LDA Audio Tech VCC-64 User Manual

Volume and channel controller
Hide thumbs Also See for VCC-64:

Advertisement

Quick Links

User's Manual
VCC 64 – Volume and Channel
Controller
Model: VCC 64

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-64 and is the answer not in the manual?

Questions and answers

Summary of Contents for LDA Audio Tech VCC-64

  • Page 1 User's Manual VCC 64 – Volume and Channel Controller Model: VCC 64...
  • Page 3: Table Of Contents

    Index 1. SAFETY INSTRUCTIONS......................1 2. DESCRIPTION..........................2 2.1 FUNCTIONING........................2 2.2 CONNECTION TO THE SYSTEM..................4 3. PROBLEM SOLVING:........................7 3.1 The screen is blank........................7 3.2 The number of sources and volume does not appear on screen..........7 4. MAINTENANCE INSTRUCTIONS....................7 5. TECHNICAL SPECIFICATIONS....................8 Index of charts Chart 1: Active mode..........................3 Chart 2: Active mode display.......................3 Chart 3: Connection..........................6...
  • Page 4: Safety Instructions

    19. If the equipment has obvious signs of damage. 20. Disconnect the audio inputs and outputs while making connections. Be sure to use the proper cables to make the connections. LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...
  • Page 5: Description

    MANUAL DE USUARIO – VCC 64 2 DESCRIPTION The VCC-64 allows up to 64 programmable channels and volume control (0-9). Usually installed in local zone and connected via bus to the system, it offers source selection, volume control and lock function.
  • Page 6: Chart 1: Active Mode

    The display will show the change in the number of the source. The number displayed corresponds to the number of the source in the PA system. The audio source in the zone of the VCC-64 can be asigned remotely from the main PA system's management or locally from the VCC-64.
  • Page 7: Connection To The System

    MANUAL DE USUARIO – VCC 64 last push of a button. To activate again the VCC-64, press CH+ and then CH-. The lock indicator will disappear from the display. 2.2 CONNECTION TO THE SYSTEM 2.2.1 DATA BUS and POWER SUPPLY The VCC-64 has two poles for data connection through RS-485 protocol.
  • Page 8 The VCC-63 has a DIP-Switch to configure the address in the bus RS-485. Every controller assigned to the same zone, should have the same address configuration. For different zones different address should be assigned. LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...
  • Page 9: Chart 3: Connection

    This way the unit located closer to the system will be connected to the interface, and from this unit to the next VCC-64. The last VCC-64 in the bus will not have any connection to a consecuent device.
  • Page 10: Problem Solving

     Do not use aerosol sprays, solvents or abrasives.  Do not spray any cleaning products directly on the device. Operations:  Wipe the system with a damp cloth. LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...
  • Page 11: Technical Specifications

    62mm x 70mmx 35mm / 2,44” x 2,75 x 1,38 Dimensions (HxWxD) 86mm x 86mm x45mm / 3,38 x 3,38 x 1,77 Chart 5: Technical specifications LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...
  • Page 12 MANUAL DE USUARIO – VCC 64 LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...
