Lint build-up in the hook and feed dog area, as
well as between the top tension disks, can cause
excessive wear, noise and tension problems. Clean
and oil your machine frequently, and your machine
will reward you with trouble-free operation.
In addition, take your BERNINA® machine to an
authorized BERNINA® dealer for an annual check-
up (schedule this during your yearly vacation and
you won't miss your machine while it's gone!)
The technician will remove the covers, clean and
lubricate the interior parts, and check the overall
condition of your machine. He/she will also test and
adjust your machine to meet the manufacturer's
specifications and perform any factory-
recommended updates.
Whille some BERNINA® sewing machines display
a message when it is time to lubricate the hook,
there are times – such as when using linty threads
and fabric – when more frequent cleaning and oiling
is warranted, particularly in machines that have a

rotary hook system.

Oscillating (CB) Hook System

activa 125-240
virtuosa 130-160
aurora 430-440
artista 165, 170, 630
1004/1005, 1006, 1011-1530
all older BERNINA models (500s-900s)
Rotary Hook System
artista 180/185/200/640/730
1000, 1001, 1008, 1010
1630
®
Conscientious upkeep of your machine will keep it at
peak performance for years of uninterrupted sewing
pleasure!

Cleaning:

Remove the needle plate, bobbin case and hook.
Oscillating Hook System only: Remove the hook.
With a lint brush clean
around the feed dog,
the hook/hook race
and the surrounding
area of the hook.
Oscillating Hook
System only: Clean
the hook.
Clean the bobbin case.
Lift the presser foot bar
and with lint brush
clean each side of the
top tension discs.
Lower the presser foot
bar and use a length
of buttonhole twist or
cordonnet to floss
each side of the top tension discs. Check take-up
lever for jammed thread ends; remove if possible.

Oiling:

Oscillating Hook
System only: Reinstall
the hook.
Place one drop or
two drops of oil in the
areas shown, or as
indicated in your
BERNINA Guide and
Instruction Manual.
Reinstall the bobbin
case.
oscillating (CB) hook system
rotary hook system
