Amkus GH2S2-XL User's Information Manual

Routine Maintenance for Couplings

Couplings should be kept free of dirt and contaminants.
They may be most easily cleaned by immersing in,
or scrubbing with, a petroleum based solvent such as
SAFE-SOL ® 140. Couplings should then be lubricated
with a non-water based lubricant such as WD-40 ® .
The rubber dust caps which are provided with the tools
should also be cleaned periodically. Be aware that
while the couplings may be clean, the dust caps will
accumulate dirt during use. Do not cover a clean cou-
pling with a dirty dust cap.

Maintenance Records

It is the responsibility of the user to keep maintenance
records for each component of the rescue system.
Maintenance shall be performed in accordance with the
recommendations as outlined in this manual.

General Maintenance and Storage

1. Always store the unit in a clean dry space.
2. Never store tools or power unit hoses under
pressure.
After each use:
1. Check to see that important markings are legible.
Contact your local dealer or AMKUS, Inc. for
replacement labels.
2. Wipe hoses, fittings and couplings clean (see
routine maintenance for hoses and couplings).
3. Inspect the power unit, hoses, fittings and
couplings after each use for damage, leakage
and excessive wear.
4. If damage or excessive wear is noticed, do not
use the power unit; contact your local dealer or
AMKUS, Inc.

GH2S2-XL Power Unit Specifications

Length: 23.0 in. (584 mm)
Width (with one hose loop standard): 19.0 in. (483 mm)
Height: 20.5 in. (521 mm)
Weight (Ready-to-use): 114.0 lbs. (51.7 kg)
(Includes gas, engine oil, hydraulic fluid and couplings)
Rated Output Pressure: 10,500 psi (724 bar)
Fluid Type: AMKUS MV-1 Mineral Base Hydraulic Fluid
(For equipment stored and operated in environments below
freezing use AMKUS MV-0 Mineral Base Hydraulic Fluid)
Hydraulic Fluid Reservoir Capacity: 2.0 gals. US (7.6 l.)
Usable Hydraulic Fluid Capacity: 1.45 gals. US (5.5 l.)
Maximum Angle of Inclination: 20 degrees from horizontal
GH2S2-XL
7/2015
Rev. 4
Parts, Service & Technical Information
Parts, service and technical information can be obtained
from your local AMKUS dealer or by contacting AMKUS, Inc.
Manufactured in the USA by
AMKUS, Inc.
2700 Wisconsin Ave.
Downers Grove, IL 60515-4226
Tel: 630-515-1800
Toll Free: 1-800-59 AMKUS
Fax: 630-515-8866
Website: www.amkus.com
E-mail: experts@amkus.com
AMKUS, Inc. is an ISO 9001
registered company.
4735

Troubleshooting Guide

Any problem not resolved by these suggestions may
require you to contact your local dealer or
AMKUS, Inc. for further guidance.
Problem Solution
Engine will not start Check owner's manual
or poor engine per-
troubleshooting guide.
formance
Rescue tools lack Check hydraulic fluid level
power or speed in power unit reservoir.
Fluid leaks at fittings Check tightness of hose
or hoses
fittings.
Replace damaged hoses.
Tools do not operate Check to see that the
power unit is running.
Check to see that the line is
charged.
GH2S2-XL Power Unit
User Information Manual
Certified Model NFPA 1936, 2015 edition
EN13204 Designation: MTO
Serial Number
Thank you for choosing AMKUS Rescue Systems. Please read this User Information Manual
thoroughly. If you have any questions, please contact your local dealer or AMKUS, Inc.
Please complete the tool registration form included with your equipment and return it to
AMKUS, Inc. You may also register your equipment on-line at www.amkus.com.
The serial number for your power unit is identified on the product label which is located on the
yellow hydraulic fluid reservoir. For quick reference, record the serial number on the cover of
this manual. Please have the serial number available if you need to contact your local dealer or
AMKUS, Inc.
DECLARED DUAL-NUMBER NOISE EMISSION VALUES in accordance with EN ISO 4871
Measured A-weighted emission sound pressure level, L
Uncertainty, K , in decibels: 1.5
pA
Measured A-weighted sound power level, L
Uncertainty, K , in decibels: 1.5
WA
Values determined according to Annex B of EN 13204 using the basic standards
EN ISO 3744 and EN ISO 11201.
Note: The sum of a measured noise emission value and its associated uncertainty represents an
upper bound of the range of values which can occur in measurements.
AMKUS, Inc., 2700 Wisconsin Avenue, Downers Grove, IL 60515-4226
Website: www.amkus.com E-mail: experts@amkus.com
Tel.(630) 515-1800 Fax (630) 515-8866
_______________________
(ref. 20µPa), in decibels: 88.6
pA
(ref. 1 pW), in decibels: 100.5
WA
