Heateflex FLUIDIX Manual

Ultra-pure d.i. water heating system

Advertisement

Quick Links

405 E. Santa Clara St.
Arcadia, CA 91006-7218
Tel: (626) 599-8566 Fax: (626) 599-9567
FLUIDIX
SERIES
Ultra-Pure D.I. WATER
HEATING SYSTEM
World Leaders in Ultra-Pure Heating
Revision 10
www.heateflex.com
01/17/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLUIDIX and is the answer not in the manual?

Questions and answers

Summary of Contents for Heateflex FLUIDIX

  • Page 1 405 E. Santa Clara St. Arcadia, CA 91006-7218 Tel: (626) 599-8566 Fax: (626) 599-9567 FLUIDIX SERIES Ultra-Pure D.I. WATER HEATING SYSTEM World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 2 405 E. Santa Clara St. Arcadia, CA 91006-7218 Tel: (626) 599-8566 Fax: (626) 599-9567 World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 3 405 E. Santa Clara St. Arcadia, CA 91006-7218 Tel: (626) 599-8566 Fax: (626) 599-9567 INDEX Section I – Fluidix Instruction Manual  Table of Contents  Preface  Theory of Operations  System Control  Safety Systems  Preventive Maintenance and Servicing ...
  • Page 4: Table Of Contents

    4.4.1 Loss of D.I. Water Line Pressure/Auto Isolation 4.5 Shellside/Vessel Flooding 4.6 Water Leak 4.7 Summary of Alarm Conditions and System Reponses 4.8 Use of Emergency Off (EMO) Switch 4.9 Door Interlock World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 5 C. Hot Valve Over Temperature Alarm D. Hot Valve Over Temperature Diagnostic Information E. Low Flow Rate Alarm F. Low Flow Rate Diagnostic Information G. Low Process Pressure Alarm H. Low Process Pressure Diagnostic Information World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 6: Table Of Contents

    8.3 Pressure Relief Valve Calibration Procedure 8.4 Quality Control Documentation 8.4.1 Equipment Specifications 8.4.2 Fluidix PC Factory Default Parameters 8.4.3 Fluidix Ultra-Pure D.I. Water Heating System Quality Assurance Checklist 8.4.4 Freescale Fluidix Source Inspection 8.4.5 Flow Meter Configuration 8.5 Drawings 8.5.1 Facility Connections...
  • Page 7: Www.heateflex.com

    405 E. Santa Clara St. Arcadia, CA 91006-7218 Tel: (626) 599-8566 Fax: (626) 599-9567 Section I Instruction Manual World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 8: Www.heateflex.com

    405 E. Santa Clara St. Arcadia, CA 91006-7218 Tel: (626) 599-8566 Fax: (626) 599-9567 World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 9: Www.heateflex.com

    _________________________________________________________ 1.1 Introduction Thank you for your purchase of the Fluidix D.I. Water Heating System. We have strived in the engineering and redesign of the Fluidix D.I. Water Heating System to provide you with a product that has quality, performance, reliability, serviceability, and safety. Further, it is our goal to support you, the customer, and the equipment in as positive and professional a manner as possible.
  • Page 10: Www.heateflex.com

    Removal of this exchanger cover gives complete access to the Fluidix tube bundle for inspection of all its components. The vessel and its cover comprise a pressurized system where steam is introduced through a flanged inlet mounted at the side of the exchanger vessel, and where steam condensate is drained at the bottom.
  • Page 11: How The Process Is Heated

    D.I. water flow rate. D.I. water is heated in the Fluidix PFA heat exchanger to above the set point temperature and is continuously blended in varying ratios with ambient-temperature D.I. water by means of two PVDF mettering valves to yield the desired set point temperature.
  • Page 12: Ancillary Systems

    The Auto-Isolation System is used to close two isolation valves, one upstream and one downstream of the unit, based on various conditions which could lead to a potential contamination of the process water. These two ancillary systems are discussed in detail in Section 4.0 World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 13: System Control

    After a specified time interval, the temperature is checked again and the actuator moves another small World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 14: Main Menu

    Touching any area on the display will return the screen to normal, illuminated operation. Pictures of all touch-screen displays are shown in the appendix of this manual. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 15: Www.heateflex.com

    To enable or disable the alarm audio press the “ENABLE AUDIO” or the “DISABLE AUDIO” buttons respectively. Three other switches allow for convenient screen changes: “MAIN MENU”, “RECALIBRATION”, and “ALARM MENU”. The “ALARM MENU” button will illuminate when any alarm condition is present. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 16: Www.heateflex.com

    These recalibration instructions are also available on the touch screen. Press the “RECALIBRATION INSTRUCTIONS” button to bring up the screen with the instructions for setting up the Look-Up Table, which is detailed above. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 17: Alarm Menu And Alarm Screens

    HMI screens. The Diagnostic Information button can be pressed to display additional troubleshooting information related to the specific alarm condition in order to assist in troubleshooting the cause for the alarm or to change alarm parameters if available. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 18: Date And Time Set Up

    The remote control panel can be used for monitoring only by not apprising users of the remote panel of the “operational password” or “administrative password” thereby permitting access to all the screens but preventing any changes from being made. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 19: Input/Output Functions

    The Process Low Temperature, Vessel Flooding and Water Weak are considered non-critical alarms and warn of the alarm condition but does not affect the operation of the unit. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 20: Safety Systems

    _________________________________________________________ 4.1 Overview The Fluidix D.I. Water Heating System is provided with a full complement of automatic safety devices, which prevent a serious safety hazard irrespective of settings entered into the touch- screen user interface. The unit itself is also protected against damage under normal and abnormal operation as the highest temperature the equipment can “see”...
  • Page 21: Shellside (Steam) Safety Mechanisms

    15 psig maximum to prevent backflow to the process fluid should a leak occur. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 22: Tube Side (Process) Safety Mechanisms

    The Process Over-Temperature alarm set point and alarm delay can be modified on the Diagnostic Information screen of the Process Over-Temperature Alarm. The default Process Over-Temperature Alarm and Process Over-Temperature Alarm Delay set points are 95 C and 20 seconds respectively. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 23: Low Process Pressure

    Diagnostic Information screen of the Low Process Temperature Alarm. The default Low Process Temperature Alarm and Low Process Temperature Alarm Delay set points are 20 C and 20 seconds respectively. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 24: Hot Valve Over-Temperature

    20 seconds when this alarm is triggered. In addition this alarm condition needs to be reset manually by pressing the “ALARM RESET” button. The factory flow rate alarm set point will vary model to model. Please refer to Section 8.3.2 Fluidix PC Factory Default Parameters for the actual set point value.
  • Page 25: Www.heateflex.com

    When the Auto-Isolation System is set to the “Bypass” mode or when the Auto-Isolation System is active (system is in “Auto”) the D.I. water supply will cease to the Fluidix unit and be diverted thus isolating the system. This will provide a cold flow bypass to the process tools downstream of the unit.
  • Page 26: Shellside/Vessel Flooding

    This alarm condition has no affect on the operation of the unit and will not initiate Auto-Shutdown or Auto-Isolation. This alarm automatically resets once the condition disappears or is resolved. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 27: Www.heateflex.com

    Although password protected, any unauthorized changes to the PLC program will void the unit‟s warranty and will cause the user to hold harmless the manufacturer for any and all liability associated with the unit whatsoever. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 28: Door Interlock

    _________________________________________________________ 4.9 Door Interlock The Fluidix unit is equipped and protected with a door interlock switch. This switch will disable the unit from powering up when the control box is open. In addition, the unit will completely shut down (there will be no steam supply and D.I. water supply to the unit) when the door interlock switch is triggered.
  • Page 29: E. Santa Clara St

    D.I. water before mixing occurs. The cold valve input temperature value is displayed along with the process temperature value and steam temperature value on the Recalibration screen. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 30: Temperature Switches

    The next sections will detail the procedures for servicing these problems. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 31: Repairing A Tube Failure

    Note that on the four-head systems, the exchanger is divided into two separate tube bundles. The corresponding pipe manifolds (inlet to outlet) are inside to inside and outside to outside. The tubes are not always in exactly mirror-image World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 32: Repairing A Leaking Fitting

    If the tube will not pull up easily, DO NOT use force! Remove the nut from the pass-through fitting, pull the tube up and slide the Goretex seal down the tube or replace it as described below, then re-tighten the World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 33: The Mixing Valves

    Adjustment of the valves or actuator may alter the performance of the Fluidix unit or cause severe damage to components. Although no adjustment is required the valves are to be hand tightened only. The mettering valves are fitted with Chemraz O-rings.
  • Page 34: Installation And Start-Up Procedures

    The landing of the wires to the terminal strips in the two panels can be done by user personnel or by Heateflex Corporation personnel at the time of start-up. See the appendix for diagrams.
  • Page 35: Initial Heat-Up

    At this point remember that almost any unplanned event during the next steps can be immediately remedied by depressing the EMO switch, which will close the pneumatic steam World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 36: Www.heateflex.com

    In most cases the unit has been run at the factory using the customer provided data on the flow regimen and temperatures that the unit is intended for and the program parameters are already resident in the controller memory. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 37: Adjusting Temperature Control Parameters

    A ±2°C maximum variation from set point should be achievable if everything is adjusted to an optimal setting. If there is more deviation, contact the factory for assistance on further adjustments. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
  • Page 38: Servicing Policies

    This manual therefore explains several self-servicing procedures. How does this relate to warranty coverage? It is Heateflex Corporation‟s policy that while we do promote self-servicing for a good reason, we reserve the right to expect quality workmanship on the customer's behalf. We also reserve the right to consequently evaluate the system or any components therein prior to providing warranty coverage for factory servicing.
  • Page 39: E. Santa Clara St

    USA. Purchaser‟s remedies shall be limited exclusively to the right of repair or replacement. Heateflex Corporation shall not be liable for any expenses incurred by the purchaser or any other person by reason of the use, misuse, sale, or fabrication of the equipment regardless of whether the equipment conforms to the specifications.
  • Page 40: Www.heateflex.com

    Company shall repair/replace the unit or component(s) thereof, as required, on-site if possible, and will bear all expenses incurred for said repairs/replacements. World Leaders in Ultra-Pure Heating Revision 10 www.heateflex.com 01/17/13...
