<ATD100B (Desktop Reader) Quick Guide>

Product Composition

ATD100B Main Body

Name of each part

1 Reset Button
2 Communication Mode
Switch Button
3 Status indicator
4 Charge Indicator
5 Power Button & Power Indicator
6 UHF
Power ON / OFF & Lamp indication
Press the power button
for 2 seconds to turn on
the power.

Switch to Bluetooth / USB Communication Mode

Push the Communication Mode
Switch Button, the Communication
Mode Switches sequentially.
USB
BT
H
S
H
RJ 9 Gender Connector
Power ON
(Green LED ON)
Power OFF
(Lamp OFF)
S
1
3
4
5
POWER
Bluetooth Mode

USB
BT
H
S
H
S
SPP (Red LED ON)

USB
BT
H
S
H
S
HID (Blue LED ON)
RJ9 USB Sync Cable
CHARGE
Charging
(Red LED ON)
Charging
Complete
(Green LED ON)
USB Mode
USB
H
S
H
SPP (Red LED ON)
USB
H
S
H
HID (Blue LED ON)
2
3
6
BT
S
BT
S
