iGuard IP-390E Installation Manual

A. Package Contents ..........................................................
A standard package should contain the following items. If
any of these items is missing, please contact your dealer.
 iGuard IP-390E Wireless IP Camera
 Detachable WiFi Antenna
 DC 12V Power Adaptor.
 iGuard Utility CD
 This Quick Installation Guide
B. Installation Requirements...............................................
1 Host PC
 CPU: Pentium III 450 MHz and above
 Memory 256 MB and above
 VGA card resolution at least 800 x 600
 CD ROM Drive
 10-100 Network Card
 Java enabled and compliant Web browser (IE 5.0 and
above)
2 Wireless Router/AP
 A wireless router that supports Port Forwarding
 Login credential for the wireless router/AP.
3 Internet Connection for remote monitoring
 Broadband internet connection with a minimum of 384K
bandwidth
 HTTP and UTP protocol enabled
4 Basic Networking Knowledge
C. Hardware Installation......................................................
1. Make sure an A/C outlet is available where the camera will
be mounted, or a 12v DC line is installed to the camera.
2. Before the camera can be accessed wirelessly, it has to be
configured through its LAN interface. We recommend
pre-program the network setting before the camera is
physically installed.
3. You can adjust the focal distance by removing the front
cover.
4. Under some extreme light conditions or specific coverage
requirement, you may need to use to a lens of different
focal length and/or adjustable iris settings (not supplied)
D. Software Installation ....................................................
1. Place the iGuard Utility CD in the CDROM, the installation
program shall start automatically.
2. Install the iGuard Utility and iGuard View programs
according to the instruction on the computer screen
3. Once installation is completed, click the ' iGuard Utility' on
the Start/Program menu to launch the program.
4. The iGuard utility will search for any iGuard unit on the
local network and list them on the right side of window.
