ring RAC750 Operating Instructions

Caution
Before operating this compressor, please read the instruction leaflet and retain for future reference. Operate only in
accordance with the instructions
When using the compressor ensure you are parked in a safe location, off the road with the handbrake fully engaged.
Ensure your personal safety is not at risk. The Compressor must not be used when the vehicle is moving. Never
leave the compressor unattended.

Power supply required 230v AC

This compressor is designed for occasional use. Operation over an extended period may overheat the unit
and damage the compressor. It should not be used continuously for more than 15 minutes. After 15
minutes, turn it off and let it cool for 15 minutes before resuming.

If the compressor is making an abnormal sound, or the temperature of the unit is too high, turn the power
off immediately and let it cool for at least 15 minutes before resuming operation.

Do not use the air compressor on high pressure tyres such as those used on commercial vehicles,
agricultural or specialist vehicles.

When the air compressor is in use do not direct the air pressure towards a person.

Store in a dry place.

Do not position close to inflammable liquids or gas.

Operate only in dry conditions.

Only use the adapters supplied with the device.

The gauge on this compressor is for guidance only. Check pressure with a known accurate gauge.

Inspect before each use. Do not use the compressor if any of the components are damaged.

Do not kink or block the air hose while the compressor is working.

To Inflate Vehicle Tyres


Insert the fused plug into the 230v mains socket

After removing the dust caps connect the air hose to the tyre valve stem and push down with your
thumb the locking lever connector. Ensure the connector is securely connected (See Fig 1, 2 )

Push the ON / OFF button to switch the compressor on.

When the desired pressure is reached push the ON / OFF button to switch off.

Release the locking lever and remove the air line from the tyre valve and replace the dust caps,
remove the 230v plug from the mains socket.
Fig 1
Push
RAC750 Operating Instructions
230v Mains Powered Rapid Air Compressor
Fig 2
