the operating temperatures.
Note: It is recommended that SAE 10W-30 (multi viscosity) oils are used
5. Refit the spark plug and tighten.
at temperatures from 5 to 35ºC.
1. Place the water blaster on a level surface.
Spark plug types:
2. Clean around the oil fill plug.
LG F7RTC or equivalent.
3. Remove the oil fill plug from the engine.
4. Fill the engine with SAE 10W-30 oil up to the maximum level.
Cleaning the Water Blaster
5. Replace oil fil plug.
Use a moist cloth to wipe down the water blaster. Allow to dry thoroughly
before storing in a dry location that is protected from bad weather
Replacing the Air Filter
conditions.
1. Release the two clips securing the filter cover.
Cleaning the Nozzle
1. Shut off the pressure washer and turn off the water supply.
2. Pull trigger on the gun handle to relieve any pressure.
3. Disconnect the lance from the gun.
4. Remove any obstructions with the cleaning needle provided and back
flush with clean water.
2. Remove and inspect the filter. It must be intact
5. Direct a water supply into the end of the lance for 30 seconds to
and clean, if not clean or replace the filter.
back flush loosened particles.
6. Reconnect the lance to the gun.
3. Replace the filter and filter cover.

SAFETY INSTRUCTIONS

RISK OF EXPLOSION OR FIRE

What can happen:
• Spilled petrol and its vapours can become ignited from cigarettes, sparks, electrical
arcing, exhaust gases and hot engine components such as the muffler.
After 50 Hours After 100 Hours
• Heat will expand fuel in the tank which could result in a fire.
or 3 Months or Yearly
• Operating the tool in an explosive environment could result in a fire.
• Muffler exhaust heat can damage painted surfaces, melt any materials sensitive
to heat (such as siding plastic, rubber or vinyl) and damage live plants. Keep hot tool
away from other objects.
• Improperly stored fuel could lead to accidental ignition. Fuel improperly secured
could get into the hands of children or other unqualified persons.
How to prevent it:
• Shut off engine and allow it to cool before adding fuel to the tank.
• Use care when filling the tank to avoid spilling fuel. Move tool away from fuelling
area before starting engine.
• Keep maximum fuel level 20mm below top of tank to allow for expansion.
• Operate and refuel in well ventilated areas free from obstructions.
(change if neccesary)
• Store fuel in a approved container (AS/NZS 2906-1999) for petrol. Store in a secure
location away from the work area. Make sure the container is clearly marked "fuel".
*
*

RISK TO BREATHING

What can happen:
* • Breathing exhaust fumes can cause serious injury or death.
How to prevent it:
• Operate tool in a well ventilated area. Avoid enclosed areas.
• Never operate unit in a location occupied by other people or animals.

SAVE THESE INSTRUCTIONS

1) Work area
a) Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate petrol tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating a petrol tool.
Distractions can cause you to lose control.
2) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating
a petrol tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol, or medication. Amoment of inattention while operating power tools may
result in serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such as a
dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate

WATER BLASTER SAFETY INSTRUCTIONS

(0.7 ~ 0.8mm) between the
RISK OF UNSAFE OPERATION
What can happen
• Unsafe operation of your water blaster could lead to serious injury or death to you or others.
• The spray gun/wand is a powerful cleaning tool that could look like a toy to a child.
• Reactive force of spray results in gun/lance movement, potentiolly causing the operator to slip, fall
or misdirect the spray. Improper control of gun/lance can result in injuries to self, others and property
damage.
How to prevent it
• Become familiar with the operation and controls of the pressure cleaner.
• Keep children away from the pressure cleaner at all times.
• Never modify or remove the safety features of this product.
• Do not operate the machine with missing, broken or unauthorized parts.
• Never leave wand unattended while unit is running.
• Keep work area free of obstacles.
• Stand on stable surface and grip gun/lance firmly. Expect the gun to kick back when engaged
1) Never refuel while engine is running or hot. Fuel spilled on a hot engine could result in a fire or
explosion.
2) Use caution when handling petrol. Refuel in well-ventilated area. Do not overfill fuel tank and do
not spill fuel. Make sure tank cap is closed properly. Petrol is extremely flammable and is explosive
under certain conditions.
3) Never run the engine in an enclosed or confined area. Exhaust contains poisonous carbon
monoxide gas;exposure may cause loss of consciousness and may lead to death.
4) Do not use to pump flammable or explosive liquids such as gasoline, fuel oil, kerosene,solvents or
thinners. Pump should only be used with liquids compatible with water blaster component materials.
Failure to follow to this warning can result in serious personal injury, death and/or property damage.
5) Water blaster must be located on a solid level surface. Pump could tip or fall causing serious
injury.
6) Do not hold or suspend pump by means of a discharge pipe. Pipe could break or come loose.
PETROL
conditions will reduce personal injuries.
c) Remove any adjusting key or wrench before turning the tool on. A wrench or a
WATER
key that is left attached to a rotating part of the petrol tool may result in personal injury.
d) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the petrol tool in unexpected situations.
BLASTER
e) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
f) If devices are provided for the connection of dust extraction and collection 5.5hp - 2800psi
facilities ensure that these are connected and properly used. Use of these devices
can reduce dust-related hazards.
INSTRUCTION MANUAL
3) Petrol tool use and care

SPECIFICATIONS

a) Do not force the petrol tool. Use the correct petrol tool for your application.
The correct petrol tool will do the job better and safer at the rate for which it was
designed. Engine Power: 5.5hp
b) Do not use the petrol tool if the switch does not turn it on and off. Any petrol Engine Displacement: 163cc
Engine Type: 4-Stroke OHV
tool that cannot be controlled with the switch is dangerous and must be repaired.
Working Pressure: 145bar/2100psi
c) Turn tool off completely before making any adjustments, changing
Maximum Pressure: 193bar/2800psi
Accessories, or storing petrol tools. Such preventive safety measures reduce
Flow Rate: 8L/min
the risk of starting the petrol tool accidentally.hair can be caught in moving parts.
Fuel Tank Capacity: 3.6L
d) Store idle petrol tools out of the reach of children and do not allow persons Weight: 33kg
ozito.com.au
unfamiliar with the petrol tool or these instructions to operate the petrol tool.
Petrol tools are dangerous in the hands of untrained users.
e) Maintain petrol tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the petrol tool's
operation. If damaged, have the petrol tool repaired before use. Many accidents are
caused by poorly maintained petrol tools. 1
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the petrol tool, accessories and tool bits etc., In accordance with these
instructions and in the manner intended for the particular type of petrol tool,
taking into account the working conditions and the work to be performed. Use
of the petrol tool for operations different from intended could result in a hazardous
situation.
h) This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
i) Children should be supervised to ensure that they do not play with the
appliance.
4) Service
IN ORDER TO MAKE A CLAIM UNDER THIS
a) Have your petrol tool serviced by a qualified repair personnel using only
identical replacement parts. This will ensure that the safety of the petrol tool is WARRANTY YOU MUST RETURN THE PRODUCT
maintained.
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
7) Be careful not to touch the muffler while it is hot. To avoid severe burns or fire hazards, let the
engine cool before transporting or storing it indoors. The muffler becomes very hot during operation Australia 1800 069 486
and remains hot for a while after stopping the engine. Exhaust may contain chemicals that may
New Zealand 0508 069 486
cause cancer orreproductive harm.
WARNING!: This appliance has been designed for use with the cleaning agent supplied or
recommended by the manufacturer. The use of other cleaning agents or chemicals may adversely
TO ENSURE A SPEEDY RESPONSE PLEASE
affect the safety of the appliance.
WARNING!: High pressure jets can be dangerous if subject to misuse. The jet must not be directed HAVE THE MODEL NUMBER AND DATE OF
at persons, live electrical equipment or the appliance itself.
PURCHASE AVAILABLE. A CUSTOMER SERVICE
• Do not direct the jet against yourself or others in order to clean clothes or foot-wear.
REPRESENTATIVE WILL TAKE YOUR CALL
• High pressure cleaners shall not be used by children or untrained personnel.
• To ensure appliance safety, use only original spare parts from the manufacturer or approved by
AND ANSWER ANY QUESTIONS YOU MAY
the manufacturer.
HAVE RELATING TO THE WARRANTY POLICY
WARNING!: High pressure hoses, fittings and couplings are important for the safety of the appliance.
Use only hoses, fittings and couplings recommended by the manufacturer.
OR PROCEDURE.
• Do not use the appliance if a supply cord or important parts of the appliance are damaged,
e.g. safety devices, high pressure hoses, trigger gun.
• Where gas or liquid fuel are used ensure the specification of the fuel is correct and adhere to the
following warnings:
WARNING!: Incorrect fuels shall not be used as they may prove hazardous.
• For oil fired appliances without a primary safety control, the statement:
• This appliance must be attended during operation.
• The intended use of the appliance.
OZITO
Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
WHAT'S IN THE BOX
Petrol Water Blaster
8m High Pressure Hose
Gun & Lance
Spray Nozzles
Solid Rubber Wheels
Spark Plug Spanner,
Screwdriver, Cleaning
Needle & Breather
PWB-2800

WARRANTY

The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
1 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 12 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: seals, o-rings,
filters, fuel & oil hoses.
WARNING
The following actions will result in the warranty being void.
• Professional, Industrial or high frequency use.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
1212
