Summary of Contents for Rosetta CERPRINT3500

Page 1: User Manual
3500 RINT Ceramic Decal Printer User Manual Version 2.1...
Page 2 If you need assistance with that part of the process, please contact us. We also welcome and ask for your feedback and suggestions. Please contact us at info@rosettatechnologies.com. This product was developed by Rosetta Technologies and Enduring Images. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved...
Page 3: Table Of Contents
Media Considerations ..........................21 Decal Transfer and Application ........................22 Printing Tips ..............................24 Firing Schedules ............................25 Warranty Support ............................27 Warranty Statement ........................... 27 Contact Information ............................ 27 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 3...
Page 6: What's In The Box
PC for the first time. Once the installation is complete the PS driver can then be installed from the Windows “Devices and Printers” Control panel. 1. Connect the printer via USB to a port on your computer. Turn on the printer 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 6...
Page 7 2. Windows will automatically install the PCL Version of the printer driver 3. Once the printer is installed. Open the Devices and Printers from the Control panel 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 7...
Page 11 7. Click Next on the “Add Printer Driver Wizard”. 8. Click on the “Have Disk…” button on the Printer Driver Wizard. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 11...
Page 12 10. Extract the files to the c:\Temp\3500 PS folder. a. If one does not exist, the extractor will create one. b. Click Unzip 11. If successful, the following will display. 12. Close the extractor. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 12...
Page 13 13. Go back on the Have Disk screen press Browse 14. Navigate to the “c:\Temp\3500 PS\disk1” folder. a. Select the GIEPA.inf file, and press open. 15. Click OK on the “Install From Disk” screen. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 13...
Page 15 17. Once completed the PS Driver is now installed. a. Click Finish to close the Add Printer Wizard. 18. Once completed, go to the General tab and click Print Test Page to test the PS Driver. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 15...
Page 16 Troubleshooting Guide. If the printer driver does not print. Remove the device from the “Devices and Printers” Control Panel. Right click and remove device. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 16...
Page 17: Setting Up The Driver For Printing
Media type set to Plain 1. Also, we recommend using the bypass tray for decal printing. You can experiment with this, but this selection gives the most consistent results. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 17...
Page 18 Then scroll down and click on the “+” box next to PostScript options. Scroll down to Mirrored Output and change it to “Yes”. Click “OK”, then Click “OK” again. If your application is already creating mirror images, then you can skip this part. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 18...
Page 19 Pull out the paper support guide. Make sure the paper guides on either side are spread to the 8.5 inch position. Insert your media face up in the tray. Print the page from your application. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 19...
Page 20: Installation Mac Os
Use this function to select the tray from which you want to feed paper. We recommend the Bypass Tray. You can select [Auto Select], [Tray 1] or [Bypass Tray]. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 20...
Page 21: Media Considerations
NOTE: It is very important that you remove the protective cover sheet from the decal side of the paper. On some papers, it is very difficult to distinguish this sheet from the actual decal stock. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 21...
Page 22: Decal Transfer And Application
After squeegeeing, we recommend the use of a silicone roller or brayer to ensure that full contact between the decal film and the ceramic surface is made. Roll from the middle out. These are also available from ceramic supply stores. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 22...
Page 24: Printing Tips
After spray application, remove the paper and discard. MICR Toner Cartridge – The Rosetta MICR Toner Cartridge, shown on the CerPrint 3500 Price sheet, is an excellent second toner cartridge for the CerPrint 3500. This toner cartridge can print decorations that, when sprayed with aerosol flux cover coat and fired to the lower temperatures possible with aerosol spray, give images far superior to standard prints from H-P and Canon black and white printers.
Page 25: Firing Schedules
1600 Degree Fahrenheit Firing Schedule Step Range Rate Time 70F to 160F 40F per hour HOLD 2 hours 130F per 160F to 850F hour 250F per 850F to 1600F hour HOLD 30 min. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 25...
Page 26 1200F. It is not food safe, but is fine for other ceramic pieces that will not be used to serve food or beverages. 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 26...
Page 27: Warranty Support
USE THE EQUIPMENT, OR FOR ANY DAMAGES (REGARDLESS OF THEIR NATURE) ARISING FROM BREACH OF WARRANTY OR CONTRACT, NEGLIGENCE OR ANY OTHER LEGAL THEORY OR FROM THE CLAIMS OF ANY THIRD PARTY. IN NO EVENT SHALL ROSETTA TECHNOLOGIES’ LIABILITY FOR ANY EQUIPMENT EXCEED THE SELLING PRICE OF SUCH EQUIPMENT TO BUYER.
Page 28 True Black Cerprint Toner cartridge, for use with any media Aerosol can spray flux cover coat; lead free or low temp Extended Warranty (post initial warranty) Coverage is available. www.enduring-images.com www.rosettatechnologies.com 6/1/2018 Rosetta Technologies & Enduring Images All Rights Reserved Page 28...
