Page 1
SMARTCLEAN ® CONNECTED Robotic Vacuum ___________ USER GUIDE 2147 SERIES More of a video person? Look for this icon and go online for an instructional how-to video at www.BISSELL.com/ videos...
» Do not plug in your vacuum cleaner UNTIL you are familiar with all instructions and operating procedures. » To reduce the risk of electrical shock, turn Power Switch OFF and disconnect polarized plug from electrical outlet BEFORE performing maintenance or troubleshooting checks. www.BISSELL.com...
(RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body. Package Contents BISSELL SmartClean® Connected Robotic Vacuum 2. Rechargeable Li-Ion Battery 3.
Page 4
Navigation Sensor LED Control Panel & WIFI Indicator Bumper IR Receiver (for docking station) Docking Station 10 LED Cliff Sensors 11 Front Wheel 12 Edge-Cleaning Brushes 13 Brush Roll 14 Rear Wheels 15 Wheel Cover Plates 16 Battery Cover Plate www.BISSELL.com...
Step 2: Install the Side Brushes To install the side brushes, push the brush into the holder. You may hear a “click” that indicates that the brush is in place. www.BISSELL.com...
Page 6
ON position. ‘SP’ will read on the display. The robot will not function manually or from the app while in sleep mode. To turn sleep mode OFF, turn the Power Switch OFF and then back ON. www.BISSELL.com...
Page 7
Clean with Your SmartClean® Connected Getting Ready to Clean There are 2 options for cleaning: Option 1: Schedule cleanings using the BISSELL Connect App Option 2: Manual cleaning using the robot’s control panel or the BISSELL Connect App NOTE: Before using this device, pick up objects like clothing, loose papers, and power cords.
Page 8
What It Means Battery Low: Battery needs to be charged (Power LED turns Red) The trash can indicator shows the Dust Bin is full and needs to be emptied The battery is full when the icon is illuminated green. www.BISSELL.com...
Once per week, see page 10 Every 2-3 months Brush Roll Once per week, see page 11 As needed Sensors Once per month, see page 12 Not required Edge Cleaning Brushes Every 2-3 months, see page 12 Every 6-12 months www.BISSELL.com...
Bin. on unit. Periodically clean the Once clean, reinstall the Place Dust Bin back in Filter with the attached Filter and close the Dust the cleaner and close top Cleaning Tool. Do not Bin lid. cover. wash the Filter. www.BISSELL.com...
Page 11
Brush Roll compartment. Push the round end inward and fit the opposing square end of the Brush Roll into the square end of the compartment until it Re-insert the Brush Roll Cover back onto is securely in place. the unit. www.BISSELL.com...
Place bottom of the them in hot water to make them return to cleaner upward on a flat surface. Hold the the original shape. Replace the brushes Brush bristle and pull upward to remove after they have completely dried. the Brush. www.BISSELL.com...
DISPOSAL OF BATTERY If your SmartClean robotic vacuum is to be disposed of, the battery should be removed and disposed of properly. For specific disposal instructions of the battery, please contact RBRC (Rechargeable Battery Recycling Corporation) 1-800-822-8837 or visit www.Call2Recycle.org www.BISSELL.com...
Page 14
Remove robot from the flooring and use the Invisible Wall to keep the robot off of the flooring where the error occured Battery is not installed See page 5 for proper battery installation. properly, charging error Make sure Power Switch is turned on during charging www.BISSELL.com...
NOTE: Please keep your original sales receipt. It provides proof of date of purchase in the event of a warranty claim. Service If your BISSELL product should require service: Contact BISSELL Consumer Care for information about repairs or replacement parts or if you have questions about your warranty. Website: Call: www.BISSELL.com...
