Summary of Contents for ANTIFERENCE HDMI8X8MC
- Page 1 4K HDBase-T Matrix Kit Simple set up guide HDMI8X8MC...
- Page 2 4K Compact Matrix Important Safety Notice Thank you for purchasing this Antiference HDMI distribution product. Please read the following instructions carefully and retain for future reference. Please pay careful attention to the following safety considerations: 1. Do not place any items on the device 2.
-
Page 3: Table Of Contents
4K Compact Matrix Content 1. Introduction 1.1 Features 1.2 Package Contents 2. Product Appearance 2.1 4K HDBaseT Maxtrix Switcher 2.2 HDBase-T Receiver 3. System Connection 3.1 System Applications 3.2 Connection Diagram 3.3 Installation Procedure 4. System Operations 4.1 IR Control 4.1.1 IR Remote 4.1.2 Control TV set at matrix location 4.1.3 Control Local Device Remotely... -
Page 4: Introduction
4K Compact Matrix 1.Introduction This Antiference HDMI product is a professional 4K HDBase-T matrix kit with HDCP2.2 support. The kit consists of the 4K Matrix Switcher, 7 HDBase-T PoC receivers, PSU & IR accessories. The product features 8 HDMI inputs & 7 HDBase-T outputs + 1 HDMI output. -
Page 5: Package Contents
4K Compact Matrix 1.2 Package Contents 1 x 4K HDBaseT Matrix Switcher 2 x Mounting ears & 6 x Screws 4 x Trapezoidal Plastic pads 1 x Power Cord 8 x IR Receivers 9 x IR Emitters 1 x IR Remote 1 x RS232 cable(Phoenix to DB9) 7 x HDBaseT Receivers 14 x Mounting ears &... - Page 6 4K Compact Matrix 2) Rear Panel Name Description HDMI INPUTS 8 x HDMI inputs: Type A female HDMI connector, connect the source device with an HDMI cable to any of the HDMI inputs. • 7 x HDBaseT outputs: The HDBT OUTPUTS RJ45 outputs deliver HD video, Audio and PoC to the HDBaseT Receiver up...
- Page 7 4K Compact Matrix Name Description IR OUT • 8 x IR OUT: Plug in IR emitters to deliver the IR signal sent from the far- end receivers connected to the HD- BaseT ports. These IR OUT sockets make up an IR matrix with the IR IN sockets on the far-end receivers, and all can be switched simultaneously with the AV signal, or separately from...
-
Page 8: Hdbase-T Receiver
4K Compact Matrix 2.2 HDBase-T Receiver 1) Front Panel LINK HDCP HDMI OUT IR IN IR OUT TP IN Name Description HDMI OUT Connect to the HDMI display. IR IN Connect the IR receiver and position in a suitable location where the RCU can be pointed at it. - Page 9 4K Compact Matrix 2) Rear Panel LINK HDCP HDMI OUT IR IN IR OUT TP IN Name Description Power Indicator • OFF: No power; • RED: DC power present (PoC). TP IN The RJ45 socket has two LED status indicators. HDCP: •...
-
Page 10: System Connection
4K Compact Matrix 3. System Connection 3.1 System Applications This Antiference Compact 4K matrix kit is designed for residential and com- mercial applications delivering 4K & HD video & audio to up to 8 locations/TV sets with IR control. Compatible source devices include SKY HD/Q, Blue Ray Player, Apple TV or CCTV systems. -
Page 11: Installation Procedure
4K Compact Matrix 3.3 Installation Procedure 1. Connect HDMI sources (e.g. SKY Q) to HDMI input ports of the Matrix Switcher using good quality HDMI cables. 2. Connect the Pre-Installed CAT6 cable infrastructure to Matrix Switcher and HDBase-T receivers. 3. A local TV set may be connected to the matrix via the HDMI output port. 4. -
Page 12: System Operations
4K Compact Matrix 4.System Operations 4.1.IR Control 4.1.1.IR Remote Connect the supplied IR receiver to the IR EYE port of the matrix. This allows the user to control the matrix locally with the remote control supplied. This feature can be useful if the matrix is to be located in a cupboard. Additional remote controls are available –... -
Page 13: Control Tv Set At Matrix Location
4K Compact Matrix To switch an input to an output: Example: input 1 to output 3 → Press INPUTS 1 + OUTPUTS 3 The above procedure is can be carried out on the matrix front panel or via the remote control unit. Default status, on initial boot up the matrix assigns the IR outputs to the corre- sponding HDMI input, meaning, IR out 1 is directly associated to HDMI input 1 and so on. -
Page 14: Control Local Device Remotely
4K Compact Matrix 4.1.3 Control Local Device Remotely Connect IR receiver(s) to IR IN on far-end HDase-T receiver(s), and IR Emitter(s) to IR OUT port of the switcher, and use the IR Remote of local source to control the device remotely. 1 to 1: Connect an IR receiver to IR IN on far-end HDBT receiver, and an IR Emitter to IR OUT port of the switcher. -
Page 15: Specification
4K Compact Matrix 5.Specification 5.1 4K HDBaseT Matrix Switcher Video Input Input 8 HDMI Input Connector Female HDMI Input Level T.M.D.S. 2.9V~3.3V Input Impedance 100Ω (Differential) HDMI Standard Support 4K@60 4:2:0 & HDCP2.2 and is backward compatible with all previous standards. Video Output Output 1 HDMI –... - Page 16 4K Compact Matrix Audio general Output Signal Stereo audio Digital audio Analog Audio Output Support PCM Digital Audio Output Supports PCM, Dolby, DTS, DTS-HD Frequency Response 20Hz~20KHz Output Connector 1 L&R(RCA) 1 SPDIF Control Parts Control Ports 8 IR OUT 1 IR ALL OUT 7 IR IN 1 IR EYE...
-
Page 17: Hdbaset Receiver
4K Compact Matrix 5.2 HDBaseT Receiver Input & Output Input 1 HDBaseT Input Connector Female RJ45(with LED indicators); Output 1 HDMI Output Connector Female HDMI Control 1 IR IN 1 IR OUT Control Connector 3.5mm mini jacks General Resolution Range Up to 4K×2K@60Hz Transmission Mode HDBaseT... -
Page 18: Panel Drawing
4K Compact Matrix 6. Panel Drawing 6.1 1.4K HDBaseT Matrix Switcher 6.2 HDBaseT Receiver LINK HDCP TP IN HDMI OUT IR IN IR OUT 61.60 mm... -
Page 19: Troubleshooting & Maintenance
4K Compact Matrix 7. Troubleshooting & Maintenance Problems Potential Causes Solutions Loss of colour or no The connecting cables Check whether the video signal output may not be connected cables are connected correctly or it may be correctly and in working broken condition. - Page 20 4K Compact Matrix Power Indicator remains Failed or loose power Check whether the off when powered on connection cables are connected correctly EDID management The HDMI cable is Change to another does not work normally broken at the output . HDMI cable which is in good working condition.
-
Page 21: Declaration Of Conformity
4K Compact Matrix Declaration of Conformity We, ANTIFERENCE LIMITED herewith declare that this matrix switcher complies with all essential requirements and any other applicable conditions set forth on directive EMC2014/30/EU. According to the WEEE (Waste Electrical and Electronic Equipment) EU Directive, do not dispose of this product as household waste or commercial waste.
