LUX
C O M F O R T H E A D P H O N E S
Make sure the following items are included in your package.
USB Cable
AUX Cable
Powering On Your Earphones & Pairing Them With a Bluetooth Phone
-Press and hold the Power Button for approximately 7-8 seconds. When
your headphones are ready to pair with a Bluetooth audio source, they will
go into pairing mode. The LED Indicator Light will alternately flash red and
blue to indicate that your headphones are ready to be paired.
Right
Earcup
Power Button

Wearing Your Headphones

For the best sound performance and a secure, comfortable fit, be sure that the
earcups rest gently on your ears, with the headband sitting securely on top of your
head.
Note that the headband is extendable, so that your headphones can fit comfortably
on heads of most shapes and sizes.
Earcups
For a look at the various buttons and parts of your headphones, view the graphic below.
Left
Earcup
MZX757
LUX
Comfort Headphones
-Go to the Bluetooth Manager on your phone.
Search Bluetooth devices and select "lux headphone " to start
connecting. Once paired, the LED Indicator Light will slowly flash
blue every few seconds.

Using Your Headphones with Non-Bluetooth Devices

You can also use the included Aux Cable to connect audio
devices through the Auxiliary Port on your headphones.
Listening To Music
Play/Pause
Press the Power Button to get music from your audio source to play or pause.
Next/Previous Song
Rotate and hold the Control Dial forward to advance to the next song in a playlist.
Rotate and hold the Control Dial backwards
to advance to the previous song in a playlist.
Headband
Increase/Decrease Volume
Rotate the Control Dial forward to increase
volume. Rotate the Control Dial backwards
to decrease the volume.
NOTE: Music will automatically pause when
a call is dialed out or when there is an incoming
call. It will resume when the call ends.

Quick Start Guide

FRONT VIEW
SIDE VIEW
Power Button
Auxiliary Port
Microphone
Micro USB
Charging Port
-Once powered on, you can press and hold
the Power button again for approximately
five seconds to power o your headphones.
NOTE: In order to save power, your
headphones will automatically power o if left
unpaired or idle for over ten minutes.
lux headphone
If you have previously paired your
headphones with a phone, you can press the
Power Button for three seconds to power on
your earphones and they will automatically
connect with the last phone which you paired with.
Power
Button

Charging Your Headphones

When charging, an LED Indicator Light will turn red. When charging is complete,
the LED Indicator Light will turn o . Your headphones can take up to two
hours to fully charge.
Control Dial
LED
Indicator
Light
IMPORTANT
---By pressing the Power Button down for about 3 seconds, your
headphones will power on and connect to the last phone they were
paired with.
---In order to pair your headphones with your phone for the first
time be sure to hold down the Power button for a full 7-8 seconds.
When ready to pair the LED light will flash red and blue alternately.
--If you are having trouble pairing your headphones with your
phone, be sure that you are holding down the Power Button long
enough for your headphones to go into pairing mode.
Using Your Headphones During Phone Calls
Last Number Redialing
Quickly tap the Power Button twice and the last number that you dialed will be
redialed.
Answering an Incoming Call
To answer an incoming call, quickly
press the Power Button.
Ending a Call
To end a call, quickly press the Power
Button, and the call will be disconnected.
Rejecting a Call
Control
To reject a call, press and hold the Power
Dial
Button, and the call will be disconnected.
Power
Button
