ns design CR Omni Bass Instructions

Strap system

The large, thin washer should be
placed between the instrument and the
hub (failure to use the washer can
damage the surface of the instrument).
Insert the attachment screw into the
threaded insert on the back of the
instrument. Use a 4 mm hex wrench,
flat screwdriver, or coin to tighten the
screw. The hub should be held firmly
but still be able to rotate.

Adjusting Long Arm Friction

Rotate the arms into position
for use, and attach
conventional guitar style strap
to the ends of the arms. Place
strap over the shoulder like a
guitar, and adjust the position
of arms and rotation of the hub
to the desired position for play.
The instrument should remain
in position.
NS CR Omni Bass Instructions
Attachment

Adjusting Pivot Friction

To adjust the arm friction, tighten or
loosen the two hex screws in the hub.
The screw closest to the long arm
should generally be tightened more
than the other screw, to provide more
friction on the long arm. The hex
wrench can be stored in the hole in the
ends of the tubes, but care must be
taken to insure that the hex wrench is
not positioned where it will scratch the
instrument when the arms are moved.
Strap
In Use
