TECC Titus Nano User Manual

BATTERY OPERATION:

Power on and off: Press the power button 5 times in quick succession, the power
button light will flash 5 times to indicate Titus Nano is ready for use. to turn off, press
the power button 5 times in quick succession.
Vaping: Press the power button as you inhale, release the button when you stop
inhaling. When the power button is held down, the light will be on.

CHARGING:

The battery can be recharged using the supplied USB cable plugged into a dedicated
USB port or wall adaptor. The power button light will flash white 5 times and illuminate
red until charging is complete.

BATTERY DISPLAY FUNCTION:

The power button light illuminates whilst being pressed, and on release flashes at
increased frequency as the battery becomes discharged.
Battery charge remaining
60%-100%
30%-59%
10%-29%
0-9%

TO FILL THE TANK:

• Invert the complete device and unscrew the battery from the tank.
• Fill the tank up to but not beyond the level of the central tube taking care to avoid
liquid entering the central tube.
• Attach the battery to the inverted tank.

ATOMIZER HEAD REPLACEMENT:

• Invert the complete device and unscrew the battery from the tank.
• Unscrew the atomizer head and remove from the integrated battery base.
• Screw the new CL atomizer head into place and firmly tighten.
• Refit the battery to the inverted tank.

ADJUSTING ATOMIZER AIRFLOW

Rotate the ring on the atomizer base to cover/reveal the airflow holes to increase/
decrease the airflow to the atomizer.
TECC_Titus_Nano_Manual.indd 1
USER GUIDE
Stays lit for 6 seconds
Slowly flashes for 6 seconds
Moderately flashes for 6 seconds
Flashes repeatedly for 6 seconds
03/01/2017 23:06
