Nuvoair Air Smart Spirometer User Manual

SETTING UP
YOUR DEVICE
1
Download the Air Smart Spirometer
app from the App Store.
2
Connect the spirometer to
your phone and open the app.
3
"Air" Would like to
Access the Microphone
DON'T ALLOW OK
Tap OK to allow access
to your phone's microphone.
4
Volume
Increase the volume
to the maximum level.
5
Settings
Check Device Status
Make sure the spirometer
has a functioning battery.
6
Device Status OK
You are now ready to
perform a lung function test!
UserManual_14102015.indd 1
PERFORM A LUNG FUNCTION TEST
1
Insert a new FlowMir® turbine Turn the turbine clockwise
by sliding it through the device.
Take a deep breath and exhale as
Start breathing normally
forcefully as possible, and empty
through the turbine.
Relax
1 2 3
I'm Ready!
When the first test is completed, Once you have performed all the
rest for 15 to 30 seconds before tests included in the session, the
tapping I'm ready! final results will be displayed.
2
until it locks into place.
Test (1 of 3)
2s
You should exceed 6 seconds
of exhalation to obtain a high
your lungs completely. quality spirometry test.
Results
Flow
You can share
graphs and
session values
by email.
Volume
Gender
Height
Age
Start test
Fill in the profile information and tap
Tap Start Test. Proceed to Test. Read the information on the
screen and tap Start Test when you are ready.
Test (1 of 3) Test (1 of 3)
6s 15s
The maximum time allowed
for a test is 15 seconds.

ADDITIONAL SETTINGS

Settings
Height Units
Required Trials
Device Status
Last Checked
Check Device Status
Perform a battery
status check of
the spirometer.
Profile
Female
160 cm
35
Proceed to Test
Start Test
The device
will stop
measuring
once you
stop exhaling.
cm
3
OK
06-11
Change the number
of test per session
(we recommend 3).
2015-10-26 10:55
