iLive IAEB67B User Manual

Bluetooth headset
User's Guide for Model IAEB67B v1954-01

Earbud Controls

Right side shown. All controls and features are duplicated on the left earbud.

Battery Charging

Initial charge time is approximately 2 hours. Charge fully before
use. The low battery indicator will flash for 1 minute, then the
unit will automatically power OFF.
1. Pull back the cover on the DC Power Input.
2. Using a Micro-USB to USB cable, connect to the USB
port of a powered on computer or USB power adaptor
(not included) to charge the unit.
3. Charge both earbuds at the same time with the included
dual Micro-USB charging cable.
Status
Power ON / Bluetooth Paired /
Earbuds Linked
Pairing Bluetooth
Linking Earbuds
Low Battery
Charging
Fully Charged
Power / Pair / Play / Pause / Speakerphone
Press and hold for 9 seconds to power ON and pair Bluetooth.
Press and hold on both earbuds to link to each other.
See "Linking Earbuds" on next page before attempting.
Indicator
Slow flashing blue light
Quick flashing red / blue lights
Quick flashing red / blue lights
Slow flashing red light
Solid red light
Solid blue Light
Press and hold to power ON or OFF.
Press to play or pause audio.
Press to answer incoming phone call.
Link
Volume / Skip +/-
Press to adjust volume.
Press and hold to skip tracks.
Microphone
Indicator LED
DC Power Input
