- Page 1 SnapShot Extra Black 12.0i HD INSTRUCTION MANUAL GAME & SURVEILLANCE CAMERA outdoor-focus.de...
-
Page 2: Table Of Contents
INDEX 01 | SAFETY HINTS 02 | SAFETY HINTS FOR BATTERIES 03 | PRIVACY POLICY THANK YOU for choosing this DÖRR quality product. 04 | PRODUCT FEATURES 05 | NOMENCLATURE Please read the instruction manual and safety hints carefully before 06 | FIRST USE fi... - Page 3 01 | SAFETY HINTS 03 | PRIVACY POLICY Your camera is fitted with a weatherproof housing according to protection class IP54 In every country, legal data protection rules apply. As these rules may vary per country, • (dust and splash waterproof). So the camera can be used outdoors. Nevertheless please contact the appropriate authorities to learn about the latest privacy policy in your protect the camera from extreme weather conditions and direct sunlight.
- Page 4 05 | PRODUCT FEATURES 06 | NOMENCLATURE This versatile and reliable surveillance camera o ers great user comfort and many useful Infrared fl ash features for an e ective surveillance of hunting grounds, gardens and many other ob- LED indicator jects.
-
Page 5: Inserting Batteries
06 | FIRST USE 07 | MAIN SCREEN/MENU LANGUAGE/BASIC SETTINGS 06.1 INSERTING BATTERIES Switch the slide control (9) to position SETUP. The LCD display (8) will show real time Open the camera releasing the lateral tension lock (6). Make sure the slide control (9) is image and the basic settings. -
Page 6: Changing The Settings
07.3 BASIC SETTINGS Camera Mode Photo Trigger Mode PIR trigger Work Time 1, 2, 3, 4 Set Clock Camera Scene PIR Sensitivity Language Auto Auto Format PIR Interval 1 Min Password Rename Beep Overwrite Format SD Card Default Software Version 08 | CHANGING THE SETTINGS In order to change the pre-settings, switch the slide control (9) to SETUP position and press the menu button (10). -
Page 7: Camera Mode
09.2 CAMERA MODE “PHOTO” 09.2.1 CAMERA SCENE Choose from the pre-set camera scenes or change the settings individually: Camera Scene Description Auto 8 MP colour picture at daytime 3 MP black/white picture at night Close Object Close distance 3 - 5 meters with suited fl ash range 8 MP/day –... -
Page 8: Trigger Mode
10 | MENU PIR (MOTION DETECTOR) 10.1 TRIGGER MODE Options Trigger Mode OK PIR Trigger * MENU PIR Sensitivity Auto * High PIR Interval 1 min * 1 min - 60 min, 0 sec - 55 sec Trigger Mode OK Time Lapse MENU Timer Interval 4 hrs *... -
Page 9: Menu Wkt (Work Time
11 | MENU WKT (WORK TIME) Options Work Time 1 Start: 00:00 (HHMM) Set start time Next input fi eld Stop: 00:00 (HHMM) Set stop time Next input fi eld Select working days Sun., Mon., Tue., Wed., Thu., Fri., Sat. ü... -
Page 10: Set Clock (Date And Time
12 | MENU SYS (FURTHER SETTINGS) Options Set Clock OK DD/MM/YYYY (Format: Day/Month/Year) MM/DD/YYYY (Format: Month/Day/Year) YYYY/MM/DD (Format: Year/Month/Day) Next input fi eld Set values Next input fi eld 00:00:00 Set time Set values Next input fi eld Language OK German * English, French, Italian, Hungarian, Norwegian, Swedish, Czech, Danish, Finnish Password... -
Page 11: Test Photo
12.6 OVERWRITE Set "On": As soon as the SD card is full, the camera will overwrite the oldest pictures with new ones. Set "O ": As soon as the SD card is full, the camera will stop recording until the SD card is changed or SD card is formatted. 12.7 FORMAT SD CARD This function deletes all data on the SD card. -
Page 12: Delete Photos And Videos
14.3 DELETE PHOTOS AND VIDEOS CAUTION Once deleted, you can not restore pictures or videos again! 14.3.1 DELETE SINGLE PICTURE/VIDEO Switch the slide control (9) to position SETUP. Press the OK button (15). Select the picture/video you want to delete with the arrow buttons (12) or (13). -
Page 13: Motion Detector
18 | CAMERA INSPECTION There are various possibilities to check if pictures/videos have been taken: 1. Open the camera and move the slide control (9) to position OFF. After 1-2 seconds switch the slide control (9) to position SETUP. The LCD Display (8) shows the main/live screen. The bottom line shows how many pictures have been taken and how many still fit on the SD card (e.g. - Page 14 21 | TECHNICAL SPECIFICATIONS Model SnapShot Extra Black 12.0i HD Item No. 204410 Flash Infrared/63 LEDs Black Vision/940 nm Flash range adjustable low/medium/high up to 20 m (depending on weather conditions) Lens F/2,2 ISO100 Image sensor 3 MP Image resolution...
-
Page 15: Weee Information
23 | DISPOSAL, CE MARKING 23.1 DISPOSAL OF BATTERIES/ACCUMULATORS Batteries are marked with the symbol of a crossed out bin. This symbol indicates that empty batteries or accumulators which can no longer be charged should not be disposed of with household waste. Waste batteries may contain harmful substances that can cause damage to health and to the environment. Please use the return and collection systems available in your country for the disposal of the waste batteries. - Page 16 DÖRR GmbH Messerschmittstr. 1 D-89231 Neu-Ulm 204410 Item No Fon: +49 731 97037-0 Fax: +49 731 97037-37 info@doerrfoto.de doerrfoto.de outdoor-focus.de...
