Lorex LEV1512 SERIES Quick Start Manual

Contents
• Weatherproof HD dome camera*
• Mounting kit*
• 60ft/18m UL-rated BNC / power extension cable*
• Power adapter**
* Per camera in multi-camera packs.
** A multi-camera power adapter or individual power adapters may be provided, depending on
product configuration.
ATTENTION - A REGULATED UL / CSA APPROVED
12V DC power supply is REQUIRED for use with this
camera. Use of a non-regulated, non-conforming
power supply can damage this product and voids the
warranty.
Warning/Caution
• Read this guide carefully and keep it for future reference
• Follow all instructions for safe use of the product and
handle with care
• Use the camera within given temperature, humidity and
voltage levels noted in Camera Specifications
• Do not disassemble the camera
• Do not point the camera directly towards the sun or a
source of intense light
• Periodic cleaning may be required. Use a damp cloth
only. Do not use harsh cleaners or aerosol cleaners
• Cables for in-wall / floor-to-floor installations are sold
separately
Dimensions
3.7" / 93mm
2.9" / 74mm

Installation Tips

• Point the camera where there is the least amount of
obstructions (i.e. tree branches)
• Install the camera in a location that is difficult for vandals
to reach
• Secure cabling so that it is not exposed or easily cut
• Camera rated for outdoor use. Installation in a sheltered
location recommended
Resources

Need Help?

Visit us online for up-to-date software and complete
instruction manuals
1
Vist www.lorextechnology.com
2
Search the model number of your product
3
Click on your product in the search results
4
Click the Downloads tab
Copyright © 2016 Lorex Corporation
As our products are subject to continuous improvement, Lorex Corporation reserves the right to modify
product design, specifications and prices, without notice and without incurring any obligation. E&OE
LEV1512_SERIES_TRIFOLDQSG_EN_R1
MPX HD WEATHERPROOF
NIGHT VISION SECURITY CAMERA
Quick Start Guide
English Version 1.0
LEV1512 SERIES
