- Page 1 In accordance with AS/NZS 6400 AS/NZS 3718 0277 WM-020209 Jiangmen Ottanta Otto Faucet Co., Ltd. ITM. / ART. 180229 OWNER’S MANUAL # QVA085...
-
Page 2: Table Of Contents
Table of Contents Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Installing the Faucet . -
Page 3: Warranty
Warranty ONE YEAR LIMITED WARRANTY A thorough inspection must be made before installation and any damage must be promptly reported . We will not be liable for failures or damage that could have been discovered or avoided by proper inspection and testing prior to installation . Conglom Kitchen &... -
Page 4: Pre-Installation
Pre-Installation TOOLS/MATERIALS REQUIRED (NOT SUPPLIED) Adjustable Needle nose Phillips wrench pliers screwdriver Utility knife Pipe wrench Sealant Hacksaw Carpenter’s level Hex key Safety gloves Safety goggles PARTS REQUIRED (NOT SUPPLIED) NOTE: Parts not shown to actual size. Drain P-Trap Supply lines Shims Assembly QVA085... -
Page 5: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Carefully check the utility cabinet for damage and/or missing parts prior to installation . If there is any damage or if you are missing parts, do not proceed with the installation . Report damage and/or missing parts immediately to our customer service team cs@conglomkb.com or +61 2 87245218 (Service available Monday - Friday from 6:30 am - 3 pm AEDT). -
Page 6: Installation
Installation INSTALLING THE LEVELING LEGS 1 . Unpack the unit and place the sink (C) on a blanket or WARNING: Always wear safety goggles and gloves cardboard to protect the surface . during installation . 2 . Turn the cabinet (A) upside down onto the protective surface . CAUTION: Do not place side load onto cabinet base when 3 . -
Page 7: Installing The Handles
Installation (continued) INSTALLING THE HANDLES - Attach door handles (E) to the cabinet doors using supplied door handle screws (F) and a screw driver . Do not overtighten . - Repeat this procedure to attach the handles to the drawers . ADJUSTING THE DOOR POSITION If the doors need to be repositioned, the hinges can be adjusted to ensure a precise fit with the cabinet. -
Page 8: Installing The Faucet
Installation (continued) INSTALLING THE FAUCET Handle Install the mounting studs into the faucet properly . Attach the gasket to the base plate, and put base plate to fit the underside of faucet . Install and tighten the Hot and Cold water hoses to the faucet using a wrench . -
Page 9: Mounting The Utility Sink
Installation (continued) MOUNTING THE UTILITY SINK Carefully place a bead of sealant all around the top of the cabinet . Ease the sink onto the cabinet, and ensure it is placed evenly and centered on the cabinet . Wipe off any excess sealant . Use masking tape to hold the sink in place until the sealant dries . -
Page 10: Care And Cleaning
Care and Cleaning Your vanity set is manufactured with the highest grade materials and will provide you many years of enjoyment with the proper care . SINK CABINET - After use, always rinse your sink with tap water to - Remove dust and dry dirt with a soft, damp cloth . dilute and remove deposits . -
Page 11: Service Parts
Service Parts If you are missing parts or if you require replacement parts, please contact our customer service team at cs@conglomkb.com or +61 2 87245218 (Service available Monday - Friday from 6:30 am - 3 pm AEDT . Identify the required part(s) and have the part number(s) ready . Part Description Code Quantity... - Page 12 +61 2 87245218 | cs@conglomkb.com (service available Monday - Friday from 6:30 am - 3 pm AEDT) www.conglomkb.com Made in China and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license by Conglom Inc. All Rights Reserved. Retain this manual for future use.
