Veracity Pointsource Plus VAD-PSP Quick Start Manual

WHAT'S IN THE BOX
1 x POINTSOURCE Plus Unit
2 x Rechargeable Battery Module
3 x Carry Strap - adjustable
4 x Universal Charger (UK, US, EU, AU plugs)
5 x Quick Start Guide (this leaflet)
1
2
3
4
05

MAINTAINING BATTERY MODULE

PERFORMANCE

For optimal performance and longevity, POINTSOURCE Plus should
be fully charged. POINTSOURCE Plus has an anticipated battery
life of about 3 years, or approximately 200 - 300 charging cycles,
depending on discharge depth and operating temperature.
The battery status indicator shows the remaining charge available in
steps of 25%.
| Before first use
| After long periods of storage
| Before being stored for long periods
| Every six months during storage
Always switch off POINTSOURCE Plus when it is not in use, even
if the unit is fully discharged. The battery module should not remain
Connected to the charger for any longer than 16 hours max.
BATTERY MODULE REPLACEMENT
AND END-OF-LIFE
When the battery module has reached end-of-life, it must be disposed
of either:
| At a lead-acid battery collection facility, or
| Via Veracity's defined RMA process
please contact rma@veracityuk.com or
support@veracityusa.com for further details
If this battery is dropped or cracked, the contents of the battery inside
should remain in gel form and no leakage should occur. The Health
& Safety representative should be contacted, and protective gloves
should be used to move the damaged battery to a place of
quarantine, before arrangements for disposal are made.
06

IMPORTANT SAFETY NOTES

| Only the charger supplied should be connected to the
POINTSOURCE Plus.
| Do not charge POINTSOURCE Plus in a fully sealed enclosure.
| Do not attempt to service the unit or open the battery module.
Any attempt to open the battery module invalidates the warranty.
07
VAD-PSP
QUICK START GUIDE
PORTABLE BATTERY POWERED POE INJECTOR
